- Page 1 S-Power PERFORMANCE SERIES Simply the Best Heat Pipe Collectors Innovation prize 2008 for the S-Power vacuum tubes. From glass factory to finished high performance vacuum tubes, HighTech "Made in Germany". η Installation instructions Heat Pipe Solar Keymark...
- Page 2 Simply the Best Prior to installation, please check for updates to this document at www.stiebel-eltron-usa.com/install.html S-Power Performance Series Instruction Manual Rev. April 2012...
- Page 3 SAFETY INSTRUCTIONS WARNING To reduce the risk of injury, the user must read and understand the operation manual before installing or using this product. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 4: General Safety Rules
GENERAL SAFETY RULES WORK AREA (Especially when working on the roof) » Keep the work area clean and well organized. » Keep bystanders, children and visitors away from the work area while installing this product. Distractions can cause one to lose control and personal injury can occur. »... - Page 5 Falling when working on the roof The Stiebel Eltron S-Power Performance Series HP evacuated-tube solar collector must be installed and put into operation in accordance with this instruction manual. It must be used exclusively for the described purpose. If used other than the described purpose (abusive use), dangers for persons can arise and the collector can be damaged.
-
Page 6: Lightning Protection
The Stiebel Eltron S-Power Performance Series HP evacuated-tube solar collector must be mounted and operated according to theapproved safety rules and technical regulations, of each locale. During assembly, workers must adhere to the respective national regulations for employee protection (e.g. OSHA) and accident prevention. This is especially important when working on the roof. - Page 7 SAFETY INSTRUCTIONS & REQUIREMENTS FOR ROOFTOP ASSEMBLY Risk of Burning WARNING » The metal parts of the collector can become very hot when exposed to the sun even on cloudy days and can cause burns when touched! Do not leave a collector unprotected to the sunlight after unpacking it. Install the roof assembly on a cloudy day and preferably not at noontime or shade the collector with a light blocking material.
- Page 8 AT LEAST TWO PEOPLE ARE REQUIRED FOR THE ROOF INSTALLATION. The planning of the installation and the installation on the roof as well as the setup of the Stiebel Eltron S-Power high performance heat pipe collector may only be done by persons who are familiar with and can carry out a proper installation due to their qualifica- tion and/or certification.
- Page 9 Please make sure that the tubes are oriented towards the sun. The min. and max. installation angle should be from 20° to 90°. 90 ° Tile roof 20 ° Connection Facade Stiebel Eltron, Inc. 17 West Street West Hatfield, MA 01088 Telephone: 800.582.8423 Fax: 413.247.3369 info@stiebel-eltron-usa.com...
- Page 10 Set the cap profile in the façade or elevated track. For wall/façade installation, the cap profile is to be vertically mounted. Wall/facade, flat roof and corrugated metal installation (roof and wall) S-Power SP-20 S-Power SP-20 25.25 inches — 37.75 inches S-Power SP-30 S-Power SP-30 38.75 inches —...
- Page 11 Simply the Best Installation measurements for the heatpipe collector » Tiled roof installation: Header S-Power SP-20 S-Power SP-20 25.25 inches — 37.75 inches S-Power SP-30 S-Power SP-30 38.75 inches — 55.5 inches 76.75 inches Footer S-Power SP-20 S-Power SP-20 25.25 inches — 37.75 inches...
- Page 12 Collector casing and drum must be mounted straight and flush with each other. Insert the Stiebel Eltron S-Power high performance heatpipe tube into the rubber rings, which have to be lubricated beforehand with soap. Place the safety rubber ring on top of the glass metal connection.
- Page 13 Screw upper casing to the supporting bracket. » Recommendation: The casing may be mounted to the supporting bracket even before inserting the tubes, as the tube is lockable by itself. Stiebel Eltron, Inc. 17 West Street West Hatfield, MA 01088 Telephone: 800.582.8423 Fax: 413.247.3369 info@stiebel-eltron-usa.com...
- Page 14 Following this pull the insula- tion over the hose. Screw on the connections, pull tight with a spanner and push the insulation over the corrugated hose. Stiebel Eltron, Inc. 17 West Street West Hatfield, MA 01088 Telephone: 800.582.8423 Fax: 413.247.3369 info@stiebel-eltron-usa.com...
- Page 15 DO NOT ATTEMPT TO INSTALL THIS PRODUCT IF YOU HAVE NOT READ THE INSTALLATION MANUAL AND ARE NOT EXPERIENCED WITH SO- LAR THERMAL COLLECTORS MADE BY STIEBEL ELTRON. YOU SHOULD ALWAYS HIRE AN EXPERIENCED NABCEP CERTIFIED SOLAR THERMAL INSTALLATION CONTRACTOR. THE INSTALLATION CONTRACTOR IS RESPONSIBLE FOR THE MECHANICAL STABILITY AND STRENGTH OF ALL INSTALLED INTERFACE CONNECTIONS TO THE BUILDING/BUILDING’S ENVELOPE.
- Page 16 Simply the Best We are available for questions concerning the installation of our high quality vacuum tube collectors at any time: Stiebel Eltron, Inc. 17 West Street West Hatfield, MA 01088 Phone: 800.582.8423 Fax: 413.247.3369 E-mail: info@stiebel-eltron-usa.com Internet: www.stiebel-eltron-usa.com Stiebel Eltron, Inc.
