ASSEMBLING INSTRUCTION MANUAL
01
A
7X50 Screws
24 nos.
01
BKFR - 003
BKFR - 003
PANEL CODING SYSTEM
Please follow the panel number for assembling.
04
03
03
02
03
07
09
08
05
06
HARDWARE LIST
B
3/4x 6 P.H Screw
14 nos.
[01] Fixing Side Panel & Bottom .
C
C
C
Back side up
FILING RACK
FILING RACK
01 - Side Panel (L)
02 - Side Panel ®
03 - Shelves I [03]
04 - Top
05 - Bottom
06 - Bottom Strip [02]
07 - Back Sheet
08 - Back Sheet II
09 - Shelves II
06
C
D
Bottom Cup (15mm)
Dowel
08 nos.
04 nos.
C
C
C
(1600x230x12mm)
(1600x230x12mm)
(375x227x12mm)
(375x227x12mm)
(375x227x12mm)
(375x60x15mm)
(1173x397x09mm
(360x397x09mm)
(375x227x12mm)
E
3/4 x 6 S.T Screw
08 nos.
C
C
