Acer MWIHD1 User Manual

60 ghz wireless hd transceiver.
Hide thumbs

Advertisement

60 GHz Wireless HD Transceiver
MWIHD1 User's Guide
Introduction
Package contents
The following items should be included:
• Transmitter unit (MWIT1)
• Receiver unit (MWIR1)
• HDMI
®
cable
• User's Guide
• Warranty
• Power adapter
• MHL cable
If any of the above items is damaged or missing, please
contact your supplier immediately.
Using the product safely
• Always treat your product with care and keep it in a
clean and dust-free place.
• Do not expose your product to liquid, moisture or
humidity.
• Do not expose your product to temperatures above
40° C when in operation.
• Do not drop or throw your product.
• Do not attempt to disassemble or modify your
product. Only authorized personnel should perform
service.
• Your device is not water-resistant; keep it dry.
• Only use the supplied AC adapter.
1
English

Advertisement

   Related Manuals for Acer MWIHD1

No related manuals

   Summary of Contents for Acer MWIHD1

  • Page 1 English 60 GHz Wireless HD Transceiver MWIHD1 User's Guide Introduction Package contents The following items should be included: • Transmitter unit (MWIT1) • Receiver unit (MWIR1) • HDMI ® cable • User's Guide • Warranty • Power adapter • MHL cable If any of the above items is damaged or missing, please contact your supplier immediately.
  • Page 2: Front Panel

    English Hardware 60 GHz Wireless HD MWIR1 / MWIT1 Front panel LED indicator Color Behavior Indication The transmitter has Blinking started transmitting and slowly has not yet found the receiver. Transmitter and receiver Blinking are linked and fast communicating with each other.
  • Page 3: Rear Panel

    English Rear panel HDMI/MHL DC-in Find next Power switch Configuration Short press (< 10 seconds) to detect the next source. This function allows you to switch the source of the audio/video to another in-range Wireless HD transmitter. This disconnects the current connection Find next and triggers a connection to the next available source on the device list.
  • Page 4 English Step 1 The transmitter (MWIT1) Step 2 The receiver (MWIR1) Notes  For the best results, the MWIT1 and MWIR1 should: Face each other and be in the same room. Be no more than 33 feet (10 meters) apart. MWIT1 should not be placed in a cabinet or on a closed shelf.
  • Page 5 English 3. Check that the transmitter is powered. 4. Turn on the transmitter. Select the source Connecting to a different transmitter 1. Turn on the new transmitter. Power switch 2. Press the Find next button for 2 seconds. Find next button 3.
  • Page 6: Specifications

    English Specifications Specifications Standards Wireless HD 1.1, HDMI 1.4a, MHL V2.0 Frequency 60 GHz HDMI/MHL -n (MWIT1), Input/output MHL out x 1 (MWIR1) Antenna type 24 antenna array Range 10 meters in-room usage MWIT1: 1 port (CEC pass through) A/V port MWIR1: 1 port (CEC pass through) Weight: 106 g (MWIT1)
  • Page 7 English Video formats Vertical Color Video format Sampling Supported refresh space 4:2:2 YCbCr 480i 59.94 Hz 4:4:4 (1440 x 480i) 4:4:4 4:2:2 480p/480pw YCbCr 59.94 / (640 x 480p/ 4:4:4 60 Hz 720 x 480p) 4:4:4 4:2:2 YCbCr 576i 50 Hz 4:4:4 (1440 x 576i) 4:4:4...
