720P IR Dome Camera· User Manual
720P IR Dome Camera
User Manual
UD.6L0201D1942A01
0

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION DS2CC52C7TVPIR

Summary of Contents for HIKVISION DS2CC52C7TVPIR

  • Page 1 720P IR Dome Camera· User Manual 720P IR Dome Camera User Manual UD.6L0201D1942A01...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL...
  • Page 4 720P IR Dome Camera· User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 720P IR Dome Camera· User Manual 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 720P IR Dome Camera· User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 7 720P IR Dome Camera· User Manual camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)  To reduce the risk of fire or electrical shock, do not expose this product to rain or moisture. ...
  • Page 8 720P IR Dome Camera· User Manual  The sensor may be burned out by a laser beam, so when any laser equipment is being used, make sure that the surface of the sensor will not be exposed to the laser beam. ...

  • Page 9: Table Of Contents

    720P IR Dome Camera· User Manual Table of Contents 1 Introduction .................. 10 1.1 Features ................. 10 1.2 Overview ................ 11 2 Installation ..................13 2.1 Ceiling Mounting ............14 2.2 Cover Mounting ............. 18 3 Menu Description ................. 23 3.1 AE ...................
  • Page 10 720P IR Dome Camera· User Manual 3.7 SAVE &EXIT ..............32 Appendix ..................33 1 Glossary ................33 2 Troubleshooting ..............37 3 Technical Maintenance ............40...

  • Page 11: Introduction

    720P IR Dome Camera· User Manual 1 Introduction 1.1 Features This camera adopts high performance sensor and advanced print circuit board design technology. It features high resolution, low distortion, and low noise, etc. It is suitable for surveillance system and image process system. The main features are as follows: ...

  • Page 12: Overview

    720P IR Dome Camera· User Manual 1.2 Overview The appearance of the cameras is as follows: Overview Figure 1-1 Overview Table 1-1 Description Description Trim Ring Cover Power Cable Base Plate CVBS Cable Inclined Component Video Cable Switch Cable...
  • Page 13 720P IR Dome Camera· User Manual Description Description Corner Mounting Bracket Audio Cable (Optional, with 2.8mm Lens)

  • Page 14: Installation

    720P IR Dome Camera· User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included.  Make sure that all the related equipment is power-off during the installation.

  • Page 15: Ceiling Mounting

    720P IR Dome Camera· User Manual 2.1 Ceiling Mounting Steps: 1. Attach the drill template (supplied) to the place where you want to fix the camera. 2. Drill the cable hole and screw holes on the ceiling according to the drill template as shown in Figure 2-1. Drill Template Figure 2-1 3.
  • Page 16 720P IR Dome Camera· User Manual 5. Secure the inclined component with inserting a PA4 screw, as shown in Figure 2-2. Inclined Component Install the Inclined Component Figure 2-2 6. Insert 1/3 of the 3 PM4 screw into the metal plate of the inclined component, as shown in Figure 2-3.
  • Page 17 720P IR Dome Camera· User Manual 7. Take apart the trim ring from the base plate by loosening the 3 PM3 screws on the camera with allen wrench, as shown in Figure 2-4. Trim Ring Base Plate Disassemble the Trim Ring Figure 2-4 8.
  • Page 18 720P IR Dome Camera· User Manual Assemble the Base Plate Figure 2-5 9. Loosen the PM3 screws of the inclined component with allen wrench, and the base plate can be adjusted +/-3.5° according to the direction of arrow. Adjust the Position Figure 2-6...

  • Page 19: Cover Mounting

    720P IR Dome Camera· User Manual 10. Fix the trim ring to the base plate by securing the 3 PM3 screws with allen wrench, as shown in Figure 2-7. Fix the Trim Ring Figure 2-7 2.2 Cover Mounting Take apart the plastic enclosure by loosening the screws on the bracket with allen wrench.
  • Page 20 720P IR Dome Camera· User Manual 2. Place the bracket close to the corner and mark 2 screw hole sites (P1, P2) on the left wall of the corner through the screw holes, as shown in Figure 2-9. 3. Remove the bracket from the corner and insert 1/3 of the 2 PA4 screws into the 2 screw hole sites (P1, P2) on the left wall of the corner according to the marks.
  • Page 21 720P IR Dome Camera· User Manual Screw Hole (Left) Screw Hole (Right) Place the Bracket in the Corner Figure 2-10 6. Take apart the trim ring from the base plate by loosening the 3 PM3 screws on the camera with allen wrench, as shown in Figure 2-11.
  • Page 22 720P IR Dome Camera· User Manual +/-5° according to the direction of arrow. Secure the screws after adjusting it to its appropriate position, as shown in Figure 2-12. Assemble the Base Plate Figure 2-12 8. Loosen the PM3 screws of the corner mounting bracket with allen wrench, and the base plate can be adjusted +/-3.5°...
  • Page 23 720P IR Dome Camera· User Manual 9. Fix the trim ring to the base plate and secure the plastic enclosure with the camera and bracket to accomplish the installation, as shown in Figure 2-14. Assemble the Trim Ring Figure 2-14 Fix the Screw Assemble the Bracket Figure 2-15...

  • Page 24: Menu Description

    720P IR Dome Camera· User Manual 3 Menu Description Setup LANGUAGE MAIN MENU RESET SAVE&EXIT FUNCTION VIDEO SETTING DAY&NIGHT INFRARED- BRIGHTNESS DETECTION AUTO SMART CONTRAST LAMP AE MODE MASKING MANUAL COLOR SMART-IR SHARPNESS COLOR GAIN ZOOM IN SENS-UP 3DNR MIRROR Main Menu Overview Figure 3-1 ...

