Oxford PRECISION OXD-331 IDM Operator's Manual

OXD-331-6010K_6020K_Instruction.qxd
Battery Replacement
Remove the battery compartment lid and replace one SR44 with its positive(+) side facing upward.
Batteries
SR44B Silver Oxide Battery (Pack 1)
Troubleshooting
Failure Five digits appear simultaneously and change rapidly
Possible Cause Battery Power Low
Solutions Remove battery compartment lid and replace battery
Failure The display does not work after changing battery
Possible Cause Circuit accidentally broken by poor voltage when changing battery
Solutions Remove battery and replace it within 30 seconds
Reading error for full length is ≤0.1mm
Failure
Possible Cause Dirt has damaged/covered sensor
Solutions Remove cover and slider assembly. Apply a small layer of petrol to avoid dirt build-up
Failure Nothing appears on LCD
Possible Cause Battery has poor contact. Battery voltage is under 1.1v
Solutions Check contact of battery or replace the battery
For the complete range of Oxford Precision tools, please
contact your local
distributor.
OXFORD
PRECISION
19/01/2010 14:08 Page 1
Order Code
PAN-904-5020K
Leicester, England
Digital Indicators
OXD-331 SERIES
TYPE IDS
•
Inch/Metric Convertible
•
Zero Reset
TYPE IDM
Multi Function Type.
•
Inch/Metric Convertible
•
Zero Reset
•
Data Hold
•
Min/Max Display
•
Fast Display
•
Auto Power off
OPERATOR'S MANUAL
OXFORD
PRECISION
Leicester, England
