Summary of Contents for Matrix Orbital EVE2
- Page 1 EVE2 TFT Module Hardware Manual Revision 1.2...
-
Page 2: Revision History
Revision Date Description Author October 23 , 2017 Corrected bezel information in section 2.1. Added additional Divino header information October 10 , 2017 Added link to FTDI Programmers Guide Divino August 3 , 2017 Initial Release Divino EVE2 TFT Module... -
Page 3: Table Of Contents
6.3 Digital I/O Pin Characteristics ............................9 6.4 Touch Sense Characteristics.............................. 9 7 Ordering Options ..................................10 7.1 Matrix Orbital Eve 2 series displays ..........................10 7.2 Matrix Orbital Product Line Comparison ........................10 7.3 Software Support ................................11 7.4 EVE2 Module Displays ..............................11 8 Dimensional Drawing................................. -
Page 4: Introduction
1 Introduction The Matrix Orbital EVE lineup utilizes FTDI’s second generation Embedded Video Engine to control, render, manage and display complex graphics on a full color TFT touch screen. By taking advantage of the 1 megabyte of graphics RAM, motion-JPEG encoded AVI videos can be played back in both portrait and landscape mode. Data can be displayed through a set of widgets such as gauges, spinners, sliders, and bar graphs. -
Page 5: Ftdi Eve Chip
Figure 2: EVE 2 Embedded Video Engine More details regarding the EVE2 hardware specs can be found in the FTDI FT81x Datasheet, available online. An FTDI EVE2 programming guide, titled “FT81x Series Programming Guide”, is also available and can be downloaded at FTDI/Bridgetek’s website http://www.brtchip.com/ft81x... -
Page 6: Eve2 Headers
3.1 Communication Header Pinout The 20 pin FFC header on the EVE2 TFT Module is used to interface with an SPI controller, and is compatible with a number of 20 pin ribbon cables. Any 20 pin FFC cable with a 0.5mm pitch and bottom contacts, such as the Wurth Electronics INC 687620050002 series ribbon cable will be compatible with the EVE2 module. -
Page 7: Communication Model
SPI clock Period (QUAD mode) Tsclkl SPI clock low duration Tsclkh SPI clock high duration Tsac SPI access time Tisu Input Setup Input hold Output enable delay Output disable delay Output data delay Tcsnh CSN hold time EVE2 TFT Module... -
Page 8: Spi And Qspi Communication
5.2 SPI and QSPI communication The EVE2 TFT Module is capable of communicating to hosts and microcontrollers through a quad serial parallel interface (QSPI). Only SPI mode 0 is supported. The QSPI slave interface can operate up to 30MHZ, and can be configured in SINGLE, DUAL or QUAD channel modes. -
Page 9: Serial Data Protocol
For SPI memory write transactions, a ‘1’ bit and ‘0’ bit is sent by the host, followed by the 22-bit address. The write data follows. Table 6: SPI Memory write transaction Address [21:16] Write Address [15:8] Address Address [7:0] Dummy byte Byte 0 Read Address Byte n EVE2 TFT Module... -
Page 10: Electrical Characteristics
6 Electrical Characteristics 6.1 Absolute Maximum Ratings Table 7: EVE2 Module Limiting Values Item Value Unit Storage Temperature -30 to 80 °C Ambient Temperature (Power Applied) -20 to +70 °C VCC Supply Voltage 0 to +4 DC Input Voltage -0.5 to + (VCCIO + 0.3) 6.2 DC Characteristics... -
Page 11: Ordering Options
7.1 Matrix Orbital Eve 2 series displays The EVE2 TFT Module has multiple size and touch variants, to ensure that there is an option for every application. Resistive touch panels are also available, allowing interactive touch functionality for all applications. -
Page 12: Software Support
Device Inspector 7.4 EVE2 Module Displays The EVE2 Module is paired with a Matrix Orbital Parallel TFT display. Information about Matrix Orbital’s Parallel TFT lineup, including drawings, dimensions, and tolerances can be found online at: https://www.matrixorbital.ca/manuals/parallel-display/mop-tft-manual EVE2 TFT Module... -
Page 13: Dimensional Drawing
Dimensional Drawing Figure 10: EVE2 TFT Module Technical Drawing EVE2 TFT Module... -
Page 14: Eve2 Tft Module Schematic
9 EVE2 TFT Module Schematic Figure 11: EVE2 TFT Module Schematic 10 Contact Sales Support Online Phone: 403.229.2737 Phone: 403.204.3750 Purchasing: www.matrixorbital.com Email: sales@matrixorbital.ca Email: support@matrixorbital.ca Support: www.matrixorbital.ca EVE2 TFT Module... - Page 15 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Matrix Orbital EVE2-70A-BLM-TPN EVE2-43A-BLM-TPN EVE2-29A-BLM-TPN EVE2-43A-BLM-TPR EVE2-38A-BLH-TPR EVE2- 50A-BLM-TPR EVE2-70A-BLM-TPR EVE2-50A-BLM-TPN EVE2-35A-BLM-TPN EVE2-35A-BLM-TPR...
