VHT1 Transmitter Quick Start Guide
STEP
Connect Antenna to SMA Connector
STEP
Connect camera/video input source to BNC connector
STEP
Connect power, communications, and audio/data
inputs to the MDM-9P connector *see reverse side
STEP
Set con guration *see reverse side
When setting up your system, the transmit and receive
Note
antennas should be greater than 25 feet apart to
prevent serious damage to or destruction of the
receiver's front end
For Technical Support, Contact AMP
at (775) 345-9933 (9 am - 5 pm PST)
or engineering@advmw.com
Advanced Microwave Products
PO Box 1437
2465 Old Highway 40 West, Suite 200
Verdi, NV 89439