  • Page 8 English 4:2:2 YCbCr 23.976 / 4:4:4 24 Hz 4:4:4 4:2:2 YCbCr 1080p 50 Hz 4:4:4 (1920 x 1080p) 4:4:4 4:2:2 YCbCr 59.94 / 4:4:4 60 Hz 4:4:4 59.94 Hz 4:4:4 (640 x 480) SVGA 60 Hz 4:4:4 (800 x 600) 60 Hz 4:4:4 (1024 x 768)
  • Page 9 English Audio formats Audio sample rate LPCM LPCM 2/6/8-channel 2-channel 44.1 88.2 176.4 Supported Supported *Specification subject to change without notice. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 10 English FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 11 Français Émetteur-récepteur HD sans fil 60 GHz Guide d’utilisation du MWIHD1 Introduction Contenu de l’emballage Les éléments suivants doivent être inclus : • Émetteur (MWIT1) • Récepteur (MWIR1) ® • Câble HDMI • Guide d’utilisation • Garantie • Adaptateur secteur •...
  • Page 12 Français Matériel MWIR1 / MWIT1HD sans fil 60 GHz Panneau avant Témoin à diode Diode Couleur Comportement Indication L’émetteur a commencé à Clignote transmettre et n’a lentement pas encore trouvé le récepteur. L’émetteur et le Clignote récepteur sont liés rapidement et communiquent Alimenta entre eux.
  • Page 13 Français Panneau arrière HDMI/MHL Entrée Trouver Interrupteur suivant d’alimentation Configuration Appui court (< 10 secondes) pour détecter la source suivante. Cette fonction vous permet de basculer la source de l’audio/vidéo vers un autre émetteur sans fil HD à portée. Ceci interrompt la connexion en cours et Trouver déclenche une connexion à...
  • Page 14 Français 2. Connectez le récepteur au port HDMI/MHL sur le projecteur. Sélectionnez WirelessHD dans la liste des sources de projecteurs. Étape 1 L’émetteur (MWIT1) Étape 2 Le receveur (MWIR1) Remarques  Pour obtenir les meilleurs résultats, le MWIT1 et le MWIR1 devrait : Être en face l’un de l’autre et être dans la même pièce.
  • Page 15 Français 3. Vérifiez que l’émetteur est alimenté. 4. Allumez l’émetteur. Sélectionner la source Se connecter à un émetteur différent 1. Allumez le nouvel émetteur. Interrupteur d’alimentation 2. Appuyez le bouton Trouver suivant pendant 2 secondes. Bouton Trouver suivant 3. La diode sur l’émetteur commencera à clignoter rapidement.
  • Page 16 Français Caractéristiques Caractéristiques Standards Sans fil HD 1.1, HDMI 1.4a, MHL V2.0 Fréquence 60 GHz HDMI/MHL -n (MWIT1), Entrée/Sortie Sortie MHL x 1 (MWIR1) Type d’antenne Groupe de 24 antennes Plage 10 mètres en utilisation en intérieur MWIT1 : 1 port (relais CEC) Port A/V MWIR1 : 1 port (relais CEC) Poids :...
  • Page 17 Français Formats vidéo Rafraîchi Espace Échantil Pris en Format vidéo ssement couleur lonnage charge vertical 4:2:2 YCbCr 480i 59,94 Hz 4:4:4 (1440 x 480i) 4:4:4 4:2:2 480p/480pw YCbCr 59,94 / 60 (640 x 480p/ 4:4:4 720 x 480p) 4:4:4 4:2:2 YCbCr 576i 50 Hz...
  • Page 18 Français 4:2:2 YCbCr 23,976 / 4:4:4 24 Hz 4:4:4 4:2:2 YCbCr 1080p 50 Hz 4:4:4 (1920 x 1080p) 4:4:4 4:2:2 YCbCr 59,94 / 60 4:4:4 4:4:4 59,94 Hz 4:4:4 (640 x 480) SVGA 60 Hz 4:4:4 (800 x 600) 60 Hz 4:4:4 (1024 x 768) WXGA...
