Introduction
BlueBeacon Gateway is a BLE-beacon gateway with BLE and LAN/WLAN interfaces that
allows to communicate with BLE beacons (new software manages both scanning for
generic BLE beacons and connecting to BlueBeacon beacons).
BlueBeacon Gateway is offered in two alternative versions:
BlueBeacon Gateway D for desktop applications;
BlueBeacon Gateway W for wall installations.
BlueBeacon Gateway D is provided in a plastic enclosure suitable for desktop applications
(optional mounting kit is available). It is available in one version:
- D/A00: with integrated omnidirectional BLE antenna.
BlueBeacon Gateway W is provided in an elegant plastic enclosure suitable for wall or
ceiling installation. It is available in three versions:
- W/A00: with integrated omnidirectional BLE antenna;
- W/A05: with internal 5dB-directive BLE antenna;
- W/SMA: with SMA connector for external BLE antenna.
Possible applications with BlueBeacon Gateway are:
- remote monitoring and management of beacons;
- localization of BLE beacons (tags) for RTLS and access control;
- distributed monitoring systems of environmental parameters, using BlueBeacon Sensor
(with temperature, humidity and pressure sensors);
Before you start using a BlueBeacon Gateway, verify that it is undamaged and carefully
read the instructions in this user manual, particularly the indications in the "Safety" section.
BlueUp S.r.l.s. disclaims any and all liability if the devices are used in modes and
environments incompatible for keeping the product's intact, safe and in operation.
BlueUp S.r.l.s. - 2018
BlueBeacon Gateway

User manual

V1.0– 26/06/2018
Loc. Belvedere, Ingresso 2, 53034 Colle di Val d'Elsa (SI) - ITALY
E-mail: info@blueupbeacons.com, Web: www.blueupbeacons.com
BlueUp S.r.l.s.
Ph. 347 4123206, Fax 0577 043101
VAT N. IT 01373980521
1/28

Advertisement

loading
Need help?

Need help?

Do you have a question about the BlueBeacon Gateway W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BlueUp BlueBeacon Gateway W

  • Page 1: User Manual

    (optional mounting kit is available). It is available in one version: - D/A00: with integrated omnidirectional BLE antenna. BlueBeacon Gateway W is provided in an elegant plastic enclosure suitable for wall or ceiling installation. It is available in three versions: - W/A00: with integrated omnidirectional BLE antenna;...
  • Page 2: Technical Characteristics

    Ver. D: 100 x 73 x 30 mm Ver. W: 120 x 120 x 45 mm (excluding flanges) Mounting kit: Ver. D: none Ver. W: wall-mounting plastic flange IP protection: IP40 Operating temperature: -20°C to +60°C BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 2/28...
  • Page 3: Waste Disposal

    Warnings BlueBeacon Gateway W must be intended for use for which it was designed. Any other use is considered improper and therefore dangerous. Before you start using BlueBeacon Gateway W, verify that it is undamaged.
  • Page 4 The information contained herein has been provided by sources that BlueUp S.r.l.s. considers to be dependable and is accurate to the best knowledge of the company. This sheet is not intended to be an inclusive document on worldwide hazard communication regulations.
  • Page 5: Device Connection And Setup

