Summary of Contents for Junilabs Juniline Five
- Page 1 Juniline Five Line preamplifier The Juniline five is the culmination of an idealist dream: to propose a high quality level preamplifier at an attractive price. To reach this ambitious target, we integrate many inno- vations that you can only find in our realizations.
-
Page 2: Starting Operation
Utilization The Juniline five is a four inputs stereo line preamplifier. We think simplicity of usage and ro- bustness. Commands were simplified: input selector and control level. We can't do simpler; the essential is inside... Power ON LED Input selector... -
Page 3: Technical Specifications
Connecting The Juniline five integrates 4 high level inputs allow connecting sources like CD, DAC, DVD, Tuner... It integrates 2 outputs allow connecting two amplifiers in bi-amplification mode. The fol- lowing schematic illustrate the connection. Technical specifications Inputs: 4 stereo RCA inputs... - Page 4 (hard and soft); the trans- former is damped with sand and absorbers. This allows a high definition level and comfortable bass. Using of different materials for a better vibration management. Damped capacitors Anti vibratory material fixed on the top chas- sis box. www.junilabs.com...
- Page 5 500VA transformer and many polypropylene or polypropylene film capacitors (higher quality). Into the Juniline five, we put an active shield toward positive ionic and an evolution of our "shared current power supply". The regulators are powered with high tension, like valves circuits, but with lower tension.
- Page 6 Green Earth is available in rear panel. It is internally wired to audio ground. You can improve Juniline Five's audio rendering by linking the Green Earth to: A virtual ground, (see picture) • A Main Earth via a big cable, •...
