Orange Amps Fur Coat User Manual

IMPORTANT

The​ ​ F ur​ ​ C oat​ ​ c an​ ​ b e​ ​ p owered​ ​ b y​ ​ 9 ​ ​ o r​ ​ 1 2V​ ​ D C.​ ​ A ​ ​ r egulated
DC​ ​ p ower​ ​ s upply​ ​ f itted​ ​ w ith​ ​ a ​ ​ ​ c entre​ ​ n egative​ ​ p lug
(2.1mm)​ ​ ​ m ust ​ ​ b e ​ ​ u sed ​ . ​ ​ R unning​ ​ a t​ ​ 1 2V​ ​ w ill​ ​ i ncrease​ ​ t he
headroom​ ​ a nd​ ​ t he​ ​ o utput​ ​ v olume​ ​ a vailable.
9V​ ​ B attery​ ​ O peration
To replace the battery, unfasten the four screws on the
base and secure the new battery in the battery clip,
making​ ​ s ure​ ​ t o​ ​ o bserve​ ​ t he​ ​ b attery's​ ​ p olarity​ ​ ( +​ ​ / ​ ​ - ).
The Fur Coat is a fully controllable old school fuzz pedal
inspired by the Foxx Tone Machine. Always place it first in
the signal chain with no buffer as a passive guitar pickup
as part of the circuit. When running the Fur Coat into the
clean channel, the EQ should be set to halfway or lower.
If​ ​ i nto​ ​ t he​ ​ d irty​ ​ c hannel,​ ​ s et​ ​ i t​ ​ h igher.
If the octave level is set to less than flat out, the octave
can​ ​ b e​ ​ c ontrolled​ ​ u sing​ ​ t he​ ​ g uitar​ ​ v olume.
Depending on your location, fuzz pedals can pick up radio
signals,​ ​ t his​ ​ i s​ ​ c ompletely​ ​ n ormal.
