- Page 1 Lenovo Mobile Phone User’s Guide Model: S62 Please read this guide carefully before using the phone for the first time.
- Page 2 The purpose of the user manual is to help you correctly use the Lenovo product, which doesn’t mean to make any explanations on the configuration of software and hardware of this product. For information on product configuration, please refer to the agreement (if any) related to this product, or consult with the retailer who sold the product to you.
- Page 3 Lenovo mobile phone shopping malls at: http://shop.lenovomobile.com.
-
Page 4: Table Of Contents
Contents 1. Safety and Maintenance -------------------------------------------------------- 6 2. Installation and charging ----------------------------------------------------- 11 2.1 I ................11 NSTALL BATTERY 2.2 R ................11 EMOVE BATTERY 2.3 C ................12 HARGE BATTERY 2.4 I ................13 NSTALL CARD 2.5 R ................13 EMOVE CARD 2.6 I... - Page 5 9. Technical Parameters --------------------------------------------------------- 35 5．SAR ....................36...
-
Page 6: Safety And Maintenance
•Use only the standard batteries, charger and accessories approved by Lenovo. Lenovo bears no responsibility for any consequences resulting from the use of third-party accessories. •Your mobile phone may interfere with other electronic devices around it. - Page 7 •Using any cell phone cover or plastic phone cover may damage the coating of the phone housing. •Do not disassemble your mobile phone. •Do not clean mobile housing with any dissolved matter, such as benzene, thinner or alcohol. Don’t expose your phone to corrosive chemicals, such as cleaning agents.
- Page 8 If electrolyte splashes into your eyes, you may have the risk of getting blind. In this case, rinse your eyes with clean water (never rub the eyes) and see a doctor immediately. •Squeezing of battery, mechanical vibration or shaking of battery or use of short-circuited battery is strictly prohibited, because such vehavior will damage the battery or components connected with it.
- Page 9 •Keep your battery in a safe place out of the reach of children to avoid any danger. Please follow the precautions below to use the charger. •Please read the instructions and the labels on the surface of the charger carefully before using it. •Do not try to disassemble or modify the charger.
- Page 10 •Do not use headset while driving, riding a bike or walking on the road in case of any traffic accident. •Keep the headset in a safe place out of the reach of children to avoid any danger.
-
Page 11: Installation And Charging
2. Installation and charging 2.1 Install battery Follow the steps below to install battery: Align the battery metal contact with the battery compartment metal contact in order from left to right, as shown in the figure below. Insert battery into the battery compartment in the direction of arrow as shown in the figure below;... -
Page 12: Charge Battery
Note: Before removing the battery, make sure your phone is powered off and external power supply is removed. Never remove the battery when your phone is powered on. Otherwise, SIM card and your phone may be damaged. 2.3 Charge battery Press the charger interface and insert the charger into the charging port of the mobile phone as indicated below: Note: Operate carefully. -
Page 13: Install Sim Card
• Do not remove the battery or SIM card while the battery is being charged. • If the battery runs out of power, the phone will be powered off automatically. 2.4 Install SIM card The metal contact surface of the SIM card scratches easily. So before assembly, it must be taken out cautiously. - Page 14 Your S62 phone supports a multifunctional memory card in T-FLASH (Micro SD) format. You can store videos, photos, pictures, MP3, audio clips and other files on the memory card. Sketch map of SD card installation direction Install and remove memory card Follow the steps below to install memory card: Note: Be careful when installing the memory card.
-
Page 15: Power On/Off
As shown in the figure, remove the phone battery cover and battery, lift the SD card holder, put SD card into the card holder in the direction of arrow, and then buckle the SD card holder to complete the installation of SD card. -
Page 16: Puk Code
PIN code is used to prevent your SIM card from illegal use. If the PIN code protection function is activated, the screen will display the prompt for entering PIN code. If wrong PIN codes are entered for three times in succession, the SIM card will be automatically locked. You must enter PUK code to unlock the SIM card. -
Page 17: Mobile Phone Parts Drawing And Key Functions
3. Mobile Phone Parts Drawing and Key Functions 3.1 Key Description Description [Dail Make or answer a call. Press this key in standby state to key] enter the call log of dialed numbers. End a call. [End Press and hold this key to power on or power off the key] mobile phone. - Page 18 In the standby state, press and hold the key to input a special dial character "+"(the international access code). In the standby state, press and hold the key to deactivate the mute mode, with only vibration prompt enabled. In the editing state, press the key to switch the input method.
-
Page 19: Icon
3. Press [Up navigation key]: enter Calendar in standby state. 4. Press [Down navigation key]: enter the contact list of Phonebook in standby state. 5. Press [OK key]: enter main menu in standby state 3.2 Icon <Icons on the screen > Icon Description Location... - Page 20 There is currently limited phone Icon Area record Music background play Icon Area...
