Summary of Contents for ISC DW100.2

  • Page 1 Deadweight Trolley DW100.2: Issue A - Aug 2017...
  • Page 2 There must be sufficient free space beneath the user at the work area before each occasion of use, so that in the case of a dynamic event there will be no collision with the ground or other obstacles in the fall path. General Limitations X = ≤ 5° DW100.2: Issue A - Aug 2017...
  • Page 3 ??KG DW100.2: Issue A - Aug 2017...
  • Page 4 DW100.2: Issue A - Aug 2017...
  • Page 5 8. If the intention is to combine PFPE for Fall Arrest with Deadweight Anchors the user should seek guidance from the manufacturer as to its suitability. Always ensure that all components within a safety system are compatible and allow the system to function safely B Specific Use DW100.2: Issue A - Aug 2017...
  • Page 6 1. Wheel Replacement: Remove pins and washers. Replace the wheel(s) and reattach using pins 2. Sword pin replacement: Prise open Darlaston Washer with a flat headed screwdriver. Insert chain- link of new sword pin and close Darlaston Washer with a soft-faced hammer DW100.2: Issue A - Aug 2017...
  • Page 7 D General Misuse DW100.2: Issue A - Aug 2017...
  • Page 8 3. All weights must be used at all times. Weights may need to be secured to the frame by passing a chain through the handles and the frame to prevent tampering during use 4. Do not use the Deadweight as an anchor for Self Retracting Lanyards DW100.2: Issue A - Aug 2017...
  • Page 9 2. Top Bar / Roller Carriage 3. Sword Pins 4. Nylon Roller 5. Height Adjustment Holes 6. Anchor Points 7. Antiluce Pin 8. Weight 9. Rubber Wheel Assembly Place all 6 weights over shaft and fold over Antiluce pin DW100.2: Issue A - Aug 2017...
  • Page 10 2. The device should be stored in a clean, dry environment free from corrosive or chemical substanc- es. Care should be taken to protect the device against damage during transportation DW100.2: Issue A - Aug 2017...
  • Page 11 2. Lateral Force Calculation - Use this formula to work out the force that will be exerted on the upstand by a loaded DW100 3. Dimensions 4. Total weight of Unit - 178kg (392lbs) DW100.2: Issue A - Aug 2017...

  • Page 12: Product Record

    Product Record DW100.2: Issue A - Aug 2017...
  • Page 13 Product Record Details Item Serial Number. Year of manufacture Purchased from Purchase date. Name of Manufacturer Date of first use. Inspection date. Reason (periodic examination (E) or repair (R)). Conform. Comments. Signature. DW100.2: Issue A - Aug 2017...
  • Page 14 Wyndham Way, Telford Way, Kettering, Northamptonshire, NN16 8SD. U.K. Notified body responsible for production monitoring and inspection (Art. 11B): SGS United Kingdom Ltd (0120), Unit 202B, Worle Parkway, Weston Super Mare. S22 6WA. U.K. DW100.2: Issue A - Aug 2017...
  • Page 15 Notes DW100.2: Issue A - Aug 2017...
  • Page 16 Llandygai Industrial Estate Bangor Gwynedd LL57 4YH United Kingdom T> +44 (0) 1248 363 125 F> +44 (0) 1248 372 118 sales@iscwales.com w w w. i s c wa l e s . c o m DW100.2: Issue A - Aug 2017...
