1. Introduction

The 32-bit USB Debug Adapter (UDA) provides the interface between the PC's USB port and the Silicon Labs 32-
bit target device's in-system debug/programming circuitry. The attached 10-pin debug ribbon cable connects the
adapter to the target board and the target device's debug interface.
Note: This USB debug adapter supports only SiM3xxxx variants of the Silicon Labs 32-bit MCU portfolio and none of the other
devices that can be referred to as "Silicon Labs 32-bit MCUs", including EFM32, EZR32, and EFR32 devices.

2. Relevant Documentation

Application notes can be found on the 32-bit MCU Application Notes web page: www.silabs.com/32bit-software.
 AN667: Getting Started with the Silicon Labs Precision32 IDE—Describes the software setup and
debugging process using the USB Debug Adapter.
 AN678: Precision32 Si32FlashUtility Command-Line Programmer User's Guide—The programming
utility and DLL discussed in this document uses the USB Debug Adapter to program the memory space of
32- bit devices.
Rev. 0.2 3/17
32-Bit SiM3xxxx USB Debug Adapter
USB D
XXXX
Figure 1. USB Debug Adapter