  • Page 19 Français Formats audio Taux d’échantillonnage audio LPCM 2 LPCM 2/6/8 canaux canaux 44,1 88,2 176,4 Pris en charge Pris en charge *Les caractéristiques peuvent être modifiées sans préavis. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 20 Français FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 21 Deutsch 60 GHz WLAN HD Transceiver MWIHD1 Bedienungsanleitung Einleitung Packungsinhalt Die folgenden Artikel sollten enthalten sein: • Sendeeinheit (MWIT1) • Empfangseinheit (MWIR1) • HDMI ® Kabel • Bedienungsanleitung • Garantie • Netzteil • MHL-Kabel Wenn einer der oben genannten Artikel beschädigt oder nicht vorhanden ist, kontaktieren Sie bitte umgehend Ihren Händler.
  • Page 22 Deutsch Hardware 60 GHz WLAN HD MWIR1 / MWIT1 Vorderseite LED-Anzeige Farbe Verhalten Anzeige Der Sender hat mit dem Blinkt Senden begonnen und langsam dem Empfänger noch nicht gefunden. Sender und Empfänger sind miteinander Blinkt verbunden und schnell kommunizieren miteinander. Ein/Aus Blau MWIR1 und MWIT1...
  • Page 23 Deutsch Rückseite HDMI/MHL Nächste Ein/Aus- Eingang finden Schalter Konfiguration Langsam drücken (< 10 Sekunden), um die nächste Quelle zu suchen. Mit dieser Funktion können die Audio/Video-Quelle auf einen WLAN HD Sender in Reichweite wechseln. Dies trennt die aktuelle Verbindung und startet eine Verbindung mit der Nächste finden nächsten verfügbaren Quelle in der...
  • Page 24 Deutsch Ausgangsauflösung des Computers der eines unterstützten Videoformats entspricht. 2. Verbinden Sie den Empfänger mit dem HDMI/MHL-Anschluss am Projektor. Wählen Wire- lessHD aus der Quellliste des Projektors. Schritt 1 Der Sender (MWIT1) Schritt 2 Der Empfänger (MWIR1) Notizen  Für optimale Ergebnisse sollten der MWIT1 und MWIR1: Sich gegenüberstehen und im selben Raum sein.
  • Page 25 Deutsch 3. Prüfen Sie, dass der Sender eingeschaltet ist. 4. Schalten Sie den Sender ein. Auswahl der Quelle Verbindung mit einem anderen Sender 1. Schalten Sie den neuen Sender ein. Ein/Aus-Schalter 2. Drücken Sie 2 Sekunden lang auf Nächste finden. Nächste finden Taste 3.
  • Page 26: Technische Daten

    Deutsch Technische Daten Technische Daten Standards WLAN HD 1.1, HDMI 1.4a, MHL V2.0 Frequenz 60 GHz HDMI/MHL -n (MWIT1), Eingang/Ausgang MHL Ausgang x 1 (MWIR1) Antennentyp 24 Antennenanordnung Bereich 10 Meter Nutzung innen MWIT1: 1 Anschluss (CEC Passthrough) A/V-Anschluss MWIR1: 1 Anschluss (CEC Passthrough) Gewicht: 106 g (MWIT1)
  • Page 27 Deutsch Videoformate Vertikale Videoformat Aktualisie Farbraum Abtastung Unterstützt rung 4:2:2 YCbCr 480i 59,94 Hz 4:4:4 (1440 x 480i) 4:4:4 4:2:2 480p/480pw YCbCr 59,94 / (640 x 480p/ 4:4:4 60 Hz 720 x 480p) 4:4:4 4:2:2 YCbCr 576i 50 Hz 4:4:4 (1440 x 576i) 4:4:4 YCbCr...
  • Page 28 Deutsch 4:2:2 YCbCr 23,976 / 4:4:4 24 Hz 4:4:4 4:2:2 YCbCr 1080p 50 Hz 4:4:4 (1920 x 1080p) 4:4:4 4:2:2 YCbCr 59,94 / 4:4:4 60 Hz 4:4:4 59,94 Hz 4:4:4 (640 x 480) SVGA 60 Hz 4:4:4 (800 x 600) 60 Hz 4:4:4 (1024 x 768)
  • Page 29 Deutsch Audioformate Audio Abtastrate LPCM LPCM 2/6/8-Kanal 2-Kanal 44,1 88,2 176,4 Unterstützt Unterstützt *Die technischen Daten des Produktes können ohne Ankündigung geändert werden. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 30 Deutsch FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Oper- ation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 31 Italiano Ricetrasmettitore HD wireless da 60 GHz Guida per l’utente di MWIHD1 Introduzione Contenuto della confezione Devono essere presenti i seguenti articoli: • Unità del trasmettitore (MWIT1) • Unità del ricevitore (MWIR1) ® • Cavo HDMI • Guida per l’utente •...
