KORTEX PSI – KX Router 3G Pro User Manual V1.3
KORTEX
Kx Router 3G Pro
User Manual
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KX ROUTER 3G PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Kortex KX ROUTER 3G PRO

Summary of Contents for Kortex KX ROUTER 3G PRO

  • Page 1 KORTEX PSI – KX Router 3G Pro User Manual V1.3 KORTEX Kx Router 3G Pro User Manual - 1 -...

  • Page 2: Table Of Contents

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 Content CHAPTER 1 INTRODUCTION ....................... 4 1.1 P ............................4 URPOSE 1.2 A ......................... 4 PPLICATION RANGE 1.3 E ............................. 4 DITION 1.4 T ........................4 ECHNICAL SUPPORT CHAPTER 2 PRODUCT SPECIFICATION ..................5 2.1 O...
  • Page 3 KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.1 System ............................ 41 4.5.9.2 SIM ............................44 4.5.9.3 SMS ............................47 4.5.9.4 Firmware ..........................48 4.5.9.5 Configuration ........................48 4.5.9.6 Status ............................. 50 4.5.9.7 Statistics ..........................51 4.5.9.8 System log ..........................52 4.5.9.9 REBOOT ..........................

  • Page 4: Chapter 1 Introduction

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 Chapter 1 Introduction Here to introduce the KX ROUTER 3G PRO, it will be much helpful during your application. 1. Purpose 2. Application range 3. Version 4. Technical support 1.1 Purpose The user manual will be used for your installation and test.

  • Page 5: Chapter 2 Product Specification

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 Chapter 2 Product specification 2.1 Overview With the development of mobile communication technology, the mobile data communication network using GPRS/CDMA/EDGE/EVDO/HSDPA/HSUPA/HSPA+ has covered many regions in the world. And network is very stable. All these make a large market for wireless terminals.

  • Page 6: Specification

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 2.2 Specification  RAM:256Mbit  FLASH:64Mbit Power Input  Input DC 6-12V, standard DC8V 1A 5% 8.0W (max)  Low-voltage, over current, over voltage, anti-reverse protection Environment  Storage Temperature：-20℃～60℃...

  • Page 7: Chapter 3 Installation

     Outdoor LED  Smart home  Oil monitor  Car video surveillance (Coach, bus) Chapter 3 Installation Here you can see the appearance of KX ROUTER 3G PRO, and how to install. 1. Accessories 2. Edition - 7 -...

  • Page 8: Accessories

    WIFI, one for 3G SMA connector. RJ45 cable standard User manual standard 3.2 Installation KX ROUTER 3G PRO must be properly installed and configured to meet the design features. Note: Please install the router and SIM card before inputting power. - 8 -...

  • Page 9: Chapter 4 Configure

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 Chapter 4 Configure 4.1 Overview The router has its own webpage for parameter settings. You can access the router by the following way. 4.2 Connection 4.2.1 Computer network configuration Find “Local Area Connection”, and choose “Properties”...

  • Page 10: Login The Router

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.2.2 Login the router Open the Web browser, and type http://192.168.8.1 into the address field and press Enter button in your computer keyboard. Type User Name “admin” and Password “kxpro75002” in the pop-up Login Window, and then press the “OK”...

  • Page 11: Front Leds

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.3 Front LEDs - 11 -...
  • Page 12 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Meaning Lit when power is ON. Lit when a SMS is received. Used for remote monitoring. MAIL Lit when the Wi-Fi function is enabled (default). WLAN Flash when the data is transmitting.

  • Page 13: Rear Panel

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.4 Rear Panel Items Meaning After the device is powered on, press the reset button to restore to factory default settings. RESET 10 seconds above: restore to factory default settings (this is used when you cannot login to the router.

  • Page 14: Configure Parameters

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5 Configure Parameters 4.5.1 Internet Settings - 14 -...

  • Page 15: Wan Settings

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.2 WAN settings The WAN (Wide Area Network) section is where you configure your Internet connection type. The KX ROUTER 3G PRO supports 3G dialup connection type to access Internet.
  • Page 16 KORTEX PSI – KX Router 3G Pro User Manual V1.3 WAN Connection Type: support: Static IP (fixed IP), DHCP (Auto Config), PPPOE (ADSL) DHCP Mode: Hostname: input it (optional) 3G Mode: APN (Access Point Name): This SIM Card APN name is from Mobile Management Service Provider.

  • Page 17: Lan Settings

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.3 LAN settings These are the settings of the LAN (Local Area Network) interface for the router. The router's local network (LAN) settings are configured based on the IP Address and Subnet Mask assigned in this section.
  • Page 18 KORTEX PSI – KX Router 3G Pro User Manual V1.3 DHCP Type: DHCP stands for Dynamic Host Configuration Protocol. The DHCP section is where you configure the built-in DHCP Server to assign IP addresses to the computers and other devices on your local area network (LAN). When you select Server item from this pull-down list to enable this function, the following parameters will be displayed.

