Wheeled Walker
Handle with lever brake
Handle height adjustment knob
Side brace
6 inch
(150 mm)
wheels
We recommend you keep this User Guide in a safe place for future reference.
Petite
u ser gui de
Prior to use please read all instructions.
Brake cable
Backrest
Padded seat with
concealed pouch
Bag with shopping
basket inside
Advertisement
Related Manuals for Evadale Healthcare Petite
Summary of Contents for Evadale Healthcare Petite
- Page 1 Petite Wheeled Walker Handle with lever brake Brake cable Handle height adjustment knob Backrest Padded seat with concealed pouch Bag with shopping basket inside Side brace 6 inch (150 mm) wheels u ser gui de Prior to use please read all instructions.
-
Page 2: Table Of Contents
Petite Wheeled Walker Overview page 3 Product Overview The Petite Wheeled Walker is ideally suited for Set Up page 4-5 users 5’5” (165 cm) or less, offering lower overall Operation page 6 height range and seat height. Designed for general... -
Page 3: Overview
If used outside, it is recommended for authorised dealer or Evadale Healthcare. smooth or sealed surfaces. Prior to use, remove all packaging and plastic It is not designed to be used as a wheelchair. -
Page 4: Set Up
set up Unfold the wheeled walker Remove the protective covering from all four wheels. Remove cardboard from between the rear wheels and brake latches. Place the wheeled walker on a stable surface. Unfold by spreading the frame while pushing down on the side braces, making sure each brace locks horizontally in place. - Page 5 set up Align handle and frame holes at the ideal height, and then insert the bolt (from inside the frame) and push until fully inserted. Ensure the bolt head fits securely within the hexagonal frame hole. Place washer on bolt (curved face against frame), screw on the Star Knob and tighten firmly.
-
Page 6: Operation
Operation Using as a walking aid immediately in case of an emergency. When using the wheeled walker as a walking aid, it is recommended both hands be placed firmly The ideal walking technique is to push the walker on the handles, with fingers curled around the forward to a comfortable arm’s length, then step in brake levers so that the walker can be stopped towards the walker, and repeat. -
Page 7: Transport And Storage
Transportation & storage removing the basket and bag To remove the basket and/or bag, lift up and fold back the padded seat. Use the handle to lift out the shopping basket. The bag can be removed for cleaning or when attaching specific accessories such as an Oxygen Bottle Carrier. -
Page 8: Safety And Maintenance
safety & Maintenance General Safety Precautions regular Maintenance Do not use the wheeled walker to transport Professional inspection of the a person while seated. wheeled walker is recommended at least once a year. A risk assessment should always be carried ◆... -
Page 9: Cleaning
Cleaning Do not use high pressure cleaners, steam cleaners or harsh, caustic chemicals for cleaning. Frame Bag and seat Wipe the wheeled walker frame with a damp cloth. Regularly clean the padding materials using a mild detergent solution up to 40 °C, or wash For more stubborn dirt, use a mild detergent with alcohol-based disinfectants if necessary. -
Page 10: Accessories
Accessories Walking Stick Holder Oxygen Bottle Carrier eD1430 eD1478 Designed to sit under the seat of any ‘A’ frame Allows easy storage and wheeled walker. Suspended by hooks attaching transport for walking sticks. to front and back cross piece. Angled for optimal Attaches to frame of wheeled oxygen supply and safety. -
Page 11: Warranty
Warranty This warranty is provided by Warranty Claims Evadale Healthcare To claim under this warranty, please contact (ABN 62 775 261 931) Evadale Customer Service Centre and have your of Unit 11, 12 Mars Road receipt or proof of purchase ready. Evadale may Lane Cove NSW 2066. - Page 12 470 mm Seat Height 310 mm Seat Depth 150 mm (solid) Wheels Aluminium Frame 130 kg Safe Working Load 176830 ARTG Evadale Healthcare Manufacturer For more information or to order, freecall 1300 883 194 www.evadale.com.au ©2012 Evadale Healthcare. All rights reserved.