  • Page 32 Italiano Hardware 60 GHz Wireless HD MWIR1 / MWIT1 Pannello anteriore Indicatore LED Comporta Colore Indicazione mento Il trasmettitore ha Lampeggio iniziato la trasmissione lento e non ha ancora trovato il ricevitore. Il trasmettitore e il Lampeggio ricevitore sono collegati rapido e comunicanti tra loro.
  • Page 33 Italiano Pannello posteriore HDMI/MHL Ingresso Trova Interruttore successiva alimentazione Configurazione Premere brevemente (< 10 secondi) per rilevare la sorgente successiva. Questa funzione consente di commutare la sorgente audio/video a un altro trasmettitore Wireless HD all'interno del raggio. Questo disconnette la Trova connessione corrente ed attiva una successiva...
  • Page 34 Italiano 2. Collegare il ricevitore alla porta HDMI/MHL del proiettore. Selezionare WirelessHD dall'elenco delle sorgenti del proiettore. Passo 1 Il trasmettitore (MWIT1) Passo 2 Il ricevitore (MWIR1) Note  Per ottenere risultati ottimali, il MWIT1 e il MWIR1 devono: essere uno di fronte all'altro e trovarsi nella stessa stanza.
  • Page 35 Italiano 3. Verificare che il trasmettitore sia alimentato. 4. Accendere il trasmettitore. Selezione della sorgente Collegamento a un trasmettitore diverso 1. Accendere il nuovo trasmettitore. Interruttore alimentazione 2. Premere il pulsante Trova successiva per 2 secondi. Trova il pulsante Avanti 3.
  • Page 36 Italiano Specifiche Specifiche Standard Wireless HD 1.1, HDMI 1.4a, MHL V2.0 Frequenza 60 GHz HDMI/MHL -n (MWIT1), Ingresso/uscita Uscita MHL x 1 (MWIR1) Tipo di Gruppo di 24 antenne antenna Intervallo 10 metri utilizzo nella stanza MWIT1: 1 porta (CEC pass through) Porta A/V MWIR1: 1 porta (CEC pass through) Peso:...
  • Page 37 Italiano Formati video Aggiorna Spazio Campiona Suppor Formato video mento colore mento tato verticale 4:2:2 Sì YCbCr 480i 59,94 Hz 4:4:4 Sì (1440 x 480i) 4:4:4 Sì 4:2:2 Sì 480p/480pw YCbCr 59,94 / 60 (640 x 480p/ 4:4:4 Sì 720 x 480p) 4:4:4 Sì...
  • Page 38 Italiano 4:2:2 Sì YCbCr 23,976 / 4:4:4 Sì 24 Hz 4:4:4 Sì 4:2:2 Sì YCbCr 1080p 50 Hz 4:4:4 Sì (1920 x 1080p) 4:4:4 Sì 4:2:2 Sì YCbCr 59,94 / 60 4:4:4 Sì 4:4:4 Sì 59,94 Hz 4:4:4 Sì (640 x 480) SVGA 60 Hz 4:4:4...
  • Page 39 Italiano Formati audio Frequenza di campionamento audio LPCM 2/6/8 canali LPCM 2 canali 44,1 88,2 176,4 Supportato Supportato *Le specifiche possono essere soggette a cambiamenti senza preavviso. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 40 Italiano FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 41 Español Transceptor HD inalámbrico 60 GHz Manual de usuario del MWIHD1 Introducción Contenido de la caja La caja debería incluir los siguientes artículos: • Unidad transmisora (MWIT1) • Unidad receptora (MWIR1) ® • Cable HDMI • Manual de usuario • Garantía •...
