BG Light Ltd BLUEDENT POWER PEN Operation Manual

OPERATIONS GUIDE
BLUEDENT POWER PEN - cordless
LED curing light
Black color
Silver color
OPERATIONS GUIDE
ATTENTION!
Before installation and starting work with the unit, carefully read this guide!
CONTENTS:

I. UNIT DESCRIPTION AND FUNCTION

II. TECHNICAL DATA

Iii. Accessories And Spares
Iv. Safety Precautions
V. PREPARATION AND SEQUENCE OF OPERATION
VI. ROUTINE CARE AND MAINTENANCE
VII. WARRANTY CONDITIONS
VIII. BLUEDENT DATA
IX. SYMBOLS
X. SERVICE DATA
I. UNIT DESCRIPTION AND FUNCTION
LED curing light BLUEDENT POWER PEN cordless is a light source for intraoral polymerization
of dental materials. The unit uses LED (Light Emitting Diode) module as the light source.
emitted light is in the wavelength range 450-490 or 410-490 nm .
BLUEDENT POWER PEN cordless is produced in conformity with MDD 93/42/EEC and 2007/47/EC.
II. TECHNICAL DATA
1. Operating voltage - 3.7V Li Ion battery (800mAh)
2. Power consumption - mains adaptor: 110-240VAC / 50-60Hz, 0.2-0.1A.
- Output: 5VDC / 1.2A micro USB socket.
3. Dimensions:
- max diameter of handpiece - 25mm
- length - 148 mm without lightguide
4. Weight of Emitting handpiece - 105 g
5. Light intensity:
- up to 1000 mW/sq.cm - constant intensity, regardless of battery charge level.
6. Emitting time:
- In RAMP mode - 10 / 20 / 30 sec. /±10%
Start/Stop button, can stop in every moment by second press of the button.
7. Emitted light - blue, 450-490 or 410-490 nm.
8. Light source - powerful LED crystals in module.
9. Charge time - 6-8 hours for full charge and 3-4 hours to 80% of full charge.
10. Working ability after full charged battery - up to 2000sec.
11. Visual indication - color RING and (audible) signal every 10 sec.
12. Low battery warning. Fully discharged battery indication.
13. Working mode (1 min. / 10 min.)
The
