OWNER'S MANUAL
Tofinou 9.5
This document comprises 58 pages, numbered 1 - 28, plus 30 pages of drawings and diagrams.
Tofinou 9.5
ENGLISH 08-10-2010
Page 1/58
LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE)
Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tofinou 9.5 and is the answer not in the manual?

Questions and answers

Rob Male
May 26, 2025

I have a Tofinou 9.5 delivered Jan 2012. Can the rudder shaft be removed from the rudder? If not, is there a way of repairing a worn shaft? Do you have a procedure for replacing the keel lifting line?

0

Summary of Contents for Latitude 46 Tofinou 9.5

  • Page 1 This document comprises 58 pages, numbered 1 - 28, plus 30 pages of drawings and diagrams. Tofinou 9.5 ENGLISH 08-10-2010 Page 1/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 2 This yacht is covered by the guarantee terms given on page 25 of this Owner's Manual. This guarantee runs from __________ (today's date) Signature: Tofinou 9.5 ENGLISH 08-10-2010 Page 2/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 3: Table Of Contents

    Page 54 12. Lifting diagram Page 56 13. List of attached documents Page 58 Tofinou 9.5 ENGLISH 08-10-2010 Page 3/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 4: Introduction

    Tofinou 9.5 ENGLISH 08-10-2010 Page 4/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 5: Design Category Of Yacht

    This sailing capability is equally dependent on the skills of the crew, their physical capacities, the maintenance of the boat and its equipment. So always take care before putting to sea. LATITUDE 46 is not able to guarantee perfect functioning of the boat in exceptional sea conditions (violent storms, hurricanes, cyclones, waterspouts,...) DESIGN CATEGORIES...

  • Page 6: Specifications

    Water capacity Fuel capacity Miscellaneous Max. recommended loading (kg): Indicated on information plate Tofinou 9.5 ENGLISH 08-10-2010 Page 6/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 7: Electrical Systems

    Location of circuit-breakers and isolator for lifting keel winch (on port bulkhead beneath cockpit). 12V electrical panel Tofinou 9.5 ENGLISH 08-10-2010 Page 7/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 8 55 Ah engine battery stowed under starboard cockpit seat 105 Ah auxiliary battery stowed under port cockpit seat Tofinou 9.5 ENGLISH 08-10-2010 Page 8/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 9: Inventory

    2 self-tailing winches 4 triple jammers for halyards Mainsheet on 2-speed car Boom vang Tofinou 9.5 ENGLISH 08-10-2010 Page 9/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 10: Drain And Sanitation System

    It is intended to remove water coming from spray, leaks from seacocks or any other moderate leaks. Electric bilge pump at bottom of companionway Tofinou 9.5 ENGLISH 08-10-2010 Page 10/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 11: Flooding

    Always keep the bilges clean and check that there is no fuel vapour. Tofinou 9.5 ENGLISH 08-10-2010 Page 11/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 12: Check List

    Close the various valves and sea-cocks. Engine stop lever Location of engine panel in cockpit to port Tofinou 9.5 ENGLISH 08-10-2010 Page 12/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 13 In case of doubt or problem, consult the Owner’s Manual, the instruction books, the drawings or your agent. Tofinou 9.5 ENGLISH 08-10-2010 Page 13/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 14: Engine Wintering

    In the event of more serious corrosion, consult your agent. Tofinou 9.5 ENGLISH 08-10-2010 Page 14/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 15 Regularly check the condition of the anodes and ensure that they are suitable for the boat's environment (fresh water, salt water). Tofinou 9.5 ENGLISH 08-10-2010 Page 15/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 16: Fuel Installation

    Modify the installation, unless this is carried out by a technician qualified in this field. 25 L Fuel tank Tofinou 9.5 ENGLISH 08-10-2010 Page 16/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 17: Steering System

    In the event of doubt or a problem, consult your agent. Optional auto-pilot actuator Rudder post Tofinou 9.5 ENGLISH 08-10-2010 Page 17/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 18: Navigation

    Towing a boat causes a significant extra strain that will have an unfavourable effect on the stability of your boat. Tofinou 9.5 ENGLISH 08-10-2010 Page 18/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 19 Mast Longitudinal adjustment As delivered by LATITUDE 46 boat-builders, the mast is intended to be rigged with a rake aft of around 50 cm [20"]. This rake can be checked using the mainsail halyard like a plumb-line and measuring the distance from the halyard to the mast at the level of the boom gooseneck.
  • Page 20 Only ever moderate, cunningham tension has the effect of slightly re-tensioning the luff in order to remove small wrinkles perpendicular to the mast. Tofinou 9.5 ENGLISH 08-10-2010 Page 20/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 21 20 + kt Very taut Pulled in as tight as 5th hole 25% camber possible Tofinou 9.5 ENGLISH 08-10-2010 Page 21/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 22: Lightning Protection

    It is desirable that people should avoid any contact with metal parts, the spars, deck fittings and the lifelines. Tofinou 9.5 ENGLISH 08-10-2010 Page 22/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 23: Environmental Protection And Safety

    The crew should be familiarized with the use of all safety equipment (harnesses, flares, etc...). Training sessions are organized regularly by sailing schools and clubs. Tofinou 9.5 ENGLISH 08-10-2010 Page 23/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 24: Handling, Transporting, Haulout

