- Page 1 8006 Installation and Use Manual BODET SA 1 rue du Général de Gaulle 49340 Trémentines I France Tél +33 241 71 72 00 www.bodet-sport.fr Fax +33 241 71 72 01 When receiving goods please check nothing is broken otherwise make a claim near shipping company.
-
Page 2: Table Of Contents
- It is prohibited and dangerous to immerse the scoreboard in to water or clean it with a water jet. - Installation ground connection as per EE or EN (earth/earth or earth/neutral) power supply diagram. - Bodet accepts no responsibility for any use not in compliance with these instructions. - Any modification to the product will invalidate the guarantee. -
Page 3: I - Checking The Material Supplied
Diagram of HF wireless installation: 8025 8006 8006 Possession time keyboard Secondary keyboard Main keyboard The communication with the 8006 shot clocks is handled by the main keyboard. Maximum distance for HF communication between the keyboard and the shot clock panels is 100 metres. -
Page 4: Ii - Mounting Behind Basetball Backboard
Ø10 flat washer With 1x H M10x90 screw and 1x HU M10 nut. HU M10 nuts III - Wall mounting 1/ Install the 8006 on the wall using 4 screws and rawlplugs respecting the dimensions between the bracket holes as shown below:... -
Page 5: Iv - Dip Switches Setting
↑ off ↓ off ↓ ADVICE: number the 8006 display panels as n°2 and n°3 (the main scoreboard being n°1). the other panels (2nd scoreboard, additional horn...) will be numered n°4, n°5... V - Electrical connections 1/ Open the access door (page 4) 2/ Punch a hole in the membrane of the grommet (B) and feed the power cord through it. -
Page 6: Vi - Wired Connection
VI - Wired connection Main scoreboard n°1 Display 24sec Display 24sec n°2 n°3 To other scoreboards (other main scoreboard, horn case...) Scorepad Possession time keyboard 1/ For an installation with one or several boards, connect a telephone cable 1 pair 0.9 mm RT+ and RT- (C) on every board. And connect the other side of the cable to the connection box (B). -
Page 7: Vii - Use Of Possession Time Keyboard
This parameter is not saved in case of power loss or if the Time Pad is disconnected after a game. Does not work with the RESET 14s (8) key. 8006 display panel brightness adjustment 1/ Press the (+5) key of the possession keyboard during 3 sec. The keyboard LED screen display the current luminosity level from 1 to 5.