  • Page 25: Brightness

    720P IR Dome Camera· User Manual 3.1 AE AE describes the brightness-related parameters. You can adjust the image brightness by the BRIGHTNESS, AE MODE, AGC, SENS UP, etc. in different light conditions. BRIGHTNESS GLOBAL AE AE MODE MIDDLE SENSE UP ...

  • Page 26: Sens Up

    720P IR Dome Camera· User Manual order to optimize the clarity of image in poor light scene. You can set the AGC level as HIGH, MIDDLE, LOW and OFF. The noise will be amplified if the AGC is on. 3.1.4 SENS UP The SENS UP is adjustable.

  • Page 27: Day & Night

    720P IR Dome Camera· User Manual MANUAL R GAIN B GAIN RETURN  Manual White Balance Figure 3-3 The white balance is not adjustable if B/W mode is selected. 3.3 Day & Night Smart, Color, and B/W are selectable for DAY and NIGHT switches. ...

  • Page 28: Video Setting

    720P IR Dome Camera· User Manual  COLOR The image is colored in day mode all the time.  The image is black and white all the time, and the IR LED turns on in the low-light conditions. 3.4 Video Setting 3.4.5 CONTRAST This feature enhances the difference in color and light between parts of an image.

  • Page 29: Mirror

    720P IR Dome Camera· User Manual capturing moving images in low light conditions and delivering more accurate and sharp image quality. The 3D NR level can be set as HIGH, MIDDLE, LOW, and OFF. 3.4.9 Mirror OFF, H, V, and HV are selectable for mirror. OFF: The mirror function is disabled.

  • Page 30: Detection

    720P IR Dome Camera· User Manual 3.5.1 DETECTION In the user-defined detection surveillance area, the moving object can be detected and the alarm will be triggered. DETECTION 1. SENSITIVITY HIGHT  2. AREA NO.0  3. AREA NO.1  4. AREA NO.2 ...

  • Page 31: Masking

    720P IR Dome Camera· User Manual AREA 1. STATUS 2. COLOR WHITE 3. HORIZON SIZE 0 4. VERTICAL SIZE 5. HORIZON MOVE 6. VERTICAL MOVE  7. RETURN Detection Area Figure 3-7 Steps: 1. Set the STATUS as ON to enable the area. 2.
  • Page 32 720P IR Dome Camera· User Manual MASKING 1. COLOR WHITE  2. AREA NO.0  3. AREA NO.1  4. AREA NO.2  5. AREA NO.3  6. AREA NO.4  7. AREA NO.5  8. AREA NO.6  9. AREA NO.7 ...

  • Page 33: Zoom In

    720P IR Dome Camera· User Manual Steps: 1. Set the STATUS as ON to enable the area. 2. Move the cursor left/right to define the horizon size of the selected masking area, the range of the value is 0 to 1280. 3.

  • Page 34: Appendix

    720P IR Dome Camera· User Manual Appendix 1 Glossary Note: The glossary gives brief explanations to the basic operation principle or the basic function of the camera. However, it doesn’t mean the listed functions are all supported by the cameras mentioned in this manual.
  • Page 35 720P IR Dome Camera· User Manual AGC is a control circuit that automatically changes the gain of a receiver or other piece of equipment, so that the desired output signal remains essentially. When under low illumination, AGC will regulate the gain and amplification of the video signal. S/N ratio: It is the ratio of Signal voltage and noise voltage.
  • Page 36 720P IR Dome Camera· User Manual Privacy Mask: This function allows you to block or mask certain area of a scene, thus prevent the personal privacy from recording or live viewing. OSD (On Screen Display): OSD is the texts superimposed on a screen. It can show the menu on the screen.
  • Page 37 720P IR Dome Camera· User Manual processing the noise in the separated Y video signal and C video signal. HLC (High Light Compensation): The HLC is capable of detecting and reversing the bright spots in the picture (such as headlights) to black so as to achieve optimum picture quality.

  • Page 38: Troubleshooting

    720P IR Dome Camera· User Manual 2 Troubleshooting Problem 1: Why does the camera restart intermittently? And the problem is much more serious when infrared lights of IR camera are turned on at night. Possible Reasons: The main and common reason is power supply shortage. This problem may happen to the IR camera especially at night, because the infrared lights are turned on at night and increase the power consumption.
  • Page 39 720P IR Dome Camera· User Manual Problem 3: The camera is installed with an auto-iris lens. You adjust the focus to get a clear image in the daytime. But the image is defocused at night. Possible Reasons: In the daytime, the illumination is high, so the iris is adjusted to a small size automatically.
  • Page 40 720P IR Dome Camera· User Manual Check the auto-iris lens connector to ensure good contact. Set the iris driven mode of the camera the same as the mode of lens. The modes can be VD (video drive) or DD (direct drive). DD mode is commonly used.

  • Page 41: Technical Maintenance

    720P IR Dome Camera· User Manual 3 Technical Maintenance Lens Maintenance The lens surface is plated an anti-reflection coating. The dust, oil and finger print, etc. will cause scratch, mildewed and performance degraded. Please refer to the following method to clean the lens. ...
  • Page 42 720P IR Dome Camera· User Manual Glass Maintenance of IR Camera Steps: Wipe off the dust, water-drop or oil by soft cloth and dry the glass. Use oil free cotton cloth or glass clean paper to wipe the glass from center to outside with alcohol or detergent. Change the cloth to wipe the glass until the glass is clean.
  • Page 43 720P IR Dome Camera· User Manual...