  • Page 42 Español Hardware MWIR1/MWIT1 inalámbrico HD 60 GHz Panel frontal Indicador LED Comporta Color Indicación miento El transmisor ha iniciado Parpadeo la transmisión pero aún lento no ha encontrado el receptor. El transmisor y el Parpadeo receptor están rápido vinculados y se están comunicando entre sí.
  • Page 43 Español Panel trasero HDMI/MHL Entrada Buscar Interruptor de de CC siguiente encendido Configuración Pulsar brevemente (< 10 segundos) para detectar la siguiente fuente. Esta función le permite conmutar la fuente de audio/vídeo a otro transmisor HD inalámbrico que se encuentre dentro del alcance.
  • Page 44 Español formato de vídeo compatible. 2. Conecte el receptor al puerto HDMI/MHL del proyector. Seleccione WirelessHD en la lista de fuentes del proyector. Paso 1 El transmisor (MWIT1) Paso 2 El receptor (MWIR1) Notas  Para lograr los mejores resultados posibles el MWIT1 y el MWIR1 deben: Estar orientados uno hacia el otro y encontrarse en la misma sala.
  • Page 45 Español 3. Asegúrese de que el transmisor se encuentra encendido. 4. Encienda el transmisor. Seleccione la fuente Conexión a un transmisor distinto 1. Encienda el nuevo transmisor. Interruptor de encendido 2. Pulse el botón Buscar siguiente durante 2 segundos. Botón Buscar siguiente 3.
  • Page 46 Español Especificaciones Especificaciones HD inalámbrico 1.1, HDMI 1.4a, MHL Estándares V2.0 Frecuencia 60 GHz HDMI/MHL -n (MWIT1), Entrada/salida 1 salida MHL (MWIR1) Tipo de antena Matriz de 24 antenas Alcance Uso de 10 metros en salas MWIT1: 1 puerto (pasarela CEC) Puerto de A/V MWIR1: 1 puerto (pasarela CEC) Peso:...
  • Page 47 Español Formatos de vídeo Actualiza Formato de Espacio Compati ción Muestreo vídeo de color vertical 4:2:2 SÍ YCbCr 480i 59,94 Hz 4:4:4 SÍ (1440 × 480i) 4:4:4 SÍ 480p/480pw 4:2:2 SÍ YCbCr (640 × 59,94/60 4:4:4 SÍ 480p/720 × 4:4:4 SÍ...
  • Page 48 Español 4:2:2 SÍ YCbCr 23,976/ 4:4:4 SÍ 24 Hz 4:4:4 SÍ 4:2:2 SÍ YCbCr 1080p 50 Hz 4:4:4 SÍ (1920 × 1080p) 4:4:4 SÍ 4:2:2 SÍ YCbCr 59,94/60 4:4:4 SÍ 4:4:4 SÍ 59,94 Hz 4:4:4 SÍ (640 × 480) SVGA 60 Hz 4:4:4 SÍ...
  • Page 49 Español Formato de audio Tasa de muestreo de audio LPCM 2 LPCM 2/6/8 canales canales 44,1 88,2 176,4 Compatible Compatible *Las especificaciones están sujetas a cambios sin previo aviso. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 50 Español FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 51 Português Transceptor HD 60 GHz Sem fios Manual do Utilizador do MWIHD1 Introdução Conteúdo da embalagem Devem estar incluídos os seguintes itens: • Unidade Transmissora (MWIT1) • Unidade Receptora (MWIR1) ® • Cabo HDMI • Manual do Utilizador • Garantia •...
  • Page 52 Português Hardware 60 GHz HD Sem Fios MWIR1 / MWIT1 Painel frontal Indicador LED Comportamento Indicação O transmissor iniciou a transmissão e Piscar lento ainda não localizou ou receptor. O transmissor e receptor estão Piscar rápido conectados e a comunicar entre si. Alimen Azul tação...
