Introduction
The DMX controller has 6 channels and 7 sliders. only one slider is set as the master and the left sliders are
slaves. the master slider controls 6 channels's DMX output and 6 slave sliders control each channel's DMX
output respectively. DMX value is from 0~255. Before your application, please read instructions carefully and
thoroughly.
Technical specification
power source-------------------------------------------DC 9V 100mA ADAPTER 6F22 BATTERY
DMX output--------------------------------------------3PIN XLR female socket
Dimension----------------------------------------------173x153x55mm
Panel layout
8
7
DMX6 user manual
6CH DMX Controller
6
5
4
3
2
1
Advertisement
Table of Contents
Summary of Contents for mbt Lighting DMX6
- Page 1 DMX6 user manual 6CH DMX Controller Introduction The DMX controller has 6 channels and 7 sliders. only one slider is set as the master and the left sliders are slaves. the master slider controls 6 channels’s DMX output and 6 slave sliders control each channel’s DMX output respectively.
- Page 2 power indicator master slider slave slider (control channel 6) slave slider( control channel 5) slave slider (control channel 4) slaveslider (control channel 3) slave slider(control channel 2) slave slider(control channel1) Operational instruction After connecting power source,switch on.the power indicator is on. Adjust DMX value by sliders.