    At the end of the procedure, BlueBeacon Gateway will automatically reboot and the green LED will flash again indicating the correct execution of the software on board. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 5/28...
  • Page 6 Figure 1 shows an example of identifying the IP address assigned to the BlueBeacon Gateway by a SpeedTouch router.As you can see, BlueBeacon Gateway is identified by its hostname which consists of the string BBGW-CPU_SERIAL_NUMBER. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 6/28...
  • Page 7 At this point, the login screen will appear on the browser (Figure 3). Figure 3: Login sireen of the BlueBecion Gctewcy cdministrction interfcie. The default password to be used at the first start is blueup. Once logged in, you will be redirected to the index page of the BlueBeacon Gateway administration interface.
  • Page 8 At the top you can view the topbar, where in the top right menu you have access to the features of: • Reboot , restart of BlueBeacon Gateway • Shutdown , shutdown of BlueBeacon Gateway • Logout from the administration interface BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 8/28...
  • Page 9 Figure 4: BlueBecion Gctewcy homepcge. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 9/28...
  • Page 10 Login Password : allows you to change the password for accessing the BlueBeacon Gateway administration interface • Firmware Upgrade : allows you to upgrade the software developed by BlueUp (requires the upload of the software package released by BlueUp) Administrative interface: Network Settings The Network Settings tab displays and allows you to configure the BlueBeacon Gateway network interfaces (Ethernet and WiFi) (Figure 6).
  • Page 11 At the next restart, you can verify that the new network settings have been correctly applied also through the System Info page, in the Network Interfaces section (Figure 7). Figure 5: System Info BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 11/28...
  • Page 12 Figure 6: Network Settings, ionfgurction interfcie for the BlueBecion Gctewcy network interfcies. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 12/28...
  • Page 13 Figure 7: Network Interfcies, displcying the ionfgurction in use for the network interfcies. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 13/28...
  • Page 14 Administration interface: BlueBeacon Cloud The BlueBeacon Cloud tab allows you to manage the BlueBeacon Gateway connection with the BlueUp BlueBeacon Cloud backend system. If you have an account on the BlueBeacon Cloud system, you can authorize BlueBeacon Gateway to monitor and synchronize your registered beacons on the BlueBeacon Cloud.
  • Page 15 Figure 8: User iredenticls input interfcie to login on BlueBecion Cloud bcikend. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 15/28...
  • Page 16 Figurc 9: Interfcie to visuclize cnd ionfgure the becion synihronizction system with the BlueBecion Cloud bcikend. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 16/28...
  • Page 17 Quuppa : shows all the beacons that transmit packets in Quuppa format • Sensor : shows all the beacons that transmit packets in BlueUp Sensor format The Settings menu, on the other hand, allows you to configure some values related to the reception of the beacon: •...
  • Page 18 FrameTimeout is lower than the beacon's advertising interval, there will be continuous oscillations (insertions / removals) of the frames transmitted by the beacon. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 18/28...
  • Page 19 Data sent in HTTP POST from BlueBeacon Gateway: "gateway": "00000000087569a7", "beacons": [ "bdaddr": "e0:37:a2:3d:bb:08", "timestamp": "2018-04-16 12:19:46.914 GMT+0200 (CEST)", "rssi": -62, "connectable": true, "ibeacon": [ "rssi": -65, "uuid": "acfd065ec3c011e39bbe1a514932ac01", "major": 0, "minor": 18000, "measuredPower": -62, "timestamp": "2018-04-16 12:19:49.57 GMT+0200 (CEST)" BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 19/28...
  • Page 20 The one-time password for the HMAC-SHA256 algorithm is computed as the SHA256 hash of the concatenation of: otk = SHA256(gateway || password || timestamp) The signature is calculated as: signature = HMAC-SHA256(JSON.stringify(beacons), OTK) Figure 10: HTTP icllbcik ionfgurction interfcie. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 20/28...
  • Page 21 (Eddystone, iBeacon, Quuppa ...), in the Averaged mode, only the beacons in iBeacon format will be considered. In Figure 11 and 12 it is possible to see two examples of Real-Time and Averaged plots, respectively. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 21/28...
  • Page 22 Figure 10: HTTP icllbcik ionfgurction interfcie. Figure 11: Excmple of Recl-Time plot with fltering on iBecion. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 22/28...
  • Page 23 Figure 12: Excmple of Avercged plot with vcrious becions. BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 23/28...
  • Page 24 Eddystone-UID format with NamespaceId equal to the one specified • http://gateway-ip/api/beacons/eddystone/uid/ namespace instance Returns a JSON containing the data related to all the beacons that transmit packages in Eddystone-UID format with NamespaceId and InstanceId equal to those specified BlueUp S.r.l.s. - 2018 V1.0– 26/06/2018 24/28...
  • Page 25 BlueUp format with Model Number equal to the one specified • http://gateway-ip/api/beacons/blueup/ model serial Returns a JSON containing the data related to all the beacons that transmit packages in BlueUp format with Model and Serial Number equal to those specified • http://gateway-ip/api/beacons/blueup/ model serial /status...
  • Page 26 POST http://gateway-ip/api/beacons/blueup/ model serial /configuration/ read ◦ BODY "unlock" : "md5-of your-beacon-password" Used for reading the GATT of a BlueUp beacon. • Returns a JSON containing the data related to the read-task scheduled on the beacon. • POST http://gateway-ip/api/beacons/blueup/ model...
  • Page 27 "unset" : true "index" : 3, "unset" : true Used for writing the GATT of a BlueUp beacon. Returns a JSON containing the data related to the write-task scheduled on the beacon or an error in case of invalid parameters.
  • Page 28: Warranty

    BlueUp S.r.l.s. may, at its sole discretion, replace the defective product or have it repaired. The costs for shipping the product to BlueUp S.r.l.s. shall be borne by the buyer. In case of an effective detection of defeccts of conformity and / or manufacturing defects the cost of shipping the product are borne by BlueUp S.r.l.s..
