- Page 1 598557 BELT & DISC LINISHING SANDER 550WATT MOTOR & VARIABLE SPEED 25MM X 762MM BELT SIZE 150MM DISC SIZE INSTRUCTION MANUAL CONSUMER SERVICE CENTRE PO BOX 1012 HAMILTON NSW 2303 AUSTRALIA Made in P.R.C.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions..........................3 - 5 Contents of Package ............................6 Getting to Know Your Sander ..........................7 Assembly ........................... 7 - 9 Adjustments .......................... 9 - 11 General Use............................12 Troubleshooting............................13 - 14 Maintenance ...........................14 Parts Diagram ..........................15 SPECIFICATIONS Motor ..........550W S2 30min, 230V, 50Hz Motor Speed (variable) ........ - Page 3 SAFETY SYMBOLS IMPORTANT! Safety is the single most important consideration in the operation of this equipment. The following instructions must be followed at all times. Failure to follow all instructions listed below may result in electric shock, There are certain applications for which this tool was designed. W and/or used for any other application other than that for which it was designed.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS 14.ALWAYS dress properly. Loose clothing or jewellery may get caught in moving parts. Wear protective hair covering to contain long hair. 15.ALWAYS guard against electric shock. Avoid contact with earthed surfaces - pipes, radiators etc. 16.NEVER operate machine while under the influence of drugs, alcohol or any medication. - Page 5 SAFETY INSTRUCTIONS SPECIFIC SAFETY INSTRUCTIONS FOR SANDERS This machine is intended for the surfacing of natural, solid woods and composite materials. Any other use not manufacturer can cause unforeseen damage, and invalidate the warranty. ATTENTION: Use of this sander still presents risks that cannot be eliminated by the manufacturer. Therefore, the user must be aware that wood working machines are dangerous if not used with care and all safety precautions are adhered to.
-
Page 6: Contents Of Package
4. Apply a coat of paste wax to the table to prevent rust. Wipe all parts thoroughly with a clean dry cloth. 5. Set packing material and shipping carton aside. Do not discard until the machine has been set up and is running properly. Note: Not Actual Toolex Product Pictured below TABLE OF LOOSE PARTS A. Belt & Disc Sander Assembly F. -
Page 7: Getting To Know Your Sander
GETTING TO KNOW YOUR SANDER Note: Not Actual Toolex Product Pictured below 25mm x 762mm Belt / 150mm Disc Variable Speed Sander Sanding Belt 25mm x 762mm Sanding Disc 150mm Sanding Belt Tracking Knob Sanding Belt Safety Cover Sanding Belt Table... -
Page 8: Assembly
(between the holes for rubber feet). 4. Drill holes in the workbench at the 2 marks. Note: Not Actual Toolex Product Pictured below 5. Using long bolts, washers, lock-washers and nuts; or lag bolts; (fasteners not supplied), secure the sander to the workbench. - Page 9 2 ‘L’ mounting slots in the sides of the disc sander guide’s frame. FIG. D. Note: Not Actual Toolex Product Pictured below 2. Align the two screw holes in the guard with the arched slots above the angle gauges, so that the knobs &...
-
Page 10: Adjustments
ADJUSTMENTS Note: Not Actual Toolex Product Pictured below DISC TABLE ADJUSTMENTS - continued 2. Loosen the 2 disc-table adjustment handles (#39), and adjust table angle to 90º. 3. Re-tighten the 2 disc-table adjustment handles. 4. To adjust the disc-table to another angle, loosen the 2 disc-table adjustment handles. - Page 11 ADJUSTMENTS ARE COMPLETE. guard (#53), and three Phillips screws (#37) that secure the side cover (#54) to the sander’s frame. Note: Not Actual Toolex Product Pictured below 2. Remove the side cover. SIDE GUARD COVER AND 3. Push the tracking knob forward release the TOP CLEAR GUARD ARE belt tension.
-
Page 12: General Use
GENERAL USAGE Note: Not Actual Toolex Product Pictured below ON/OFF & VARIABLE SPEED SWITCHES 1. To start the machine, the Power Switch must be in the “OFF” position and the Variable Speed Switch must be turned to its slowest setting by being turned all the way to the left until solid resistance is felt. -
Page 13: Troubleshooting
TROUBLESHOOTING SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Motor will not start. 1. Low voltage 1. Start the motor at high speed. 2. Open circuit in motor or loose 2. Inspect all lead connections on motor connections. for loose or open connections. (Send Blown fuse or breaker. -
Page 14: Maintenance
TROUBLESHOOTING SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION MAINTENANCE MAINTENANCE REQUIRED FREQUENCY Service beyond recommended maintenance on these tools should only be performed by an Page 14... -
Page 15: Parts Diagram
PARTS DIAGRAM Page 15... - Page 16 PARTS LIST DESCRIPTION QTY. DESCRIPTION QTY. Page 16...
