DATASHEET
MasterLogic-200
High Speed Counter
2MLF-HO2A
2MLF-HD2A
10310000614 Printed in Korea
For more information on MasterLogic PLCs , contact your nearest Honeywell office
Australia
Japan
Singapore
Honeywell Ltd.
Honeywell Inc.
Honeywell Pte Ltd.
Phone : (61) 2-9353-4500
Phone: (81)3-5440-1395
Phone: (65) 6355-2828
Fax : (61) 2-9353-7677
Fax: (81)3-5440-1368
Fax: (65) 6445-3033
China
South Korea
Thailand
Honeywell (Tianjin) Ltd. – Beijing
Honeywell Co., Ltd.
Honeywell Systems Ltd.
Phone: (86-10) 8458-3280
Phone : (82) 2-799-6114
Phone: (662) 693-3099
Fax: (86-10) 8458-3102
Fax : (82) 2-792-9015
Fax: (662) 693-3085
Honeywell (Tianjin) Ltd. – Shanghai
Malaysia
Taiwan
Phone: (86-21) 6237-0237
Honeywell Engineering Sdn Bhd.
Honeywell Taiwan Ltd.
Fax : (86-21) 6237-3102
Phone: (603) 7958-4988
Phone: (886) 2-2245-1000
Fax: (603) 7958-8922
Fax: (886) 2-2245-3241
Indonesia
PT Honeywell Indonesia
New Zealand
For Countries (SE Asia) Listed
Phone : (62) 21-535-8833
Honeywell Ltd.
below, call Honeywell Singapore
Fax : (62) 21-5367-1008
Phone: (64-9) 623-5050
Office
Fax: (64-9) 623-5060
Pakistan, Cambodia, Laos,
India
Myanmar, Vietnam and East Timor
Honeywell Automation India Ltd.
Philippines
Phone: (91) 20-5603-9400
Honeywell Systems Inc.
For Countries Listed below,
Fax: (91) 20-5603-9800
Phone: (63-2) 633-2830
call Honeywell India Office
Fax: (63-2) 638-4013
Bangladesh, Nepal, and Sri Lanka
Honeywell Co., Ltd.
Honeywell Process Solutions
17F, Kukje Center Building, 191 Hangangro-2ga,
Yongsan-gu, Seoul 140-702, Korea
Tel : 82-2-799-6114 / Fax : 82-2-792-9015
Email : MasterLogic@Honeywell.com
10310000614 Printed in Korea
Safety Precautions
► Safety Precautions is for using the product safe and correct in order to prevent the accidents and
danger, so always follow the instructions.
► The precautions explained here only apply to the 2MLF-HO2A and 2MLF-HD2A module. For safety
precautions on the PLC system, refer to the MasterLogic-200 CPU User's manual.
► The precautions are divided into 2 sections, 'Warning' and 'Caution'. Each of the meanings is
represented as follows.
If violated instructions, it may cause death, fatal injury or considerable
Warning
loss of property.
Caution
If violated instructions, it may cause a slight injury or slight loss of
products
► The symbols which are indicated in the PLC and User's Manual mean as follows
Gives warnings and cautions to prevent from risk of injury, fire, or malfunction.
Gives warnings and cautions to prevent from risk of electrical shock.
► Store this datasheet in a safe place so that you can take out and read whenever necessary.
Always forward it to the end user.
Warning
Do not contact the terminals while the power is applied.
Risk of electric shock and malfunction.
Do not drop or insert any metallic object into the product.
Risk of fire, electric shock and malfunction.
Do not charge, heat, short, solder and break up the battery.
Risk of injury and fire by explosion and ignition.
Caution
► Before wiring the PLC, ensure to check the rated voltage and
terminal arrangement for the module before wiring work.
Risk of electric shock, fire and malfunction
► Tighten the screw of terminal block with the specified torque range.
Risk of fire and electric shock if the terminal screw looses.
► Use the PLC in an environment that meets the general
specifications contained in this datasheet.
Risk of electrical shock, fire, erroneous operation and deterioration of the PLC.
► Be sure that external load does not exceed the rating of output module.
Risk of fire and erroneous operation.
► Do not use the PLC in the environment of direct vibration
Risk of electrical shock, fire and erroneous operation.
► Do not disassemble, repair or modify the PLC.
Risk of electrical shock, fire and erroneous operation.
► When disposing of PLC and battery, treat it as industrial waste.
Risk of poisonous pollution or explosion.
Precautions for use
► Do not install in any places other than PLC controlled place.
► Ensure that the FG terminal is grounded with class 3 grounding which is dedicated to the PLC.
Otherwise, it may cause disorder or malfunction of PLC
PLC
Others
PLC
Others
PLC
Others
< Best >
< Good >
< Bad >
► Connect expansion connector correctly when expansion modules are needed.
