AML LDX10 Quick Start Manual

LDX10
Batch Data Collection Handheld
Quick-Start Guide
800.648.4452
www.amltd.com
01132017-1
Getting Started
1
Charge the LDX10 for 6 hours
Use the USB cable and the optional adapter
to charge from a 110VAC wall outlet.
Physical Features
Scan Key
Power
Button
Scan Engine
Window
Top
Getting Started
2
Starting up the LDX10
Power and Reboot Procedures
• Pressing the power button while the
LDX10 is OFF powers up and
re-boots the unit.
• While charging, the LDX10 display
will go dark after a time set in the
'Display Properties' settings in
Windows® Control Panel. Touching
the screen or any key will awaken it
from this idle state.
Power Button
• If left idle for 30 minutes, the LDX10 will automatically
power down.
• Pressing the power button briefly, while the unit is on,
will either put the LDX10 into suspend mode, or wake it up
depending on its current state.
• Pressing and holding the power button for more
than 3 seconds causes the LDX10 to power off.
LCD
USB Port
Bottom
3
Download
Download the DC Console utility at
www.barcodepower.com
Users must install either Microsoft
or Windows
Note: Microsoft ActiveSync works only with
Windows
Note: The Windows Mobile Device Center is only
supported on Windows Vista
24-key Keypad
T9 Keypad
Getting Started
DC Console
Utilize DC Console to
quickly modify existing
applications or create
new ones and transfer
files from your LDX10 to
your PC.
IMPORTANT!
ActiveSync
®
Mobile Device Center before
® ®
DC Console.
installing AML
XP or earlier.
®
or later.
™
®
