VisualEyes™ 505 Instructions for Use - US
VisualEyes™ remote control
3.5.7
The remote control provides a hand held option for controlling and performing tests within the
VisualEyes™ suite. The operator can operate the software using the remote control while remaining at
the patient's side during testing. The remote control's receiver connects to the PC via a USB port, while
the remote control connects to the receiver using 2.4 GHz rf transmission.
Figure 3.5.6 VisualEyes™ Remote Control
1. Top button:

Centers eyes (top mount goggles only)
2. Right button:

Goes forward in the software

If the test is running, it stops the test

If in playback mode, the button will advance to the next test in the list
3. Left button:

Stops the test
4. Bottom button:

Turns on/off the fixation light during a test
3.5.8

External room camera

Figure 3.5.7 USB room camera
The room camera is an external device connected to the computer's USB port. It serves to record the
external environment and patient testing process from the beginning. The external room camera provides
additional flexibility in recording the testing procedure, though the laptop's integrated observation camera
can be used with orienting the computer towards the patient.
Page 12