    During the wintering, the keel should be left in the highest position to avoid any fouling. 15.2 Transporting For transport by road, a twin-axle trailer should be provided Tofinou 9.5 ENGLISH 08-10-2010 Page 24/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 25: Guarantee

    French law, even in the event of guarantee or multiple counsels. Tofinou 9.5 ENGLISH 08-10-2010 Page 25/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 26 17. SEA CHARTER Tofinou 9.5 ENGLISH 08-10-2010 Page 26/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 27 Un reçu de déductibilité fiscale me sera adressé avec la carte et l'autocollant de membre NOM:…………………………………………………..PRENOM:……………………………… ADRESSE………………………………………………………………………………………… Téléphone::……………………………………………email::……………………………… Tofinou 9.5 ENGLISH 08-10-2010 Page 27/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 28 NOTES Tofinou 9.5 ENGLISH 08-10-2010 Page 28/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 29: Drawings

    Page 54 12. Lifting diagram Page 56 13. List of attached documents Page 58 Tofinou 9.5 ENGLISH 08-10-2010 Page 29/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 30 Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 30/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 31 Indice 10: Rescue facilities Index 11 : Plan de grutage Indice 11: Lifting diagram Tofinou 9.5 ENGLISH 08-10-2010 Page 31/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 32 Tofinou 9.5 ENGLISH 08-10-2010 Page 32/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 33 Locker (must be kept fermés en navigation closed when sailing * Option * Option Tofinou 9.5 ENGLISH 08-10-2010 Page 33/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 34 Fig A Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 34/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 35 Fig B MAINSHEET ARRANGEMENT PREVENTER SHROUD ARRANGEMENT JIBBOOM ARRANGEMENT Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 35/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 36 Fig C REEFING ARRANGEMENT LAZY JACK ARRANGEMENT Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 36/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 37 Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 37/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 38 This page is intentionally left blank This page is intentionally left blank This page is intentionally left blank Tofinou 9.5 ENGLISH 08-10-2010 Page 38/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 39 Circuit Lazy Jack Lazy Jack arrangement Figure D Fig. D Circuit Bosse d'enrouleur Roller-reefing arrangement Tofinou 9.5 ENGLISH 08-10-2010 Page 39/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 40 12441 Tétière 115 5616 Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 40/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 41: Sail Plan

    Loose luff ( no luff snaps ) Pour être sur un emmagasineur For furler fitting Tofinou 9.5 ENGLISH 08-10-2010 Page 41/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 42 Tofinou 9.5 ENGLISH 08-10-2010 Page 42/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 43: Electrical Installation

    Circuit breaker Winch Pompe de cale Bilge pump Treuil électrique Electric winch Option* Option* Tofinou 9.5 ENGLISH 08-10-2010 Page 43/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 44 22 20 Tofinou 9,5 Tofinou 9.5 ENGLISH 08-10-2010 Page 44/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 45: Engine Installation

    22 Tuyau de retour gasoil 22 Fuel return hose 23 Filtre à gasoil 23 Fuel filter Tofinou 9.5 ENGLISH 08-10-2010 Page 45/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 46 Tofinou 9.5 ENGLISH 08-10-2010 Page 46/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 47: Drain Plan

    Discharge hose Pompe de cale électrique Electric bilge pump Douchette de pont Deck shower Tofinou 9.5 ENGLISH 08-10-2010 Page 47/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 48 Tofinou 9.5 ENGLISH 08-10-2010 Page 48/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 49: Holding Tank

    Pompe (sert également à l'évacuation du Pump (also used for emptying réservoir holding tank) holding tank) Siphon Trap Tofinou 9.5 ENGLISH 08-10-2010 Page 49/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 50 Tofinou 9.5 ENGLISH 08-10-2010 Page 50/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 51: Steering System

    Butée de barre Rudder stop Indicateur d’angle de barre* Helm angle indicator* * Option Tofinou 9.5 ENGLISH 08-10-2010 Page 51/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 52 Tofinou 9.5 ENGLISH 08-10-2010 Page 52/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 53: Keel

    - Inspecter l’état du cordage en spectra - Check the Spectra operating cable. Tofinou 9.5 ENGLISH 08-10-2010 Page 53/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 54 Tofinou 9.5 ENGLISH 08-10-2010 Page 54/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 55: Rescue Facilities

    Lampe étanche Waterproof torch ** hors fourniture standard ** in addition to standard supply Tofinou 9.5 ENGLISH 08-10-2010 Page 55/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
  • Page 56 Tofinou 9.5 ENGLISH 08-10-2010 Page 56/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 57: Lifting Diagram

    2,45 m Tirant d'eau 1,20 / 2,20 m Draught 1,20 / 2,20 m Tofinou 9.5 ENGLISH 08-10-2010 Page 57/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...

  • Page 58: List Of Attached Documents

    9. Winch maintenance instructions 10. Exhaust silencer instructions 11. Compass instructions 12. Holding tank instructions Tofinou 9.5 ENGLISH 08-10-2010 Page 58/58 LATITUDE 46–- 17410 Saint Martin de Ré- Ile de Ré - (FRANCE) Tel 33 (0)5.46.09.41.79 Fax 33 (0)5.46.09.01.60 – email: latitude-46@classic-boats.com...