► Do not detach PCB from the case of the module and do not modify the module.
► Turn off the power when attaching or detaching module.
► Cellular phone or walkie-talkie should be farther than 30cm from the PLC
► Input signal and communication line should be farther than minimum 100mm from a high-tension
line and a power line in order not to be affected by noise and magnetic field.
Before handling the product
Before using the product, read the datasheet and the User's manual through to the end carefully in
order to use the product efficiently.
MasterLogic-200 User's Manual
Name
Code
2MLK-CPUH/CPUS User's manual
10310000648
MasterLogic-200 Basic instruction manual
10310000649
MasterLogic-200 Software manual
10310000650
2MLF-HO2A/HD2A User's manual
10310000618
1. Introduction
High speed counter module designed for MasterLogic-200 series is used to count high
speed pulses from the encoder and there are two types of the pulse type 2MLF-HO2A
and the line drive type 2MLF-HD2A.
2. General specifications
General specifications of MasterLogic-200 series are as specified below.
No
Item
Specifications
Operating
1
0℃∼+55℃
temp.
Storage
2
-25℃∼+70℃
temp.
Operating
3
5∼95%RH, no dew allowed
humidity
Storage
4
5∼95%RH, no dew allowed
humidity
For discontinuous vibration
Frequency
Acceleration
Amplitude
Number
10≤f< 57㎐
-
0.075mm
57≤f≤150㎐
9.8m/s2(1G)
-
Vibration
5
proof
For continuous vibration
Each 10 times in
X,Y,Z directions
Frequency
Acceleration
Amplitude
10≤f< 57㎐
-
0.035mm
57≤f≤150㎐
4.9m/s2(0.5G)
-
* Max. impact acceleration: 147㎨(15G)
6
Impact proof
* Authorized time: 11㎳
* Pulse wave : Sign half-wave pulse (Each 3 times in X,Y,Z directions)
Square wave
±1,500V
impulse noise
Static electric
Voltage : 4kV(contact discharging)
discharging
Radiation
electromagnetic
27 ~ 500MHz, 10 V/m
7
Noise proof
field noise
Digital/
Class
Power module
Analog I/O
Fast Transient
communication interface
/ burst noise
Voltage
2kV
1 kV
Ambient
8
No corrosive gas or dust
conditions
Operating
2,000m or less
height
Pollution
10
2 or less
level
11
Cooling type
Natural air cooling
3.
Performance specifications
Performance specifications of high speed counter module are as specified below.
Item
2MLF-H02A
Signal
Voltage input
Count
Input type
(Open Collector)
Input signal
Signal level
DC 5/12/24V
Max.count speed
200Kpps
Number of channels
Count range
Signed 32-bit (-2,147,483,648 ~ 2,147,483,647)
Linear count (if 32-bit range exceeded, carry/borrow occurs)
Count type
(program setting)
Ring count (repeated count within setting range)
1-phase input
Input mode
2-phase input
(program setting)
CW/CCW input
Voltage
Signal type
Increasing/decreasing operation setting by B-phase input
1-phase input
Increasing/decreasing operation setting by program
Up/down
2-phase input
Automatic setting by difference in phase
Setting
A-phase input: increasing operation
CW/CCW
B-phase input: decreasing operation
1-phaseinput
1/2 multiplier
(program setting)
Multiplier
2-phaseinput
1/2/4 multiplier (Program setting)
function
CW/CCW
1-multiplier
Sign
Preset command input, additional function command input
Control input
Sign level
DC 5V/12V/24V(select terminal)input type
Related
specifications
Sign type
Voltage
Output points
2-point/channel(for each channel): terminal output available
Select single-compared(>, >=, =, =<, <) or section
External output
Type
compared output (included or excluded) (program setting)
Output type
Open collector output(Sink)
A-phase, B-phase, Preset command, additional function
Input sign
Function to
command
Output sign
OUT1, OUT2
display
operation
Operation
status
Module Ready, A/B phase pulse input status
status
To be set through program
Count enable
(count available only in enable status)
Preset function
To be set through terminal or program
Additional functions
Count clear, count latch,
IEC 61131-2
(program setting)
Section count (time setting value: 1~60000ms)
M
t f i
Terminal
I/O Occupied points
Fixed point assignment: 64, Variable point assignment: 16
Internal consumed current
270 mA
Weight (g)
IEC 61131-2
-
IEC61131-2,
IEC61000-4-2
IEC61131-2,
IEC61000-4-3
IEC61131-2,
IEC61000-4-4
Specification
2MLF-HD2A
A-phase, b-phase
Differential input
(Line Drive):
RS-422A Line Drive/
HTL LEVEL Line Drive
500kpps
(HTL input is 250kpps)
2
t f
40-pin connector
270 mA
90g
