UE Systems Ultraprobe 401 Instruction Manual

Digital grease caddy pro
Hide thumbs

Advertisement

Quick Links

Download this manual
Version 1
1
Ultraprobe 401
Digital Grease caddy Pro
Instruction Manual

Advertisement

loading

Summary of Contents for UE Systems Ultraprobe 401

  • Page 1 Version 1 Ultraprobe 401 Digital Grease caddy Pro Instruction Manual...

  • Page 2: Table Of Contents

    Version 1 Contents Instructions for Ultraprobe 401 Digital Grease Caddy Pro: ..............3 Mounting the 401 Digital Grease Caddy to Grease Gun: ..............5 III. Setup: .............................. 5 IV. Getting Started: ..........................5 V. Display Panel Screens and Functions ..................... 6 Setup Menu Screens: ...........................

  • Page 3: Instructions For Ultraprobe 401 Digital Grease Caddy Pro

    Version 1 Instructions for Ultraprobe 401 Digital Grease Caddy Pro: Overview: The 401 Digital Grease Caddy Pro is an important element to ultrasound assisted lubrication. Through uploading and downloading of bearing data it lets users know when to stop adding lubrication as well as provide data of lubrication history that adds to analysis of bearing condition to prevent premature failure.
  • Page 4 Version 1 B. Main Unit: Headphone Jack On/ Off Button Sensitivity / Spin and click dial Display panel BNC connector for magnetic mount probe Recharge Jack LED flash light SD Card slot C. Grease Gun Mounting Kit Open clamp end Clamp knob Grease gun mount foot Grease gun ring with foam strip...

  • Page 5: Mounting The 401 Digital Grease Caddy To Grease Gun

    Version 1 Mounting the 401 Digital Grease Caddy to Grease Gun: 1. Screw Mount Ball (2/22) into threaded fitting on the bottom of the Digital Grease Caddy housing as shown. 2. Place Mount (21) on Grease gun so that the Grease Gun Mount Foot (19) is resting on the grease gun.

  • Page 6: Display Panel Screens And Functions

    Version 1 V. Display Panel Screens and Functions . Moving around the screens using the Sensitivity/Spin & Click dial: a. To move around a screen or to enter and use a feature of the “Function Bar” (described below) there are two ways to use the Sensitivity/Spin and Click dial. The first is to lightly click to move the blinking indicator/cursor to a feature on the display screen.
  • Page 7 Version 1 1. Display Screen 1: a. Displays: Sensitivity value S=, record location (001- 399), dB level and the “Function Bar” on the bottom of the screen. This is Display 1 showing the ability to move to Display 2 shown in the Function bar. 2.

  • Page 8: Setup Menu Screens

    Version 1 Setup menu (Function Bar Screen): There are 18 Setup menus. To enter and use any of the Setup menus: a. click the Sensitivity dial until the cursor blinks on the Function Bar b. If Setup menu is not shown, spin the Sensitivity dial until Setup menu appears. Push and hold the Sensitivity dial until the first screen appears.
  • Page 9 Version 1 3. Add lube amount: The number of strokes of the grease gun used to apply the grease can be added after the lubricant has been applied and Add Lube Amount has been selected. To select this feature: A, Enter set up mode and go to Menu 3. B.
  • Page 10 Version 1 7. User Frequency Default: Click to enter, spin click to set and exit to set the desired frequency. The frequency range is 20 kHz to 100 kHz. 8. Frequency Adjust: This feature allows the user to change frequencies between 20 kHz and 100 kHz in one kHz steps..
  • Page 11 Version 1 10. Headphone Volume: This feature allows you to adjust the sound level or volume level in the headphone. Click to enter the volume selections range from 0% to 99%. The default value is 95%. 11. Enter Inspector ID: Click to enter.
  • Page 12 Version 1 14. CAL Due Date: The date for instrument calibration is shown on the top of the screen. 15. DB Scale Type Select: The choices are Relative and Offset. dB Offset Value: Click to enter. Spin for values -1-10, Spin to the right for values 1-40.

  • Page 13: Other Features

    Version 1 VI. Other Features A. Selecting Sensitivity The Sensitivity is displayed on both Display Screen 1 and 2 as S=.The highest sensitivity value is 70, the lowest is 0. In order to adjust the sensitivity value the S= must blink on the display screen.
  • Page 14 Version 1 1. Without Before and After a. Be sure you have you selected add lube amount in the set up menu. b. After adjusting your sensitivity to obtain the proper DB reading, click the sensitivity dial until the 00 is blinking in the function bar.

  • Page 15: Ultraprobe 401 Digital Grease Caddy Specifications

    Covered by one or more of the following patents: 0151115,0303776,0315199,1206586, 1297576,1881263,2562758,2689339, 4416145, 4823600,5955670,6122966, 6339961, 6341518, 6415645, 6655214, 6707762, 6804992 UE Systems is committed to continual product improvement: therefore specifications are subject to change without notice. Warranty details are available by request.
  • Page 16 Version 1 Need further support? Want information regarding products or training? Contact : UE Systems Europe, Windmolen 20, 7609 NN Almelo (NL) info@uesystems.eu www.uesystems.eu t: +31 (0)546 725 125 f: +31 (0)546 725 126 www.uesystems.eu...
