- Page 1 Processor 8ASI / DVB-T RF User’s Manual Processor 8ASI / DVB-S2 (S) RF CAS ID 4AEC User's Manual...
-
Page 2: Table Of Contents
Processor 8ASI / DVB-S2(S) RF User’s Manual Overview Construction Front Panel Rear Panel Main features Specification Connections IP Out Operation Common information The System Installation How to add the new Processor to the System Server PC network parameters settings DVCrypt SW operation he new Processor Installation RF Output settings The Output Stream forming... -
Page 3: Overview
Processor 8ASI / DVB-T RF User’s Manual Overview The 8ASI DVB-S2 (S) Processor is a multifunction device intended for multichannel DVB- S2 (S) broadcasting. It provides TS re-multiplexing, scrambling, modulating and Up-con- verting. · The processor re-multiplexes up to 8 input Transport Streams(TS) and forms a spectrum in the DVB-S2(S) format transmitted at Radio frequency. -
Page 4: Construction
Processor 8ASI / DVB-S2(S) RF User’s Manual Construction The processor has a monblocking design –19`` REC mounted 1U Contains the main board with the input and output connectors, power supply. Front panel The front panel Indicators: Power Power Indicator LED LED Indicator Indicator `s control button INPUTS 1-8. -
Page 5: Rear Panel
Processor 8ASI / DVB-T RF User’s Manual Rear Panel In 1 – In 8 ASI inputs i Out, Out 2 - 2 ASI outputs RF Out. Radio Frequency output ETHERNET / IP Output RJ45 connector Ground pole AC 220V Fuse... -
Page 6: Main Features
Processor 8ASI / DVB-S2(S) RF User’s Manual Main features 8 ASI Inputs re multiplexing Modes: DVB-S or DVB-S2 Output modulation QPSK or 8PSK Software update/upgrade. DVCrypt CAS support. EPG, OTA, LCN support, Network Search. ... -
Page 7: Specification
Processor 8ASI / DVB-T RF User’s Manual Specification INPUT INTERFACE ASI Inputs 8 DVB ASI streams, 8 BNC Connectors ASI OUTPUTS 2 DVB ASI, 2 port, 2 BNC Connectors 2 DVB-ASI Outputs RF Output Connector F-type Frequency range: 70-1700 MHz (adjustable) Output RF signal level 80-100 dB/uV, adjustment -10dB/uV;... -
Page 8: Connections
Processor 8ASI / DVB-S2(S) RF User’s Manual Connections AC In 220В 50Hz+ Fuse Grounding Terminal When connecting this unit to any other component, make sure that it is properly grounded by connecting this terminal to an appropriate point. When connecting, use the socket and be sure to use wire with a cross-sectional area of at least 1.0 mm. -
Page 9: Operation Common Information
Processor 8ASI / DVB-T RF User’s Manual Operation common information Processor must be connected to the PC for the settings, control and Update and Upgrade. (The rear panel RJ45 connector) The Processors have built-in system time synchronization. The control computer is synchronized from the source time signal and in turn synchronizes the Processor. -
Page 10: The System Installation
Processor 8ASI / DVB-S2(S) RF User’s Manual The System Installation. To obtain a workable system, it is necessary: Operating System: Windows XP, or Windows server 2003/2008. DVCrypt program HUB/switch for local area computer networks - for simultaneous connection of all the Processors to a single computer. -
Page 11: Server Pc Network Parameters Settings
Processor 8ASI / DVB-T RF User’s Manual Server PC network parameters settings. Server PC requirements: please check that following requirements are met: CPU: 1 GHz or faster; RAM: 1 GB or more; HDD: at least 1 GB of free space; LAN adapter and/or USB for modules interface;... - Page 12 Processor 8ASI / DVB-S2(S) RF User’s Manual Wiring diagram is as follows: If you need to have the Server with the other Computer in the network, we recommended to use the other diagram, in order to provide reliable communication with the Processor and additional security:...