-
Page 21: Main Function Guide
4. Main Function Guide 4.1 Download of MP3 music Your phone supports MP3 music playback, and you can download MP3 music by: 1. connecting to the Internet; 2. connecting to the computer using USB; or 3. receiving MP3 music via Bluetooth. 4.2 Camera You can enter the camera interface from [Entertainment]/[Camera]. -
Page 22: Serial Port
2. When files stored on your phone become abnormal, select memory card formatting. 3. When the phone is powered on and the USB function is activated, USB related functional modules of the phone cannot not be used. 4.3.2 Serial port Your phone supports PC synchronization. -
Page 23: Dial An Extension Of A Fixed Phone
4.4.2 Dial an extension of a fixed phone Some fixed phones can not be put through directly. You need to enter the exchange number first, followed by * key until “P” or “W” appears on the screen, and then enter the extension number. You can dial an extension of a fixed phone by entering the following in series: area code exchange number... -
Page 24: Dial An Emergency Number
4.5 Dial an emergency number Within the coverage of the network (as indicated by the signal strength bar on the upper left corner of the screen of your phone), you can make an emergency call, even if you do not have a SIM card. If your network provider does not provide roaming service in the area, the screen will display “Out of Service”. -
Page 25: Text Input
5. Text input The phone provides the following input methods: smart English, phonetic, smart Pinyin, strokes, English (uppercase and lowercase), and number input. The following input functions are enabled in the phone: Input and edit text messages Input and edit the names in phonebook Edit the text in multimedia messages …... - Page 26 database, so that the correct character can be selected. UPPERCASE OR LOWERCASE LETTERS INPUT Each key is used to enter multiple characters. Press the key repeatedly and quickly until the character you want appears. Number input Press the key corresponding to the number to be entered. Spanish input Press related keys and select the suitable one in the text area.
-
Page 27: Function List
6. Function list 1 Call log 5-7 Bussiness 1-1 Missed calls 5-8 Classmates 1-2 Recieved calls 1-3 Dialed calls 6 Message service 1-4 Rejected calls. 6-1 Write message 1-5 Delete call logs 6-2 Inbox 1-6 Data center 6-3 Sent 1-7 Generate Monthly Call Log 6-4 Outbox 6-5 Drafts 2 Movistar... - Page 28 8-2 Bookmarks 9-4 Call setup 8-3 Recent pages 9-5 Dedicated key 8-4 Input address 9-6 Security setup 8-5 Settings 9-7 Connect Setup 9-8 Games settings 9 Settings 9-9 Java settings 9-1 Profiles 9-10 Restore factory settings 9-2 Display Charicteristics 9-3 Phone setup Note: SIM card tool kit is the added-value SIM card service menu.
-
Page 29: Quick Function Reference
7. Quick Function Reference This chapter briefly describes functions of the mobile phone. Function Description Options Check Check recently dialed, Main Menu-Call Log-missed, recent call answered, missed and answered calls, dialed calls, rejected calls rejected calls Delete all records, Delete Call delete dialed, Main Menu-Call Log-Delete all answered, missed and... - Page 30 Main Menu-Message Save commonly used Service-Templates-commonly short messages and Message used short messages；Main multimedia messages template Menu-Message to be used when Service-Templates-commonly editing messages used multimedia messages Main Menu-Message Service-Capacity Query- SMS Message Check message statistics; Main Menu-Message capacity capacity status in the Service-Capacity Query- MMS status SIM card and phone...
- Page 31 keypad tone Select the prompt tone Main Menu-User Prompt when a specific event profiles-Options-Custom-Ringtone tone occurs. setting-Prompt Tone Set up passwords to Main Menu- Settings –security Security protect the phone from setup being used without setup authorization Restore some phone settings to factory Restore Main Menu- Settings - Restore...
-
Page 32: Troubleshooting
Please refer to the list below if you encounter any problems when using your phone. If you tried but the problem has not been solved, contact a qualified Lenovo dealer or your local maintenance provider immediately. Your display prompts Enter PIN Code: Enter the valid PIN code for your SIM card. - Page 33 There are three possible reasons for this. First, the charger does not function normally. In that case, you should contact the nearby maintenance center or dealer designated by Lenovo. Second, the working environment or temperature is not appropriate to the charger, and you can change the charging environment.
- Page 34 ■Some functions can’t be selected: The related service is not in use or the local network service provider doesn’t support such service. Please contact with Lenovo’s designated maintenance center, dealer or your network service provider.
- Page 35 9. Technical Parameters Standard Product: GSM dual band digital mobile phone with GPRS features Model: S62 System: GSM 900/DCS 1800 Operating Temperature Highest: +55 °C Lowest: -10 °C Basic Parameters Dimensions (Length x Width x Thickness): about 94.5 x 47.6 x 19.5 (mm) Weight: about 94.3g (including battery)
- Page 36 Appendix: 1. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 37 While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for RF exposure. For body-worn operation, the phone meets FCC RF exposure guidelines provided that it is used with a non-metallic accessory with the handset at least 1.5 cm from the body.
