Table Of Contents - Kaindl SZ Instruction Manual

EC-Declaration of conformitiy
Description of product
Description of function
Basic equipment / Accessory BSM 20 / SZ
Technical data BSM 20 / SZ
General safety advice
Description of safety symbols
Basic safety operations
Request to the operating personal
Special kind of danger
Set up / Transport / Hints for disposal of packing material
Start up / Checks before first start up
Operation BSM 20
Description of parts
Grinding of right hand drills
Grinding of left hand drills
Web thinning
Thinning Split-Point
Four facet shape / cutters
Grinding of stepped drills
Grinding of carbide drills (Widia) - drills
Grinding of sheet metal drills
Grinding of wood drills
Grinding of Forstner drills
Grinding of the outer cutting edges
Countersink sharpening device SVR 20
Alignment of the sharpening device SVR 20
Montage + dressing the grinding wheel before first operation /
adjustment of the grinding wheel protection
Change the grinding wheel
Dressing of grinding wheel
User manual SZ
Operating part (On/Off switch)
Description of the machine
Description of the machine / wheel dressing
Operation of the SZ
Maintence / Wear parts BSM 20 / SZ / Repairs
Warranty / Disposal of the machine
Spare part lists BSM 20 / SZ
