Summary of Contents for Eliwell RadioAdapter
- Page 1 RadioAdapter ISM 2.4 GHz wireless system for plant monitoring and control USER MANUAL...
-
Page 2: Table Of Contents
3.5.1 - SCANNING TO FIND A NEw CHANNEL ..............................11 3.5.2 - SETTING COMMUNICATION CHANNEL MANUALLY ..........................11 4 - wARNINGS ......................12 4.1 - ELECTRICAL CONNECTIONS ......................12 4.2 - DISCLAIMER ............................12 4.3 - RESPONSIbILITY AND RESIDUAL RISkS ................... 12 4.4 - CONDITIONS OF USE ........................12 RadioAdapter... -
Page 3: -Introduction
RadioAdapter features IEEE 802.15.4 standard functions and runs on ISM frequency band at 2.4GHz. Thanks to MESH networking technology and associated dynamic routing combined with RadioAdapter capabilities to act as a repeater for adjacent nodes, large surface areas can be covered, getting around blocked paths to send or receive messages and continuous function guaranteed even when one or more nodes breaks down. -
Page 4: Circuit Diagram
Do not install the device in damp or dirt-laden areas. 1.5 - INSTALLING THE ANTENNA (NO FCC MODELS) The antenna can be inserted straight into the RadioAdapter connector or panel-mounted and connected to RadioAdapter using the cable supplied in the Antenna kit. -
Page 5: Models And Accessories
REPEATER RS-485 NODE Repeater The repeater is a RadioAdapter that is not connected to any Controller fitted with serial port that can be connected to RS-485 devices. It is installed between two NODES when the signal the NODE via a Televis or Modbus protocol. -
Page 6: Installation
2 - INSTALLATION The RadioAdapter device can function as part of the network, as a PAN-C, as a NODE or a repeater. The RadioAdapter should therefore be configured accordingly when it is actually inserted into the network. The communication network consists of: - A RadioAdapter configured as PAN-C and connected to a monitoring system (Televis or Modbus) - A RadioKey device to identify and configure the network. -
Page 7: How To Install A Node
2.2 - HOw TO INSTALL A NODE 2.2.1 - INITIALIzING A NODE - Connect the RadioAdapter to the power - Disconnect the RadioKey when the supply. GREEN LED on the NODE starts to TTL + Power RS485 Supply blink. TTL +... -
Page 8: How To Install A Repeater
- Set the switch on the RadioKey to position 1. - Connect the powered-on RadioAdapter to the RadioKey and wait for the GREEN LED (N) (on the RadioKey) to light up (YELLOW LED (P) off). The RadioAdapter is now configured as a REPEATER and information on the type of network is sent to the REPEATER. -
Page 9: Configuring The Pan-C
- Disconnect the RadioKey and configure the NODE as explained in section 2.2 How to install a NODE (ignore the first section 2.2.1 Initializing a NODE). - Configure the PAN-C again as explained in section 2.4 Configuring PAN-C Pag. 9/12 RadioAdapter... -
Page 10: Troubleshooting
3 - TROUbLESHOOTING 3.1 - REPLACING THE PAN-C When a PAN-C is found to be faulty, replace it with a new RadioAdapter. Follow the steps below when replacing a faulty PAN-C with a new one. Supervisor Power Power Power Supply... -
Page 11: Changing Channel
4 - Disconnect the NODE from the power supply and disconnect the RadioKey. Repeat the steps listed in points 3 and 4 for each NODE and repeater in the network without changing the setting on the RadioKey Position of RadioKey switch Channel Pag. 11/12 RadioAdapter... -
Page 12: Warnings
4.2 - DISCLAIMER This document is the exclusive property of ELIWELL CONTROLS SRL and may not be reproduced or circulated unless expressly authorized by ELIWELL CONTROLS SRL itself. The same applies to any person or company involved in preparing and editing this document.
