for Paradox alarm system
Version.
Date
1.00
14-AUG-2017
2.00
08-FEB-2018
2.01
20-MAR-2018
© ELAUSYS SPRL
User Manual
EVO-KNX – Paradox KNX Interface
ELAUSYS
EVO-KNX
KNX Interface
User Manual
Document history
Author
NDE
NDE
NDE
This document cannot be reproduced fully or partially without written authorization
Comment
First issue
Update firmware to standard Elausys "Alarm System
Gateway V2.00" ETS Application
Add details on configuration of the PRT3 interface
Doc.Ref :
EVO-KNX-UM
Revision :
Page :
1 of 23
2.01
Advertisement
Table of Contents
Summary of Contents for ELAUSYS EVO-KNX
-
Page 1: User Manual
Document history Version. Date Author Comment 1.00 14-AUG-2017 First issue Update firmware to standard Elausys “Alarm System 2.00 08-FEB-2018 Gateway V2.00” ETS Application 2.01 20-MAR-2018 Add details on configuration of the PRT3 interface © ELAUSYS SPRL This document cannot be reproduced fully or partially without written authorization... -
Page 2: Table Of Contents
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 2 of 23 TABLE OF CONTENT INTRODUCTION OVERVIEW ..USAGE & LIMITATION ....................4 ..SOFTWARE ......................... 4 ..CONNECTION DIAGRAM ................... 5 ..CONFIGURING THE PRT3 INTERFACE ..............5 PARAMETERS .. -
Page 3: Introduction
Page : 3 of 23 1. INTRODUCTION The KNX interface module EVO-KNX is a KNX gateway for the Paradox EVO alarm systems. It enables bidirectional communication with the alarm system using the RS232 communication module (PRT3) from Paradox. It allows integrators to take advantage of a fully integrated alarm system including KNX scenarios, automatic lighting using the motion detectors, arming or monitoring the system using a KNX visualization. -
Page 4: Overview
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 4 of 23 2. OVERVIEW USAGE & LIMITATION This interface is intended to be used with a PARADOX EVO or DGP series alarm system. The system must be equipped with a PRT3 module for RS232 communication. -
Page 5: Connection Diagram
No additional component or wiring is required. The PRT3 module must be configured at 9600 baud. CONFIGURING THE PRT3 INTERFACE To enable the communication with the EVO-KNX module, the following options must be selected in the PRT3 configuration: © ELAUSYS SPRL... - Page 6 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 6 of 23 In the PRT3 tab ”Options”: © ELAUSYS SPRL This document cannot be reproduced fully or partially without written authorization...
- Page 7 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 7 of 23 In the tab “Areas and Zones”, select the areas and zones that should be enabled in the interface: © ELAUSYS SPRL This document cannot be reproduced fully or partially without written authorization...
- Page 8 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 8 of 23 If virtual inputs and PGM need to be used, they should be enabled in the respective tabs: © ELAUSYS SPRL This document cannot be reproduced fully or partially without written authorization...
-
Page 9: General Settings
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 9 of 23 3. PARAMETERS The KNX interface parameters are defined in the “parameters” tab of the device, in the ETS project. GENERAL SETTINGS The following parameters are defined in the General section of the device parameters:... - Page 10 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 10 of 23 Use Virtual inputs Not used (default) When this parameter is set to “Used”, ▪ Used the virtual inputs group objects are ▪...
-
Page 11: Pgm
Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 11 of 23 PG Status must be enabled in the general parameters to enable PGM status group objects. Depending on the general parameter “Number of PG”, 16 or 32 PGs are listed in the group objects. The Paradox alarm system however uses a maximum of 30 PGM. -
Page 12: Area
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 12 of 23 AREA Depending the general parameter “Number of areas”, up to 4 areas are listed in the group objects. Each area can be controlled by using the 3 group objects: Arm, partial arm or disarm. Several statuses are available and have a dedicated group object. -
Page 13: General
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 13 of 23 4. COMMUNICATION OBJECTS GENERAL General communication objects of the device. NAME DESCRIPTION Sends 0 when the module is operating normally, sends an error code when Module status applicable. -
Page 14: Zone
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 14 of 23 ZONE Each ZONE has 1 Group Objects (GO) for the status to KNX. NAME DESCRIPTION Zone status Zone x Status This chapter details what GO are available for each ZONE. The same GO applies to all other ZONE (x = 1 to 96). - Page 15 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 15 of 23 Area x status Area x – Fire alarm Area x status Area x – Siren ON Area x status Area x – Panic alarm Area x status Area x –...
-
Page 16: Group Object List
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 16 of 23 GROUP OBJECT LIST Name Function Size Flags Type ID Type Name Range Description Module status Status code 1 byte C R - T - 20.011... - Page 17 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 17 of 23 Name Function Size Flags Type ID Type Name Range Description Virtual input 16 Open/Close 1 bit C - W - - 1.001 DPT_Switch 0..1...
-
Page 18: Configuration
ELAUSYS devices are configured using the ETS tool. You should first download and install the free version of ETS tool before you continue. The EVO-KNX Interface must be assigned a physical address on the KNX network. Assign a free address to the module, in our example we choose 1.1.50. - Page 19 Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 19 of 23 Enable the required group objects and select the number of PG, zone and areas to be used. Note that the Paradox system is limited to 30 PGMs and only PGM status is available (no PG control).
-
Page 20: Group Objects
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 20 of 23 GROUP OBJECTS A group address (GA) must be assigned to each group object (GO) needed by the application. Open the Group Objects tab of the device and assign a GA to the object scene, PGM, zones, virtual inputs and areas as needed. - Page 21 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 21 of 23 Virtual inputs: Power supply status: © ELAUSYS SPRL This document cannot be reproduced fully or partially without written authorization...
- Page 22 User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 22 of 23 Zone status: When GO and parameters are all configured, download the KNX Interface application to the device. The first download requires to press the programming button on the device to set the device in KNX programming mode then perform a full download.
-
Page 23: Firmware Version
User Manual Doc.Ref : EVO-KNX-UM Revision : 2.01 EVO-KNX – Paradox KNX Interface Page : 23 of 23 6. FIRMWARE VERSION This user manual and related ETS application is valid for firmware versions V2.00 and above. A “Firmware” group object is available on the device to read the firmware version as a string. It is also automatically sent at power up.
