- Page 1 Source Mix IR IR volume control user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 27.06.2018, ID: 427362...
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 7 Safety instructions............................. 8 Features............................... 10 Installation and starting up........................ 11 Connections and controls........................13 Technical specifications........................16 Plug and connection assignment.................... -
Page 4: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 5: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. -
Page 7: Symbols And Signal Words
General information 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. -
Page 8: Safety Instructions
Safety instructions Safety instructions Intended use This device is used to adjust the volume of audio signals with line level. Use the device only as described in this user manual. Any other use or use under other operating conditions is consid- ered to be improper and may result in personal injury or property damage. - Page 9 Safety instructions NOTICE! External power supply The device is powered by an external power supply. Before connecting the external power supply, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual cur- rent circuit breaker.
-
Page 10: Features
Features Features Stereo volume control for line level audio devices. RCA in and outputs Plug-in power supply and infrared remote control included Robust metal housing IR volume control... -
Page 11: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 12 Installation and starting up Inserting the battery into the Press the lock of the battery holder to the centre of the housing and pull out the battery holder remote control like a drawer. Insert the battery. The battery is correct if the positive pole points to the housing base of the remote control.
-
Page 13: Connections And Controls
Connections and controls Connections and controls Source Mix IR... - Page 14 Connections and controls 1 [MUTE] The LED indicates that the output is muted. 2 [IR] Infrared sensor for the remote control signals. 3 [POWER] The LED indicates that the device is connected to the power grid. 4 [INPUT] RCA sockets as signal inputs for left and right stereo channels 5 [OUTPUT] RCA sockets as signal outputs for left and right stereo channels 6 [DC 12V]...
- Page 15 Connections and controls Remote control 7 [MUTE] Mutes or unmutes the output 8 [VOL+], [VOL–] Buttons for increasing / decreasing the volume. Source Mix IR...
-
Page 16: Technical Specifications
Technical specifications Technical specifications Voltage supply Plug-in power supply (12 V / 150 mA ), positive pole via inner contact Input level max. 1,65 V Input impedance 47 kΩ Output level max. 2 V Frequency range 20 Hz…20 kHz Signal-to-noise ratio >... -
Page 17: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip- ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... -
Page 18: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate- rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose these materials with your normal household waste, but make sure that they are fed to a recovery. - Page 19 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose this device through an approved waste disposal firm or through your local waste facility.
- Page 20 Notes IR volume control...
- Page 21 Notes Source Mix IR...
- Page 22 Notes IR volume control...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
