Ansee BWR-01A Operation Instructions

BWR-01A is a fuel gas detector with high stability, used for checking the leakage of fuel gas and
increase the safety. It adopts advanced catalytic gas sensor with high stability and sensitivity features.
The detector supports microprocessor technology, it can trigger light and sound alarm, and remotely
send related gas density value to alarm host by RF. It is suitable for areas where gas leakage may
easily occurs. The gas detector can be used standalone, also can work as accessory in smart home
application to realize remote alarm.

Features

Audible & Visual Alarm
Anti High-frequency interference
Rolling code for anti-crack

Specifications

Model Name
Working Voltage
Temperature
Humidity
Alarm Level
Alarm Reset
Alarm Format
RF Distance
Radio Frequency
Measurement
Operation Instructions
1. Powered on,the yellow LED and Red LED will normal be on for 1 second. Then buzzer will give "di"
sound and Red LED starts to flash. The detector goes into preheating status for 3 to 5 minutes. After
that,the red LED will be normal on and the detector goes into standby status.
2. For product test: press test button, the red LED will flash fast and make "di- di- di ..." sound, also
it will send alarm signal to alarm host through RF .
3. Solenoid Valve Connection: the positive pole connects to SIG+ of detector, the negative pole
connects to SIG- of detector(optional).
Fuel Gas Detector
Wireless communication with Alarm Host
Automatic Fault Detection Indication
High Reliable Catalytic Gas Sensor
AC100V~AC240V 50~60 HZ
First level alarm, 10%LEL
Auto reset when the fuel gas is cleared
Audible & Visual alarm, remote alarm (work with alarm host)
≥ 30M (open area)
115*72*46.5 mm
BWR-01A
BWR-01A
0℃ ~50℃
10%~95% RH
915MHz/FSK