  • Page 19: Dhcp Clients

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.4 DHCP clients In this section, you can see clearly which devices are currently leasing IP addresses that you had defined for the DHCP Server‘s allocation of addresses to computers and devices on your Local Area Network.

  • Page 20: Vpn

    L2TP Server IP Address: The ISP provides this parameter, if necessary. The value may be the same as the Gateway IP Address. Operation Mode: The KX ROUTER 3G PRO allows you to set the reconnection mode. The setting is: Keep Alive: A connection to the Internet is always maintained.
  • Page 21 Server IP Address: The ISP provides this parameter, if necessary. The value may be the same as the Gateway IP Address. Operation Mode: The KX ROUTER 3G PRO allows you to set the reconnection mode. The setting is: Keep Alive: A connection to the Internet is always maintained.

  • Page 22: Advanced Routing

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.6 Advanced Routing This section mainly introduces what is Routing Table and how to configure static routing. 4.5.6.1 Routing Table This page shows the key routing table of this router.
  • Page 23 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Destination: The IP address of packets that will take this route. Range: Includes Host and Net options. When selecting “Net”, there is another “Netmask” column that needs to be filled out.

  • Page 24: Wireless Settings

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.7 Wireless settings 4.5.7.1 Basic Wireless Settings The wireless section is used to configure the wireless settings for your Company router. Please note that changes made on this section may also need to be duplicated on your Wireless Client.
  • Page 25 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Wireless Network Settings: Wi-Fi On/Off: This option turns on and off the wireless connection feature of the router. Simply click on the WI-Fi ON / WI-Fi OFF button. The system will automatically detect the current status of the router and switch the button accordingly.
  • Page 26 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Rate: Exist only when selecting 802.11b/g mixed mode, 802.11b only, 802.11g only as the Network Mode for the router. You can set up the desired transmitting rate for these network modes.
  • Page 27 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Reverse Direction Grant (RDG): This is the 11n performance parameter. Enable it if needed. Extension Channel: Exist only when selecting “20/40” as the Channel BandWidth for the router. For example, if channel 6 is selected, it means you can select channel 2 or channel 10 as the extension channel.

  • Page 28: Wireless Security/Encryption Settings

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.7.2 Wireless Security/Encryption Settings In this section, you can configure the wireless security and encryption to prevent from unauthorized access and monitoring. Please choose a SSID you had created for this router ...
  • Page 29 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Examples: - 64-bit hexadecimal keys are exactly 10 characters in length. (12345678FA is a valid string of 10 characters for 64-bit encryption.) - 128-bit hexadecimal keys are exactly 26 characters in length.
  • Page 30 KORTEX PSI – KX Router 3G Pro User Manual V1.3 WPA-PSK / WPA2-PSK Mode WPA (Wi-Fi Protected Access) is the older standard; select this option if the clients that will be used with the router only support the older standard. WPA2 is the newer implementation of the stronger IEEE 802.11i security standard.

  • Page 31: Station List

    With the AP Client function, the KX ROUTER 3G PRO could connect to other remote Wi-Fi AP (AP1) as a Wi-Fi station, and it will be bridged with KORTEX router Wi-Fi AP and LAN, which means that PC Wi-Fi clients under AP1 and PCs clients under KX ROUTER 3G PRO LAN and Wi-Fi could communicate with each other.

  • Page 32: Statistics

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.7.4 Statistics The KX ROUTER 3G PRO offers the counter function to collect all wireless traffic counting information about the transmitting / receiving packets of this router. The system will automatically update these wireless data per 3 seconds.

  • Page 33: Firewall

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.8 Firewall 4.5.8.1 MAC/IP/Port Filter Settings The router could filter the outgoing packets for security or management consideration. You can set up the filter against the IP addresses to block specific internal users from accessing the Internet.

  • Page 34: Port Forwarding

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 This section is mainly about MAC/IP/Port filter settings: Basic Settings: MAC/IP/Port Filtering: Enable/Disable the function of MAC/IP/Port Filtering. Default Policy - The packet that doesn’t match with any rules would be: Dropped/Accepted.
  • Page 35 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Create a Port Forwarding In this section, you can add a new port forwarding to the port forwarding table below or delete an existing entry from this table. Port Forwarding: Enable/Disable the function of Port Forwarding.
  • Page 36 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Create a Virtual Server In this section, you can add a new virtual server to the virtual server table below or delete an existing entry from this table. The Virtual Server option gives Internet users access to services on your LAN. This feature is useful for hosting online services such as FTP, Web, or game servers.
  • Page 37 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Virtual Server: Enable/Disable the function of Virtual Server. IP Address: The IP address of the system on your internal network that will provide the virtual service, for example, 192.168.0.50. Public Port: The port that will be accessed from the Internet.