  • Page 53 Português Painel traseiro HDMI/MHL Entrada Encontrar Interruptor de seguinte alimentação Configuração Pressionar curto (< 10 segundos) para detectar a fonte seguinte. Esta função permite-lhe mudar a fonte áudio/vídeo para outro transmissor Sem Fios HD ao alcance. Isto desliga a ligação actual e Encontrar activa uma ligação à...
  • Page 54 Português Passo 1 O transmissor (MWIT1) Passo 2 O receptor (MWIR1) Notas  Para os melhores resultados, o MWIT1 e MWIR1 devem: Estar frente a frente e na mesma divisão. Estar a menos de 33 pés (10 metros) de distância um do outro.
  • Page 55 Português 3. Verifique se o transmissor está ligado. 4. Ligue o transmissor. Seleccione a fonte Ligar a um transmissor diferente 1. Ligue o novo transmissor. Interruptor de alimentação 2. Prima o botão Encontrar seguinte durante 2 segundos. Botão Encontrar seguinte 3.
  • Page 56 Português Especificações Especificações Normas Wireless HD 1.1, HDMI 1.4a, MHL V2.0 Frequência 60 GHz HDMI/MHL -n (MWIT1), Entrada/saída saída MHL x 1 (MWIR1) Tipo de antena Conjunto de 24 antenas 10 metros, em utilização dentro de uma Alcance divisão MWIT1: 1 porta (passagem CEC) Porta A/V MWIR1: 1 porta (passagem CEC) Peso:...
  • Page 57 Português Formatos vídeo Actuali Gama Amostra Formato vídeo zação Suportado de cor vertical 4:2:2 YCbCr 480i 59,94 Hz 4:4:4 (1440 x 480i) 4:4:4 4:2:2 480p/480pw YCbCr 59,94 / (640 x 480p/ 4:4:4 60 Hz 720 x 480p) 4:4:4 4:2:2 YCbCr 576i 50 Hz 4:4:4...
  • Page 58 Português 4:2:2 YCbCr 23,976 / 4:4:4 24 Hz 4:4:4 4:2:2 YCbCr 1080p 50 Hz 4:4:4 (1920 x 1080p) 4:4:4 4:2:2 YCbCr 59,94 / 4:4:4 60 Hz 4:4:4 59,94 Hz 4:4:4 (640 x 480) SVGA 60 Hz 4:4:4 (800 x 600) 60 Hz 4:4:4 (1024 x 768)
  • Page 59 Português Formatos áudio Taxa de amostragem áudio LPCM LPCM 2/6/8-canais 2-canais 44,1 88,2 176,4 Suportado Suportado *As especificações estão sujeitas a alteração sem aviso prévio. FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 60 Português FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 61 繁體中文 60 GHz 無線 HD 收發器 MWIHD1 使用手冊 簡介 包裝內容物 包裝內應包含以下項目: • 傳輸器單元 (MWIT1) • 接收器單元 (MWIR1) • HDMI ® 傳輸線 • 使用手冊 • 保固 • 變壓器 • MHL 傳輸線 若以上物品遺失或損壞,請立即聯絡供應商。 安全使用本產品 • 請隨時善待您的產品,將產品保持在乾淨無灰塵的 空間。 • 請勿將產品暴露於液體、潮濕、或濕氣中。 • 操作產品時,請勿將產品暴露於超過 40° C 的...
  • Page 62 繁體中文 硬體 60 GHz 無線 HD MWIR1 / MWIT1 前面板 LED 指示燈 顏色 行為 指示 傳輸器已經開始傳輸, 緩慢閃爍 且沒有找到接收器。 傳輸器已經與接收器連 快速閃爍 線,雙方通訊正常。 電源 藍色 MWIR1 與 MWIT1 已經 開啟 建立影音連線,已經成 功建立網路。 變壓器關閉,或處於睡 關閉 眠模式。...
