MobileAction Q-Band HR3 User Manual

Device Overview

Reversible Wristband
How to wear your Q-Band HR3 ?
1
Wear Q-Band HR3 on your wrist
Put on the wristband with the screen facing up
and the band wrapped around your wrist. Slide
one band through the loop of the other band, and
align the clasp along the band to find the holes
where best fit the clasps.
Video Demo:
http://ww2.voiis.com/igotu-life/wear/Q-Band-HR-Plus
4

Charge your Q-Band HR3

2
1
Prior to charging Q-Band HR3, make sure it is securely placed inside the
charging box with the lid closed, and the USB connector is plugged in to a
computer or a power source via a power adapter.
Important Notice:
The product is shipped with the screen and keys locked, and will be unlocked once it is
charged via USB connection. Please make sure the "Charging" icon appears while it is
being charged, indicating the device is connected correctly and getting charged.
Video Demo:
http://ww2.voiis.com/igotu-life/charge/Q-Band-HR
Touch Button
Optical Sensor
2
Fasten Q-Band HR3 with clasp
Video Demo
Squeeze both clasps into the holes on the wristband
until you hear a click, indicating the band is securely
fastened.
Note: The wristbands are both replaceable and
reversible.
(1)Push
4
3
Charging icon
HR3
(
Q-69HR
5

Change the wristband

1
(2)Up
2
1. Remove the wristbands by sliding out both bands from the slots on both sides
of the core.
2. Insert the new bands into the slots on both sides of the core.
Important Notice:
Failure to follow the instructions above might cause damage to the device.
( User Manual
Core
Metallic contact for charging
3
Detecting your Heart Rate
1. Please make sure the wristband is worn as tightly as
possible on the wrist without any discomfort, in order
to enhance the accuracy of heart rate signals that
are detected.
Wear the wristband three fingers away from your
2.
wrist. When "-----" text appears on the screen,
please stay still briefly for about 10 seconds to obtain
a heart rate reading.
EN
Clasp