-
Page 13: Dvcrypt Sw Operation
Processor 8ASI / DVB-T RF User’s Manual DVCrypt SW operation Software installation Simply run the included DVCrypt_Install.exe installation file and follow the prompts. Starting the Control Program The Control Program is started from the Start menu. / All Programs / DVCrypt / Control Program When you start the program will require to choose the type of connection: Locally, if the program Server installed on the same computer, or to a server, if it is in-... - Page 14 Processor 8ASI / DVB-S2(S) RF User’s Manual Administrator is enters to the program as an “administrator” with personal password and appoints the other users. The administrator also can on / off some of the functions of the program DVCrypt, necessary for the user. The number of users and their rights determined by the administrator.
- Page 15 Processor 8ASI / DVB-T RF User’s Manual...
-
Page 16: He New Processor Installation
Processor 8ASI / DVB-S2(S) RF User’s Manual The new Processor Installation 1) Connect the new Processor to the HUB (RJ 45-RJ 45 cable) and HUB to the Server-PC. (see page 15) 2) Turn on the Processor power. 3) In the DVCRypt Client Window (see page 17) left click icon the DVCRypt Client -Modules window will opened. - Page 17 Processor 8ASI / DVB-T RF User’s Manual Click “Next” and follow the wizard prompts NOTE! New Device connected to the system will be searched, their MAC and IP addresses will be listed. Search can be repeated by pressing Refresh button. If there are a few Devices, it is difficult to determine the Device among others.
- Page 18 Processor 8ASI / DVB-S2(S) RF User’s Manual The server will set the IP address for the new processor and add it to the system: The IP address and MAC will be shown in Devices window in Control Software. It will be impossible to change the Device IP address hereafter.
- Page 19 Processor 8ASI / DVB-T RF User’s Manual After adding the Device it should be set. Double click on the Device number and it will ap- pear Converter setting window, Notes If the distance between the Server and Devices is rather long and there are routers, and automatic search doesn't work - in this case it is necessary to do the following: Connect the new Device to the local network or to the Server directly and set the IP ad- dress as described above.
- Page 20 Processor 8ASI / DVB-S2(S) RF User’s Manual The server will try to communicate with the Device and add it to the system:...
- Page 21 Processor 8ASI / DVB-T RF User’s Manual Attention! All Devices are delivered set to the IP address 192.168.0.254 or 192.168.0.253, network mask 255.255.255.0. The Devices should have different IP addresses when you add them to the system. The delivery set includes EthernetSetup.exe utility which makes it possible to change Device IP address and network mask.
- Page 22 Processor 8ASI / DVB-S2(S) RF User’s Manual Settings 1. Power on Processor 2. Run DVCrypt Program 3. Add Processor to System (Page__) 4. On the Instruments Panel click icon 12 (Run setup Utility) The settings window is appear: Modulation is selected by radio buttons “CAM”. The modulation by default is CAM 64 Frequency tuning is set by slider “MHz”...
- Page 23 Processor 8ASI / DVB-T RF User’s Manual Caution. The Processor Settings can be loaded to device after you click the "Set your settings"only. This can be done both after the all settings is finished or each of setting -separately.
-
Page 24: The Output Stream Forming
Processor 8ASI / DVB-S2(S) RF User’s Manual The Output Stream forming The Output Stream is forming in the DVB_Service utility (the part of DVCrypt) 1) Click the icon 2) Drag the program you need from the left side to the right, into the selected package. 3) Check the output stream you will have –... - Page 25 Processor 8ASI / DVB-T RF User’s Manual CAS settings To enable the conditional access system for the selected channels in the main window: double click the Processor number – The Condition Access settings window will appear:...
-
Page 26: Ip Outputs Settings
Processor 8ASI / DVB-S2(S) RF User’s Manual IP Outputs Settings Click icon «IP» on the tool-bar IP output configuration window appears where you must to set: 1. Protocol (RTP, UDP, RTP +) 2. Port 3. IP address the stream will be broadcast to, 4. - Page 27 Processor 8ASI / DVB-T RF User’s Manual After selecting the required parameters you should click "start" and close the window. It is possible to check (monitor) work of IP inputs using VLC player. Select Media / Network and enter the necessary parameters. An example is given on Fig- ure below.
-
Page 28: Warranty
Processor 8ASI / DVB-S2(S) RF User’s Manual Warranty Warranty period – 24 months from the selling date The manufacturer does not take any responsibility for defects occurred at the customer’s fault or trading company’s during careless transportation, improper storage, technical serv- ice or usage, mechanical damages, violating the operation rules.
