ALC 40392 Assembly Instructions Manual

48” x 24” polymer clamshell cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
40392
48" x 24" POLYMER CLAMSHELL
CABINET
ASSEMBLY INSTRUCTIONS
DIVISION OF S&H INDUSTRIES
5200 Richmond Road  Cleveland, OH 44146
Phone 216-831-0550  Toll Free 800-253-9726 
Fax 216-831-9573
www.shindustries.com
E-mail: www.service@shindustries.com
Rev. 1/19/12

Advertisement

loading
Need help?

Need help?

Do you have a question about the 40392 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALC 40392

  • Page 1 40392 48” x 24” POLYMER CLAMSHELL CABINET ASSEMBLY INSTRUCTIONS DIVISION OF S&H INDUSTRIES 5200 Richmond Road  Cleveland, OH 44146 Phone 216-831-0550  Toll Free 800-253-9726  Fax 216-831-9573 www.shindustries.com E-mail: www.service@shindustries.com Rev. 1/19/12...
  • Page 2 Page 2 WARNING! Do not use an ALC Cabinet Blaster until you have read this manual and you understand its contents and warnings. These warnings are included for the health and safety of the operator and those in the immediate vicinity. Keep this manual for future reference.
  • Page 3 40392 Assembly Instructions Page 3 ASSEMBLY INSTRUCTIONS Assemble legs to cabinet bottom using 1/4-20 x 1” screw and 1/4" washer on the outside of the cabinet. On the inside, use 1/4" rubber washer, 1/4" washer and 1/4-20 hex nut. Once the legs are attached, place 1-1/4" plastic plug in bottom.
  • Page 4 40392 Assembly Instructions Page 4 or a moisture separator. The air compressor should be drained at the bottom of the supply tank through a drain valve and should be blown down daily. It is not unusual to drain three or four gallons of water from the supply tank on a high humidity day.
  • Page 5 40392 Assembly Instructions Page 5 CABINET BLASTER SAFETY PROCEDURES CAUTION: R – EAD THESE SAFETY PROCEDURES IN THEIR ENTIRETY PARTS OF THE PERATING NSTRUCTIONS ARE WITHIN THESE ARNINGS These procedures are not intended to be exhaustive due to the many variables in the abrasive blasting field.
  • Page 6 1 pair 19007 49” Rear support 40240 Glove clamps – pair 1 pair 19008 49” Lid support 11604 ALC Gun w/15 cfm nozzle 19009 36” Upright lid support 40343 Pick-up tube 19010 23” Support strap 40338 Economy light kit (60 watt) 11601 1/4”...
  • Page 7 40392 Assembly Instructions Page 7 MOUNTING INSTRUCTIONS FOR THE ECONOMY LIGHT KIT Using drill dimension sheet, drill 1.467 (1-7/16) hole in left side of cabinet. Drill (2) 0.187 (3/16) holes 1.625 (1-5/8) from center of large hole, one above and one below.
  • Page 8 40392 Assembly Instructions Page 8 WARNING Follow all electrical and safety codes as well as the National Electrical Code (NEC) and OSHA Regulations. Light Kit Components Part No. Description 11641 Lampholder 11642 Electrical box 11008 Power Cord 11009 Switch 11011...
  • Page 9 40392 Assembly Instructions Page 9...
  • Page 10 40392 Assembly Instructions Page 10 Maximum 60 watt light bulb (not included)

  • Page 11: Maintenance

    40392 Assembly Instructions Page 11 MAINTENANCE WARNING! Failure to observe the following before performing any maintenance could cause serious injury or death from the sudden release of compressed air:  Disconnect power supply.  Lockout and tagout the compressed air supply.
  • Page 12 40392 Assembly Instructions Page 12 Overtaxed Compressor: Compressor too small Restrict time used Nozzle size too large Use smaller size Too many leaks in plumbing Seal and tighten plumbing Holes in abrasive hose Replace hose Air filter on compressor plugged...
  • Page 13 40392 Assembly Instructions Page 13 Coal Slag # 40093 Coal Slag is used when paint and rust has to be removed from steel, such as car bodies, tanks or heavy machinery. Coal Slag is faster cutting, can be re-used, is moisture free, and will not pack or absorb moisture.

  • Page 14: Limited Warranty

    40392 Assembly Instructions Page 14 Disclaimer of Warranties. S & H Industries, Inc. ("Seller") makes no warranties with respect to any goods delivered to Buyer or users except as specifically set forth within this manual. S & H INDUSTRIES, INC. MAKES NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE WITH RESPECT TO ANY OF THE GOODS, AND S &...