  • Page 38: Dmz Settings

    TCP port 80 cannot be used for DMZ; otherwise, you can use this port for DMZ. 4.5.8.4 System Security To improve the safety of the internal network environment, the KX ROUTER 3G PRO offers a variety of basic firewall management functions, including Remote management (via WAN), Ping from WAN Filter, Block port scan, Block SYN Flood and SPI Firewall.
  • Page 39 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Remote management (via WAN): Allow or Not Allow the user to log in the system with the WAN IP. Remote Port: Default 80 Block Ping from WAN: Enable/Disable the function of Ping from WAN Filter. If the function is enabled, the system will reject to response the ICMP (ping) packets coming from the WAN.

  • Page 40: Sms Server Settings

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.8.5 SMS Server Settings SMS Server: Enable/Disable the function. Port: 2005 default value. Listening port value to read the SMS "AT+CMGS" string. Country Code: Default +33 for France. To add +33 to the mobile phone receive on the SMS "AT+CMGS"...

  • Page 41: Management

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9 Management 4.5.9.1 System You may configure language, administrator’s account and password, NTP and DDNS settings here. We strongly recommend that you change the default username and password. - 41 -...
  • Page 42 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Language Settings: Select the language which you would like. It includes English and Portuguese. Administrator Settings: Modify the account and password to set up and manage the router. The default settings for administrator are as follows:...
  • Page 43 KORTEX PSI – KX Router 3G Pro User Manual V1.3 DDNS (Dynamic DNS) Settings: The Dynamic DNS feature allows you to host a server (Web, FTP, Game Server, etc.) using a domain name that you have registered (www.dyndns.com or www.no-ip.com) with your dynamically assigned IP address. Most broadband Internet Service Providers assign dynamic (changing) IP addresses.

  • Page 44: Sim

    On this SIM Card Control settings page, you can set up the password for SIM card’s authentication. The KX ROUTER 3G PRO will detect automatically the current limit times of PIN code and PUK input for your SIM card. If the remaining times of PIN code input are less than 3 times, the system will stop all related functions.
  • Page 45 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Information Table: This table will show all information about the SIM card used in your KX ROUTER 3G PRO. For more details, please refer to the following parameters below: SIM Card Status: It includes “SIM not inserted”, “READY”, “SIM PIN”, “SIM PUK”, “ERROR”...
  • Page 46 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Automatic PIN CODE insertion on boot: Decide that whether to use the value filled in the field of Type the PIN CODE for automatic insertion to do the authentication of SIM card or not while the router is powered on.

  • Page 47: Sms

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.3 SMS SMS offer the possibility to Send/Receive an SMS to/from an mobile phone number and to display in a list. You can also delete an SMS from the In Box or Sent Box windows.

  • Page 48: Firmware

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.4 Firmware Software upgrade tool is used to help upgrade the software function in order to fix or improve the function. User can upgrade the firmware in this page. Please note that power cannot be off in the process of the software upgrade.
  • Page 49 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Export: To export the current settings stored in the flash to a config file, just press the Export button. Import: Import the config file into your router. Specify the filename and directory where the file is located via the Browse…button, and press the Import button when completed.

  • Page 50: Status

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.6 Status In the Status page, it tells you the basic information of the system. You can check the device status, including the firmware version, system up time, current operation mode, WAN/Local IP address, MAC address and so on.

  • Page 51: Statistics

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.7 Statistics The KX ROUTER 3G PRO offers the counter function to collect all counting information about the memory status and all interfaces’ receiving/transmitting packets of this router. Display the statistics information of system flow.

  • Page 52: System Log

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.8 System log From the system log you can read the various situations after the system starts. 4.5.9.9 REBOOT The KX ROUTER 3G PRO offers the possibility to be rebooted. - 52 -...

  • Page 53: Remote Sms

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.10 REMOTE SMS The KX ROUTER 3G PRO has a function to be controlled via SMS. You can send a SMS to the number of the M2M SIM card in the router KX ROUTER 3G PRO;...

  • Page 54: Telnet

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 4.5.9.11 TELNET The KX ROUTER 3G PRO has a control interface "Telnet" on port 2000 accessible from the LAN ports or remote. Locally, you must type in command mode "cmd" Telnet "IP of the router"...

  • Page 55: Chapter 5 Faq

    KORTEX PSI – KX Router 3G Pro User Manual V1.3 Chapter 5 FAQ SIM Card Status shows “Not Ready” It means the SIM card is not found, you can take SIM card out, and insert it again. Signal Strength is normal, but can’t get WAN IP Check the APN parameters in WAN settings.
  • Page 56 KORTEX PSI – KX Router 3G Pro User Manual V1.3 Port forwarding not working 1) Check with ISP which ports are open by them. 2) More than 1 router. The most common problem we come across is people who are behind 2 or more routers and don’t realize it.
