Functional Devices, Inc. PSC100AB10 Installation Instructions

PSB / PSC Series Installation Instructions
Application
These general-purpose power supplies can be used to
fulfill all the 120 Vac and 24
ments needed inside a building automation (BAS) panel,
industrial enclosure, or other general purpose electrical
120 Vac Convenience
4.610˝
OFF
4 Mounting Screw Holes
Hole diameter .203"
10 Amp Main
Breaker/Switch
PSB / PSC Series Selection Guide
Model Number * VA Rating
PSC100AB10 100 VA
PSB100AB10 100 VA
PSC40AB10 40 VA
PSB40AB10 40 VA
* All models may be followed by –IC.
Installation
When installing this product...
1. Read these instructions carefully. Failure to follow them
could damage the product or cause a hazardous condition.
2. Check the product ratings and ensure that the product is
suitable for your application.
3. Installer must be a trained, experienced service technician.
4. After installation is complete, perform a voltage check as
provided in these instructions.
Functional Devices, Inc. • p: 800.888.5538 • f: 765.883.7505 • www.functionaldevices.com • sales@functionaldevices.com
Vac* (Class 2) power require-
Outlet*
Neutral Ground
120 Vac 120 Vac Aux. Output
Removable Access Plate
LED Indicator
ON
RESET
OFF
Com
24 Vac
24 Vac ON/OFF
4.500˝
Panel
Enclosed
Mount
•
•
•
•
enclosure, in addition to on/off control, equipment over-
current protection, power indication, high/low voltage
separation, and convenience receptacles. They are also
useful for many applications outside of BAS.
5.620˝
2.245˝
6.250˝
4.500˝
5.620˝
120 Vac
Aux Output
Receptacles
• •
• •
• •
• •
CAUTION
RISK OF ELECTRICAL SHOCK - MORE THAN ONE DISCONNECT MAY BE
REQUIRED TO DE-ENERGIZE THE DEVICE BEFORE SERVICING.
CAUTION
REMOVAL OF COVER OR ACCESS PLATE (IF PRESENT) EXPOSES
HIGH VOLTAGE.
Bulletin B1450
3.900˝
To remove cover
Main Breaker on Secondary
Input Power Configuration
10 Amp Switch / Breaker Terminal Strip
10 Amp Switch / Breaker Terminal Strip
10 Amp Switch / Breaker Terminal Strip
10 Amp Switch / Breaker Terminal Strip
