Clifton

THE

RANGE

Ultrasonic Baths

SW Series

Table of Contents

Need help?

Do you have a question about the SW 30 H and is the answer not in the manual?

Questions and answers

Summary of Contents for Clifton SW 30 H

Page 2: Table Of Contents
Contents 1. Safety Warnings 2. Product Features 3. Delivery Volume 4. Technical Details 5. CE Conformity 6. Unit Description 7. Initial Operation/Putting Into Operation 8. Operation 9. Cleaning Process 10. Maintenance/Care/Repair 11. Putting Out of Operation 12. Portable Appliance Testing 13.
Page 3: Safety Warnings
1. Safety warnings Carefully read the safety warnings before you operate the unit. The ultrasonic bath has been designed for treating items in liquids only. The unit must be operated by instructed staff; observe and follow the operating instructions. Risk of electrocution! Connect the unit to a grounded shock proof socket only! Do not open the unit! For operation place the unit on a dry and stable work surface.
Page 4: Product Features
2. Product features ■ Transducer tank made of cavitation-proof stainless steel. ■ Housing made of stainless steel, easy to keep hygienically clean. ■ Sandwich performance transducer systems. ■ Sweep function for the perfect sound field distribution in the cleaning liquid. ■...
Page 5: Technical Details
W x D x H W x D x H W x D x H (approx. mm) (approx. mm) (approx. mm) SW 12 H 12.75 300x240x200 365x278x321 250x190x115 SW 30 H 28.00 20.6 505x300x200 568x340x321 455x250x115 11.0 SW 45 H 45.00 35.0 500x300x300...
Page 6: Unit Description
6. Unit description Operating panel for controlling the unit functions Transducer tank Plastic carrying handles for the safe transportation of the unit Turning drain dial allows liquid emptying from the tank. Indicators show position when drain is shut and open Temperature Temperature range 30°...
Page 7: Initial Operation/Putting Into Operation
7. Initial operation / Putting into operation 7.1. How to fit the drain tube 1. Unscrew the closing plug (A); turn anti-clockwise. 2. Screw the supplied tube socket (B) clockwise 3. Connect ½“ bore tube of required length, not included. Fasten the tube with hose clip.
Page 8: Operation
8. Operation Intended action What to do Result Unit switch on / off Press on/off (I) key. Unit is ready for operation / unit is switched off. Start ultrasonics – no heating Set required cleaning time, turning dial for desired Ultrasonic activity starts.
Page 9: Cleaning Process
9. Cleaning Process Observe general laboratory safety warnings! Ultrasonic activity can damage sensitive surfaces over prolonged periods. If necessary for the cleaning task at hand, pre-heat the liquid (in units with heating). When the cleaning liquid has been freshly mixed switch on the Degas / Auto-Degas function for degassing the liquid (approx. 10 min). Immerse the cleaning items into the cleaning liquid.
Page 10: Portable Appliance Testing
When testing, ensure testing is conduced by a qualified person. 13. Warranty Our service engineers are fully trained in the assembly, calibration and servicing of all Clifton instrumentation.Products can be returned to our comprehensively equipped service centre where a fast and efficient turnaround is guaranteed: Service Department, Nickel Electro Limited, Oldmixon Crescent, Weston-super-Mare, North Somerset BS24 9BL, UK.
Page 11: Accessories - Lids And Baskets
15. Accessories LD-12 Flat One Piece Moulded Plastic Lid to suit 12 Litre Capacity Bath LD-30 Flat One Piece Moulded Plastic Lid to suit 30 Litre Capacity Bath LD-45 Flat One Piece Stainless steel Lid to suit 45 Litre Capacity Bath LD-90 Flat One Piece Stainless steel Lid to suit 90 Litre Capacity Bath BSK-12...
Page 12: Accesories - Fluids
SW-C L1 Acid foam-inhibited cleaning concentrate Removes aqueous cooling emulsions after mechanical treatment, light mineral greases and oils, fingerprints, dust as well as deposited calcinations. Suitable for all surfaces made of metal (including aluminium & aluminium alloys), glass, ceramic and plastic materials. 2.5 litres. SW-C L2 Neutral foam-inhibited cleaning concentrate Removes grease and oil, fingerprints and dust as well as deposited lime soaps.
Page 13: Spares
16. Spares 100 086 Control PCB for SW30H 100 587 Control PCB for SW45H 100 059 Fuse for Control PCB 100 171 RFI Filter PCB 100 200 Fuse T15A for RFI Filter © Nickel-Electro Ltd.
Page 14: Declaration Of Conformity
North Somerset BS24 9BL United Kingdom Tel: +44 1934 626691 Fax +44 1934 630300 Email: Clifton@nickel-electro.co.uk www.nickel-electro.co.uk Conforms with the requirements of the following standards: BS EN 61010:1 BS EN 61010:2.010 Safety requirements for electrical equipment for measurement, control and laboratory use BS EN 61326 Electrical equipment for measurement control and laboratory use –...

This manual is also suitable for:

Sw 90 h Sw 12 h Sw 45 h