  • Page 63 繁體中文 後面板 DC 輸入 電源開關 尋找下一個 HDMI/MHL 配置 短按 (< 10 秒) 以偵測下一個來源。此功 能可讓您將影音來源切換至範圍內的另 一個無線 HD 傳輸器 。 這麼做會中斷目前 的連線,並觸發連線至裝置清單上的下一 尋找下一個 組可用來源。 長按 (> 10 秒) 以重設為原廠預設值。此 功能可讓您重設接收器至出廠時的原始 設定。 將 HDMI/MHL 傳輸線連接到此連接埠以 HDMI/MHL 及電視或電腦。 電源開關 按下以開啟或關閉電源。 DC 輸入 將電源變壓器接到 DC 電源輸入插孔。 安裝...
  • Page 64 繁體中文 2. 連接接收器至投影機上的 HDMI/MHL 連接埠。從投 影機來源清單選取 WirelessHD。 步驟 1 傳輸器 (MWIT1) 步驟 2 接收器 (MWIR1) 注意  為求最佳效能,MWIT1 與 MWIR1 應: 面對彼此,並放置於同個房間內。裝置間的距離不應 超過 33 英尺 (10 公尺)。MWIT1 不應放置於櫥櫃 或密閉的架上。 請勿將裝置靠近金屬物體。  請不要忘記開啟投影機並確認其已正確設定。...
  • Page 65 繁體中文 3. 請檢查傳輸器是否已接上電源。 4. 開啟傳輸器。 選取來源 連接至不同的傳輸器 1. 開啟新的傳輸器。 電源開關 尋找下一個 2. 按下 按鈕 2 秒。 「尋找下一個」按鈕 3. 傳輸器上的 LED 會開始快速閃爍 。 新的連線建立後, LED 會停止閃爍並保持恆亮。...
  • Page 66 繁體中文 規格 規格 標準 無線 HD 1.1、HDMI 1.4a、MHL V2.0 頻率 60 GHz HDMI/MHL -n (MWIT1) 、 輸入 / 輸出 MHL 輸出 x 1 (MWIR1) 天線類型 24 天線陣列 範圍 室內使用為 10 公尺 MWIT1:1 連接埠 (CEC 傳遞) A/V 連接埠 MWIR1:1 連接埠 (CEC 傳遞) 重量:...
  • Page 67 繁體中文 影像格式 影像格式 垂直更新 色域 取樣 支援 是 4:2:2 YCbCr 480i 是 59.94 Hz 4:4:4 (1440 x 480i) 是 4:4:4 是 4:2:2 480p/480pw YCbCr 59.94 / 60 (640 x 480p/ 4:4:4 是 720 x 480p) 是 4:4:4 是 4:2:2 YCbCr 576i 是...
  • Page 68 繁體中文 是 4:2:2 YCbCr 23.976 / 是 4:4:4 24 Hz 是 4:4:4 是 4:2:2 YCbCr 1080p 是 50 Hz 4:4:4 (1920 x 1080p) 是 4:4:4 是 4:2:2 YCbCr 59.94 / 60 是 4:4:4 是 4:4:4 是 59.94 Hz 4:4:4 (640 x 480) SVGA 是...
  • Page 69 繁體中文 音訊格式 音訊取樣率 LPCM 2/6/8 頻道 LPCM 2 頻道 44.1 88.2 176.4 支援 支援 *規格如有變更,恕不另行通知。 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 70 繁體中文 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 71 简体中文 60 GHz 无线 HD 收发器 MWIHD1 用户指南 简介 包装内容 包含以下物品: • 发射器设备 (MWIT1) • 接收器设备 (MWIR1) 线 • HDMI ® • 用户指南 • 质保 • 电源适配器 • MHL 线 若上述物品中有任何损坏或缺失, 请立即与经销商联系。 安全使用本产品 • 处理产品时始终小心,并将其置于干净无尘的 地方。 • 请勿使产品遭受液体洒入或受潮。 • 请勿在温度高于 40°C 的场合操作本产品。...
