Features
Power consumption: 220w Max
LED resource: 1x 200w COB white
or warm white color(3200k or 6500k)
Control: 3 DMX channels
LCD display + 4 soft keys 4
selectable dimming curves
master/slave; stand alone
Optical group: 5200 LUx at 4meter
Beam Angle: 10/19/26/36/50°.
Body in plastics: IP20 protection
rating. Operating comperature: -20 °C
t 40 °C measurements:
64.5x28x22(cm) Weight: 8.0KG
LED Profile light
E V - 0 6 0 1 2 0 1 8
LED Profile light
Operating Manual
Advertisement
Table of Contents
Summary of Contents for Borealis BLP200B-W
- Page 1 LED Profile light Features Power consumption: 220w Max LED resource: 1x 200w COB white or warm white color(3200k or 6500k) Control: 3 DMX channels LCD display + 4 soft keys 4 selectable dimming curves master/slave; stand alone Optical group: 5200 LUx at 4meter Beam Angle: 10/19/26/36/50°.
- Page 2 LED Profile light 1.Packing List LED Spotlight LED Profile light Operating Manual 10.Notes Power Cable Manual 2.Measurements Unit mm 3.Wiring Diagram To next Power Power cable Power Input DMX Signal cable AC100~240V To next DMX Signal 50-60Hz The back DMX Controller EV-06012018...
- Page 3 LED Profile light 9.Function DMX Mode LED Profile light 4.Illumination Diagram Distace15m Distance10m DMX Address Allocation 001-512 Distance8m Distance6m DMX 3 Channels Distance 4m Dim4 DIMMING STROBE 100% Dim4 Dim3 LED Profile light Dim2 CCT 3200K Illumination Center/Lux 3350 1490 Beam angle 19 Dim1 Beam Diameter/cm...
- Page 4 LED Profile light LED Profile light 7.Technical parameters 1xWhite200W LED(3200K),CRI>90;(5600K LED is available) LED Source 9.Menu Beam angle 19,26( Beam angle 36 , 50 available) Optical group with high-efficiency optical system Control 3 DMX channels;LCD display+4 soft keys;4 selectable dimming curves DMX Mode MENU Connection...
