Sloan ST-2309-A Installation Instructions

Water Closet Installation Instructions
Efficiency Series
Model ST-2309-A Junior Toilet
The RIghT ChOICe
wARNINg: Any vitreous china can chip or
break if the bolts or nuts are over-tightened
We thank you for your purchase.
or if mishandled.
Our products are 100% tested but should you have
any questions, please contact us by phone or at our
befORe yOu sTART...
web site.
• Check all local plumbing and building codes.
• Check for any damage to the new water closet
before installation.
whAT yOu wIll NeeD...
• Putty knife
• Safety glasses
• Measuring tape
• Spud wrench
NOTe: Plumbing system Requirements
√ Minimum flowing Pressure: 25 PsI
√ Minimum flow Rate: 18 gPM
5½"
(140 mm)
1 ½"
(38 mm)
5" or 7"
(127 mm or 178 mm)
(762 mm)
10" or 12"
(254 mm or
305 mm)
C L OF OUTLET
C L OF WASTE
To maximize The performance of your Sloan WaTer cloSeT, uSe only Sloan fluShomeTerS
1. ReMOvAl Of exIsTINg wATeR ClOseT
• Turn off the water supply.
• Disconnect the flush valve.
• Remove the existing water closet.
• Sponge
• 10" adjustable wrench
• Large level
• Wax seal
• Using putty knife, completely
remove old wax seal from floor
and bottom of water closet.
• Lay water closet down on
padded surface to help protect
the vitreous china.
wARNINg: hazardous gases
can escape through the closet flange
17½"
if new water closet is not installed quickly.
(445 mm)
A temporary fix: place a large rag in the
11-1/4"
(286 mm) closet flange.
13"
(330 mm)
10"
(254 mm)
30"
13 "
27"
(330 mm)
(686 mm)
10¾"
(273 mm)
FINISHED FLOOR
5"
(127 mm)
• Place and press in new wax seal around the water
closet bottom outlet.
• Install new 5/16" T-bolts.
2. INsTAllINg New wATeR ClOseT
• Check rough-in dimensions and install or relocate
flush valve and outlet as indicated.
• Record model number for reference.
• Take out the temporary rag (if used) from the water
Anillo
closet flange hole.
Old de cera
• Carefully align and lower the water closet over the
wax ring anterior
flange and T-bolts.
IMPORTANT! Do not lift or rock the water closet
after replacement. The watertight seal will have
to be replaced if breakage occurs.
Cover with rag Cubra con tela
• To seal, apply your full body weight around the
water closet.
• Place the plastic cap in the position indicated on
cap as marked.
• The metal washers and nuts can now be placed on
the bolt cap base and T-bolts.
* HET does not apply to 1.6 gpf/6.0 Lpf flush volume.
• Tighten the nuts carefully. CARe AND CleANINg Of vITReOus ChINA
Clean water closet with a cleaner safe for vitreous
china such as Sloan's Waterfree Urinal Cleaner/
Deodorizer. Spray and wipe clean using soft cloth. Soft
abrasive cleaners may be used to remove stains.
lIMITeD wARRANTy
Unless otherwise noted, Sloan Valve Company
warrants its products, manufactured and sold for
commercial or industrial uses, to be free from defects
of material and workmanship for a period of three
(3) years (one year for SF faucets, special finish and
IMPORTANT! Do not overtighten the nuts,
PWT electronics and 30 days on PWT software) from
breakage and chipping of vitreous china
the date of first purchase. During this period, Sloan
can occur.
Valve Company will, at its option, repair, replace, or
• Cut 1/4" or more over the top of the nut. refund the purchase price of any produce which fails
• Attach the bolt caps. to confom with this warranty under normal use and
service. This shall be the sole and exclusive remedy
IMPORTANT! Product damage can occur if
under this warranty. Products must be returned to
using a saw blade to cut off the excess
Sloan Valve Company, at customer's cost. No claims
T-bolt length. Make sure vitreous china is
will be be allowed for labor, transportation or other
protected and covered.
costs. This warranty extends only to persons or
organizations that purchase Sloan Valve Company's
3. COMPleTINg The INsTAllATION
products directly from Sloan Valve Company for
• Flush valve should be installed to manufacturer's
purpose of resale. This warranty does not cover the
installation instructions.
life of batteries.
• Turn on water supply valve.
TheRe ARe NO wARRANTIes whICh
• Install water closet seat (not included).
exTeND beyOND The DesCRIPTION ON
The fACe heReOf. IN NO eveNT Is slOAN
vAlve COMPANy ResPONsIble fOR ANy
CONseQueNTIAl DAMAges Of ANy MeAsuRe
whATsOeveR.
NOTE: IN NO EVENT SHALL THE SLOAN VALVE
COMPANY BE LIABLE FOR INCIDENTAL DAMAGES,
RESULTING FROM IMPROPER INSTALLATION, OR
FOR DAMAGES CAUSED BY NEGLECT, ABUSE
OR ALTERATION.
• Flush water closet a few times and check all
connections for water seepage.
• Check for leaks.
The information contained in this document is subject to change
without notice.
10500 Seymour Avenue
Franklin Park, IL 60131
Phone: 1-800-9982-5839
Fax: 1-800-447-8329
www.sloanvalve.com
© 2013 Sloan Valve Company
Code No. 0816397 – Rev. 1 (03/13)
