Summary of Contents for Stitch 33841
- Page 1 Wireless Smart PLUG-IN WALL OUTLET 33841 User’s Manual...
-
Page 2: Table Of Contents
CONTENTS SAFETY WARNINGS AND GUIDELINES ................................3 INTRODUCTION ............................................4 FEATURES ..............................................4 CUSTOMER SERVICE ........................................... 4 PACKAGE CONTENTS ........................................5 APPLICATIONS ............................................5 PRODUCT OVERVIEW ........................................6 Front View ............................................6 Rear and Side Views ........................................6 PHYSICAL INSTALLATION......................................7 APP INSTALLATION AND LOGIN ..................................... -
Page 3: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. ... -
Page 4: Introduction
Built-in light sensor provides an app controllable night light Supports scene control to work with other "smart" devices Works with other STITCH™ by Monoprice smart devices (sold separately) CUSTOMER SERVICE The Monoprice Customer Service department is dedicated to ensuring that your ordering, purchasing, and delivery experience is second to none. -
Page 5: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x Wall Outlet 1x User's Manual APPLICATIONS Plug the device into an outlet to control and monitor your appliances and electronics. -
Page 6: Product Overview
PRODUCT OVERVIEW Front View Rear and Side Views... -
Page 7: Physical Installation
Reset button for 5 seconds until the Signal Light starts to flash rapidly. APP INSTALLATION AND LOGIN 1. Download and install the free STITCH™ by Monoprice app from Google Play™ or the App Store. Scan one of the two QR codes below to go directly to the appropriate page in the app store. - Page 8 3. If you have already used the STITCH™ by Monoprice app, tap the Login button, then enter your STITCH account information. If you have not installed and used the STITCH app before, proceed to app registration. You can register using your phone number or by using your email address.
-
Page 9: Add A Device
Wi-Fi® network or do not wish to include the plug in your network, see the Installation section below. 1. Tap + on the Add Devices screen to add a new device. 2. Scroll through the list and select Wall Outlet to add your new device to the STITCH™ app. - Page 10 3. The Signal Light should be flashing green rapidly, indicating that it is ready to be paired with your network. If not, press and hold the Reset button for 5 seconds. 4. Tap Confirm on the app to continue, input the password to your wireless network, then tap Confirm again.
-
Page 11: Ap Mode Installation
Instead, it connects your phone's Wi-Fi directly to the device's built-in hotspot network. 1. Launch the STITCH™ by Monoprice app. 2. Tap + on the Add Devices screen to add a new device. - Page 12 4. Tap AP Mode at the top right. 5. The Signal Light should be slowly blinking, indicating that it is ready to be added in AP Mode. Tap Confirm on the app to continue, input the password to your wireless network, then tap Confirm again.
- Page 13 6. In the wireless settings on your phone, select the Stitch_XXXX entry, then tap Connect Now to continue. The app will begin connecting to the device.
-
Page 14: App Features
APP FEATURES Monitor and control outlets and USB ports on and off Create a schedule or set a countdown timer for outlets to turn on and off Master switch to power on or off both outlets and USB ports ... -
Page 15: Link Devices To Amazon Alexa
2. Add one or more devices in the STITCH by Monoprice app by following the APP INSTALLATION AND LOGIN instructions in the section above. 3. In the Amazon Alexa™ app menu, tap Skills, then search for and select the STITCH by Monoprice entry. Tap Enable to enable Amazon Skills. - Page 16 4. You will be redirected to the account link page. Select the proper country/region, then input your STITCH™ by Monoprice account and password. Tap Link Now, then tap Authorize. When the message STITCH by Monoprice has been successfully linked appears, close the window.
- Page 17 STITCH™ by Monoprice app. The discovered devices will be displayed in a list. Note: Each time the device's name is changed in the STITCH™ by Monoprice app, Alexa must rediscover it again before it can be controlled.
-
Page 18: Led Indicator Status
LED INDICATOR STATUS Smart Inclusion LED Signal Light flashes green rapidly AP Mode LED Signal Light flashes green slowly BUTTON INSTRUCTIONS Press and hold the Reset button for 5 seconds, then release it to reset In Network the plug and enter Smart Inclusion Mode While in Smart Inclusion Mode, press and hold the Reset button for 5 Out of Network seconds, then release it to switch to AP Mode... -
Page 19: Specifications
SPECIFICATIONS Radio Frequency 2.4 GHz Supported Network Protocols IEEE802.11 b/g/n Receptacle Rating 125 VAC, 60Hz, 15A USB Rating 5 VDC, 4.8A total for 2 ports Operating Temperature -14 ~ +140°F (-20 ~ +60°C) Product Dimensions (without prongs) 4.7" x 3.0 x 1.3" (121 x 77 x 34 mm) REGULATORY COMPLIANCE Notice for FCC This device complies with Part 15 of the FCC rules. -
Page 20: Rf Exposure Statement For Fcc
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ... -
Page 21: Rf Exposure Statement For Industry Canada
United States and certain other countries. Wi-Fi® is a registered trademark of Wi-Fi Alliance. Amazon™, Amazon Alexa™, and all related logos are trademarks of Amazon.com, Inc. or its affiliates. STITCH™ and the STITCH logo are trademarks of Monoprice Inc. - Page 22 Product pictures are for reference only. Specifications described herein are subject to change without prior notification. All trademarks are the sole property of their respective companies. Stitch is a Sub-Brand for Smart Home of Monoprice. Copyright © 2018 Monoprice, Inc. All rights reserved.
