Hezborg BGR8016B Product Manual

All technical interest rates prevail in the performance
of the real machine,
Herzborg reserves the final interpretation.
16-CHANNEL
SMART EMITTER
PRODUCT MANUAL
MODEL：BGR8016B
SMART HOME
From The German Quality
For More Information, Please Visit Our Website
www.herzborg.de
For More Information, Please Visit Our Website
www.herzborg.de
EQUIPMENT OPERATION
DEVICE CODE:
Button "1", "2", "3", "4" is the first channel; "5", "6", "7",
"8" is the second,"9", "10", "11","12 " is the third channel;
"13", "14", "15", "16" for the fourth. Take the first channel
as an example of device code. (The second, third and
fourth channel are the same as the first)
In the code, press the emitter "2" button and "4" button
twice, and then press the emitter "1" button once to
complete the device code.
NOTE: After the success of the code, the device will be
displayed in the APP emitter list.
02
Smart Module
Introduction
For More Information, Please Visit Our Website
www.herzborg.de
MAIN FUNCTION
BGR8016B smart emitter can mark button mode
・・
by replacing the inserted card; through 868MHZ,
16 scenes can be controlled.
SMART EMITTER
SPECIFICATION:
· Product Name: 16-CHANNEL SMART EMITTER
· Product Model: BGR8016B
· Control: 868MHz
· Working Temperature: －10℃～60℃
· Dimensions: 86mm x 86mm
· Input Power Supply: 3V (3CR2430battery)
· Wireless Range: outdoor100m, indoor35m
· Directive: LED
01
Smart Module
Introduction
For More Information, Please Visit Our Website
www.herzborg.de
BUTTON SPECIFICATION
Button 1
Button 3
Button 5
Button 7
Button 9
Button 11
Button 13
Button 15
03
Smart Module
Introduction
Button 2
Button 4
Button 6
Button 8
Button 10
Button 12
Button 14
Button 16
