- Page 1 Work bench E, 4 E and 4 E FIFO User guide...
-
Page 2: Table Of Contents
Contents 1. General safety information 1.1 Correct use 1.2 Improper use 1.3 Personnel qualifications 1.4 Warning symbols 1.5 CE declaration 2. Product description 3. Operating data 4. Setting up the height-adjustable work bench 4.1 Environmental considerations 4.2 Levelling the work bench 5. -
Page 3: General Safety Information
Use only item products that are in perfect working order. The height-adjustable work bench is not suitable for lifting people. Failure to use original spare parts will invalidate the product warranty! 5. -
Page 4: Correct Use
ƒ The electrical, height-adjustable work bench is used only in a fixed, station- safety requirements set out in this document. The electrical, height-adjustable ary location, work bench is a technical item of work equipment and is not intended for ƒ You integrate the electrical, height-adjustable work bench into its surround- private use. -
Page 5: Ce Declaration
1.5 CE declaration... -
Page 6: Product Description
2. Product description Work bench 4 E FIFO The item work bench 4 E FIFO – a logical and efficient combination of work bench and FIFO rack. Strong and steady with a customisable configuration. Work bench E Two table columns at the rear of the table, table top positioned on stable steel supports. An electrical, height-adjustable work bench that is easy to operate and incorporates a control system with a memory function. - Page 7 ≤ 640 The Upright The Overhang Work Bench E Table Top material Optional attachments Dimensions plastic coated high pressure high pressure beech multi-ply Upright Overhang Cable Duct E a x b mm s = 25 mm laminate laminate/ESD s = 40 mm...
-
Page 8: Operating Data
ƒ Selection and installation of the appropriate components ensures suitability for use in areas where electrostatic charges pose significant hazards. We Table 4 E / 4 E FIFO 4 columns 4000 N distributed recommend that you consult your item representative. Perm. bending moment in travel mode 140 Nm Speed... -
Page 9: Electrical Connections For Height-Adjustable Tables
In particular, cables must not be clamped in the foot area of the table columns (safety area of approx. 10 mm around the ƒ The control system may only be used with item table columns. table column feet). -
Page 10: Start-Up
6. Start-up The basic function of the control system is to raise or lower the table. Both The height-adjustable work bench can be damaged if it comes into of these functions can be performed via the table’s manual controls (before contact with obstacles, and the service life may be shortened. -
Page 11: Functions
7. Functions 7.1 On-time limiter The electronic system monitors how long the table columns have been active. If the maximum permissible time is exceeded, the electronics will not permit any further movement in the table columns. This protects the power pack, control system and drives against overload. -
Page 12: Setting The Upper And Lower Travel Limits
7.7 Setting the upper and lower travel limits The travel distance can be electronically limited to prevent collision with any potential obstacles in the travel range. For reference purposes, the lower mechanical limit switch must stay within range. Press the “M” button eight times to enter setting mode. An audible signal indicates the setting mode is active. Press the UP or DOWN button to move the table columns to the desired upper or lower travel limit. -
Page 13: Error Messages On The Manual Controls
8. Error messages on the manual controls Cause Solution Reset – compulsory Please RESET the system (see 6.1). Movement lock engaged Press the “M” button for 10 seconds. A 6F Travel monitor 1. Remove the load and move the table a short distance in the opposite direction. -
Page 14: Maintenance And Servicing Work
9. Maintenance and servicing work There are no maintenance requirements associated with the height-adjustable work bench. See Section 9 for warning/error messages and solutions. 10. Disassembly and replacement of parts Touching live parts can lead to an electric shock, causing serious injuries or death. ƒ... -
Page 15: Annex
12. Annex 12.1 Declaration of incorporation for the table columns... -
Page 16: Specification Plates
Serial number, Table Column 2 Manufactured by Date www.item24.com You find the Notes on Use and Installation online, in the download section for this product. item Industrietechnik GmbH Friedenstrasse 107-109 42699 Solingen Germany Phone +49 212 6580 0 +49 212 6580 310 info@item24.com...