  • Page 72 简体中文 硬件 60 GHz 无线 HD MWIR1 / MWIT1 前面板 LED 指示灯 颜色 行为 指示 指示灯 发射器已开始传输,尚 慢闪 未找到接收器。 发射器和接收器进行链 快闪 接并相互通信。 电源 蓝色 MWIR1 和 MWIT1 已建 开启 立音频/视频连接,网络 已建立。 适配器已关闭或处于睡 关闭 眠模式。...
  • Page 73 简体中文 后面板 直流电源输入 电源开关 找到下一个 HDMI/MHL 配置 短按 (< 10 秒) 可检测下一个来源。此功 能可让您将音频/视频源切换到另一个范 围内的无线 HD 发射器。 这将断开当前的 连接并触发至设备列表中下一个可用来 找到下一个 源的连接。 长按 (> 10 秒) 可恢复为默认出厂设置。 此功能可让您将接收器恢复至原始发运 状况。 将 HDMI/MHL 线连接到此端口和电视或 HDMI/MHL 电脑。 电源开关 按下可开或关闭电源。 直流电源输入 将电源适配器连接到直流电源输入插口。 安装 设置步骤 1. 用 HDMI/MHL 线将发射器连接到媒体源,如电脑、 蓝光播放器或智能手机。如果连接电脑,请确认电脑...
  • Page 74 简体中文 2. 将接收器连接到投影机的 HDMI/MHL 端口。从投影 机信号源列表中选择 WirelessHD。 步骤 1 发射器 (MWIT1) 步骤 2 接收器 (MWIR1) 注  要获得最佳结果,MWIT1 和 MWIR1 应: 面对面并在同一屋内。 之间的距离不要超出 33 英尺 (10 米)。MWIT1 应不要置于机柜内或闭合的架中。 请勿置于金属物体附近。  请勿忘记开启投影机并确保设置正确。...
  • Page 75 简体中文 3. 检查发射器电源打开。 4. 开启发射器。 选择信号源 连接到不同的发射器 1. 开启新发射器。 电源开关 查找下一个 2. 按 按钮 2 秒钟。 “找到下一个”按钮 3. 发射器上的 LED 将开始快闪。 当新连接建立后, LED 将停止闪烁并保持亮起。...
  • Page 76 简体中文 规格 规格 标准 无线 HD 1.1、HDMI 1.4a、MHL V2.0 频率 60 GHz HDMI/MHL -n (MWIT1), 输入/输出 MHL 输出 x 1 (MWIR1) 天线类型 24 天线陈列 范围 10 米,室内使用 MWIT1:1 端口 (CEC 认证) A/V 端口 MWIR1:1 端口 (CEC 认证) 106 克 (MWIT1) 重量:...
  • Page 77 简体中文 视频格式 视频格式 垂直刷新 颜色空间 采样 支持 是 4:2:2 YCbCr 480i 是 59.94 Hz 4:4:4 (1440 x 480i) 是 4:4:4 是 4:2:2 480p/480pw YCbCr 59.94 / 60 是 (640 x 480p/ 4:4:4 720 x 480p) 是 4:4:4 是 4:2:2 YCbCr 576i 是...
  • Page 78 简体中文 是 4:2:2 YCbCr 23.976 / 是 4:4:4 24 Hz 是 4:4:4 是 4:2:2 YCbCr 1080p 是 50 Hz 4:4:4 (1920 x 1080p) 是 4:4:4 是 4:2:2 YCbCr 59.94 / 60 是 4:4:4 是 4:4:4 是 59.94 Hz 4:4:4 (640 x 480) SVGA 是...
  • Page 79 简体中文 音频格式 音频采样率 LPCM 2/6/8-通道 LPCM 2-通道 44.1 88.2 176.4 支持 支持 *规格如有更改,恕不另行通知。 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 80 简体中文 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 81 IC Statement: This device complies with Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
