Capital fireplaces Lectro Installation & User's Instructions

Inset fire manual/remote control

Advertisement

Quick Links

Installation & User Instructions:
Models:
Lectro Inset Fire (Manual) – Electric – Code: 1703001
Lectro Inset Fire (Remote Control) – Electric – Code: 1703002
Once installed, the installer should take the appropriate steps
To ensure that the user understands how the appliance operates and
Should make the customer aware of the appliances basic service requirements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lectro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Capital fireplaces Lectro

  • Page 1 Models: Lectro Inset Fire (Manual) – Electric – Code: 1703001 Lectro Inset Fire (Remote Control) – Electric – Code: 1703002 Once installed, the installer should take the appropriate steps To ensure that the user understands how the appliance operates and...
  • Page 2 IMPORTANT INFORMATION All Capital fireplaces Ltd products meet the requirements of the EC Directives 2004/108/EC and 2006/95/EC. These directives have been met by compliance with the following standards: BS EN 60335-1:2002 BS EN 60335-2-30:2003 BS EN 6100-6-3:2001 Please read these instructions before installation or use and keep this booklet handy for future reference.
  • Page 3 Replacement plug: (Please note that it may invalidate your warranty is the moulded plug is removed) This appliance must only be connected to a 230/240 Volts AC 50Hz supply. Before connecting the fire, check that the supply voltage is the same as stated on the fire. This appliance must only be used on a AC supply, fuse rating 13Amp. The wires in the mains lead are coloured in accordance with a standard UK supply, these being: GREEN/YELLOW –...
  • Page 4: Installation Requirements

    INSTALLATION REQUIREMENTS INSET MODELS: This product has been designed to be installed into a standard 420mm(W) x 570mm(H) x 100m(D) If the products is to be installed into a open chimney or flue, it is important that the chimney/flue is blocked off to prevent any up/down draughts and falling debris which could restrict and alter the airflow to the product.
  • Page 5: Installation

    INSTALLATION STEP 1 Determine the type of decorative frame or fascia that will be fitted to the appliance. If it is a separate steel, 3 sided trim and cast iron fret, please proceed to step 2. if it is a one piece cast iron frame (with removable ash pan cover), then the appliance canopy will need to be removed.
  • Page 6: Technical Specifications

    STEP 3 Fit the decorative frame or fascia. 3 sided trim and cast iron fret – fit the trim to the fire using magnets provided, then place the cast iron fret in front of the ‘fuel bed’. 1 piece cast iron frame – before fitting, bend down the two ‘hooks’ at the top of the appliance.
  • Page 7 CABLE TIE-BACK FIXING METHOD Screw and fix the eyelet into the top of the installation aperture. Fig:2 Fig:1 Fig:1 Feed the wire first through the body of the fire and then through the eyelet. Fig:2 Once threaded through the eyelet, feed back through the same hole on the fire body to create a loop.
  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS The appliance can be operated manually using the rocker switch to the right of the heater outlet, or by remote control. To operate, first press the right master switch (located to the right of the heater under the canopy) which is marked (O/I) to the ( I ) position then perform the following actions: FLAME EFFECT ONLY (NO HEAT) Manual –...
  • Page 9: Maintenance

    MAINTENANCE BULB REPLACEMENT Always switch the appliance and disconnect from the mains before replacing the bulb. Replacement bulb specification: B22, 20w/ 1200 Lumen, Warm White 220-240V, 50 -60Hz, Energy Saving Lamp. To replace the bulb, first remove the decorative frame/fascia and remove all of the pebbles or coals from the top of the fuel bed.
