NOTE
If the green light goes out completely or fails to come on or if the unit
is making unfamiliar audio tunes, the unit is unstable and should not be
used until the battery is recharged or replaced.
If the unit is not to be used for a certain length of time it is advisable to
remove the battery to avoid battery leakage which could cause serious
damage to the detector.
When not in use, the detector should be stored in a dry warm
environment.
SPECIFICATION
Power Voltage
Power
Operating Frequency
Operating Current
Operating Voltage
Operating Temperature
Net Weight
Dimensions
9V Standard or Rechargeable Battery
270mW
22KHz
<50mA
7V-9V
-5C° to +55C°
409G
41(L) X 8.5(W) X 4.5(H)cm
OPERATING MANUAL
High Performance Hand Held Scanner
2
1
DETAILS:
1. Detection Face
3. Audio Alert
5. Handle
7. Low Sensitivity Switch
9. Rechargeable Battery Socket
AT-600S
7
8
3
4
5
10
9
2. LED(Green /Red Color)
4. Sensitivity Adjuster
6. Battery Lid
8. On/Off Switch
10. Vibrator Button
6
Advertisement
Summary of Contents for Aoteng AT-600S
- Page 1 High Performance Hand Held Scanner If the green light goes out completely or fails to come on or if the unit AT-600S is making unfamiliar audio tunes, the unit is unstable and should not be used until the battery is recharged or replaced.
- Page 2 INTRODUCTION The sensitivity of the detector is determined primarily by the size, shape and The AT-600S is a high performance Hand Held Metal Detector composition of the object to be detected. designed to meet the exact requirements of the security industry.
