Article VI. Tec h Pr o C onnecti ons
Equipment Databus
Connection
The Genie Tech Pro Link includes a
4-pin connector in its handle for
Power, Ground and CAN databus
connection with Genie control
systems.
The harness power connection also
charges the internal battery.
USB Connections
USB Connection - Type A
A standard USB thumb drive may
be connected to download machine
data or upload new machine
software.
USB Connection - Micro B
Use the USB cable included, to
charge the internal battery.
Databus Harness Pin-out
Equipment Circuit
Battery Voltage 12V / 24V
Ground
CAN High
CAN Low
Part No. 1276689GT
Tech Pro Connections
Equipment Connector
Locations
Compatible Genie equipment will be
identified by the Tech Pro Link logo
located next to one or more round 5
pin connection points.
4 Pin Connector
Tech Pro™ Link
User Guide
5 Pin Connector
1
2
3
4
A
B
D
E
7
