GMW DPM 24x96-2000 S Operating Manual

Digital Panel Meter
The DPM 24x96-2000 S are digital panel instruments for measurement of current DC and voltage DC with 9 measuring
ranges. 3 ranges for power supply are available.
Service:
The measuring ranges and zero point selectable using jumpers at the back. The choise of many factory pre-set measuring
ranges is included, with user adjustments available for the zero and full scale values.
Technical data:
Display
Measuring ranges
Digital input
Options
Power supply
Environmental conditions
Dimensions and weights
Sundry

Operating Manual

Display range
Decimal point position
Negative display indication
Digit height
Overload indication
Setting time
Direct current
(Voltage drop < 600 mV)
Direct voltage
(input current < 300 µA)
Range adjustment span
Zero offset (suppression)
Accuracy
Temperature coefficient
HOLD (option)
Brightness adjustment
Zero point adjustment
Hold input
Direct voltage DC
common mode voltage
Alternating voltage AC
(47 - 60 Hz)
Climatic class
Operating temperature
Storage temperature
Safety class
Protection class
front
Device safety
EMC immunity
EMC radiated interference
Front frame
Panel cut-out
Overall depth
Weight
Connections
DPM 24x96 - 2000 S
1999
selectable
„-"
14 mm / 7 segment digits
last 3 digits blank
< 1 s (0 ... 99 %)
0 ... 1 mA
0 ... 20 mA
0 ... 200 mA
0 ... 0.2 V (1 V)
0 ... 1 V (5 V)
0 ... 5 V (25 V)
0 ... 25 V (100 V)
0 ... 100 V (300 V)
0 ... 300 V
from 20 % to 100 %
up to -1000
< 0,2 %+ 1 digit
100 ppm / K
plus 100 ppm / K zero point drift
„0"
5 V ±5 % max. 0,6 W not isolated
-0,5 V ... 1,5 V max.
21 ... 30 V ±15 % 4,0 W approx.
230 V +10 %, -15 % 1,3 W approx.
Class 2 to VDE / DIN 3540
0 ... 50 °C
-40 °C ... +80 °C
II to IEC 348 / VDE 0411
IP 20 to IEC EN 60 529
IP 54 (IP 65 on request)
corresp. IEC EN 61 010
corresp. DIN EN 61 000-4-1 to 4
corresp. DIN EN 50 081 class B
24 mm x 96 mm to DIN 43 718
22,2 +0,3 mm x 92 +0,8 mm
72 mm
approx. 90 g (210 g if power supply >5 V DC)
Plug-in screw terminal blocks
