Huayan Light Smart DJ LED Flat User Manual

Par battery&wireless
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

TECH SPECIFICATION:

Model No:
SmartDJ Flat
Voltage Input：
100-240V AC, 50/60Hz
LED Type:
TianXin 6in1 LEDs
Beam Angle:
20 °
Optical Lens Size:
42mm
Protocol:
USITT DMX-512, AirDMX Wifi System
DMX Channel Mode:
6/8/11/3
AirDMX, DMX-512, Standalone, Master/slave, Sound
Control Mode:
Active, iOS or Android Smartphone
Dimmer Mode:
4 Dimming Curves
PWM Dimming:
16bit PWM Dimming at 5200HZ
Battery Powered:
14.8V x 8.8Ah = 131Wh
Wireless DMX:
2.4G Wireless DMX Transceiver
Body Material:
Aluminum Die-casting
Waterproof Grade:
IP33 Indoor Use Only
Product Size
138x144x188mm
Net Weight.:
3Kgs
New Smart DJ LED Flat
Par Battery&Wi reless
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart DJ LED Flat and is the answer not in the manual?

Questions and answers

Summary of Contents for Huayan Light Smart DJ LED Flat

  • Page 1 TECH SPECIFICATION: New Smart DJ LED Flat Par Battery&Wi reless Model No: SmartDJ Flat Voltage Input： 100-240V AC, 50/60Hz LED Type: TianXin 6in1 LEDs User’s Manual Beam Angle: 20 ° Optical Lens Size: 42mm Protocol: USITT DMX-512, AirDMX Wifi System...

  • Page 2: Getting Started

    Getting Started The Lithium Battery System The “SmartDJ Flat” features our proprietary Lithium-Ion internal battery system which What’s In The Box? allows the user to operate their light without AC power for up to 20 hours. SmartDJ Flat battery powered wireless LED Uplights •...

  • Page 3: Standard Mode

    The “AirDMX” Wifi System The “AirDMX” App for iOS or Android The “AirDMX” System includes one “AirDMX Box”, and “AirDMX RECV” on You can scan the QR code on the “AirDMX Box” to download the right app for your each Light, you can connect the “AirDMX Box” to DMX Controller or Smartphone smart phone App for iOS or Android to have more fun with our “SmartDJ-Flat”...
  • Page 4 2. Standard Mode 000-255 Master Dimmer 000-255 000-255 Green Channel 000-255 Blue 000-255 Amber 000-255 White 000-255 000-255 Strobe 3. Easy Mode 000-255 000-255 Green Channel 000-255 Blue 000-255 Amber 000-255 White 000-255 4. HSV Mode 000-255 Channel 000-255 Saturation 000-255 Value...
  • Page 5 The Channel Modes The Safety Instructions Extend Mode • Please keep this User Guide for future use. If you sell the unit to someone else, be sure 000-255 Master Dimmer that they also receive this User Guide. 000-255 • ALWAYS make sure that you are connecting to the proper voltage, and that the line 000-255 Green voltage you are connecting to is not higher than that stated on the decal or rear panel of...
  • Page 6 attempt any repairs yourself. In the unlikely event your unit may require service, please contact The Menu Panel The Menu Structure The Control Panel There are 4 control buttons below the LED display which allow you to navigate through the various control panel menus. Address : 001-512 Address Setting Channel : 6 / 8 / 11 / 3...
