Solartron Digital Input/Output Module Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
DIOM 502237_Issue 2.qxd
20/07/2005
15:38
Page fcov1
solartron
Digital Input/
Output Module
Manual No. 502237
Issue 2

Advertisement

loading
Need help?

Need help?

Do you have a question about the Digital Input/Output Module and is the answer not in the manual?

Questions and answers

Summary of Contents for Solartron Digital Input/Output Module

  • Page 1 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page fcov1 solartron Digital Input/ Output Module Manual No. 502237 Issue 2...

  • Page 2: Issue

    No part of this document may be reproduced or transmitted in any form or by means, electronic or mechanical, for any purpose, without the express permission of Solartron Metrology. © 2000 Solartron Group Ltd. All rights reserved.

  • Page 3: Table Of Contents

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 1 Index 1.0 Introduction 3.0 Communication with the DIOM INTRODUCTION ......3 ORBIT COMMANDS .

  • Page 4: This Manual

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 2 1.0: Introduction Introduction This Manual The Digital Input / Output Module (DIOM) enables the The manual describes the technical specification of the 'Orbit Network' to interface with the outside world. The product enabling you to connect to the DIOM. All module provides 8 general-purpose input / output lines, communication with the DIOM, including configuration housed in the standard Orbit Module case.
  • Page 5 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 3 1.0: Introduction Safety Summary WARNINGS: WARNING statements identify conditions or practices Do not operate in an explosive atmosphere that could result in personal injury or loss of life. To avoid explosion, do not operate this equipment in an explosive atmosphere.

  • Page 6: Diom General Specification

    NOTES: This equipment contains no user serviceable parts. Module Supply (from Orbit Network): This equipment must be returned to a Solartron Dealer 4.75 V - 5.25V @ 60 mA max. (all outputs on) for all service and repair. Does not include current sourced from +5V Orbit supply (pin 13).
  • Page 7 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 5 1.0: Introduction EMC Compliance IP Rating BS EN 50081-1: 1992 Generic emission standard Part 1. IP53 when mounted in an upright position. Residential, commercial and light Industry. IP50 when mounted in any position (other than BS EN 50081-2: 1995 Generic immunity standard Part 2.
  • Page 8 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 6 2.0: Detail Specification Pin Connections Inputs / Outputs: 8 lines used as either input or outputs, connected via a short (0.5 m) flying lead and 15-way D-type connector. Pin Number Pin Label Pin Number Pin Label pin 1 I/O bit 0...

  • Page 9: I/O Port: Input Specification

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 7 2.0: Detail Specification I/O Port: Input Specification • 4K7 pull up to Orbit +5 V • High-level input voltage ≥ +3.15 V • Low-level input voltage ≤ +1.35 V Absolute Maximum Ratings +30 V IH(MAX) -0.5 V IL(MIN)
  • Page 10 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 8 2.0: Detail Specification I/O Port: Output Specification - Driver Configuration External Supply Typical specification, assuming 8 outputs used at 100% duty cycle. • Open drain • Low-level output voltage ≤ +0.2 V Absolute Maximum Ratings - Each Output +30 V OH(MAX) -0.5 V...

  • Page 11: Connector

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 9 2.0: Detail Specification 0 V connections: Pins 9 to 12 DIOM connector Return current for load connected to an external supply must be connected to a local 0V (Load 0V). This prevents the load 0V current returning through pins 9 - 12.

  • Page 12: I/O Port: Output Specification - Driver Configuration Using Orbit Supply

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 10 2.0: Detail Specification I/O Port: Output Specification - Driver Configuration Using Orbit Supply +5 V Orbit Supply (pin 13 DIOM connector): Maximum 50mA total current is available from the Orbit supply via the DIOM. This can be used for external loads such as active switches, indicators and sensing devices.

  • Page 13: Configuration

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 11 2.0: Detail Specification I/O Port: Output Specification - Logic Configuration (for driving typical 5V logic inputs). • High-level voltage VH - 4K7 internal pull up to Orbit +5 V • Low - level voltage VL ≤ +0.2 V (50mA max sink) 2.0: Detail Specification Manual No.
  • Page 14 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 12 3.0: Communication with the DIOM Orbit Commands The following Orbit commands allow you to communicate with the DIOM. (Also refer to the Orbit Network Measurement System manual). When using the RS232 Interface Module please refer to the RS232 Interface Module manual. Orbit Command OrbitRst Description: reset all Orbit Modules.
  • Page 15 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 13 3.0: Communication with the DIOM Orbit Command OrbitSetaddr Description: set Orbit Module address. Type: addressed Parameters: card, channel, address, identity, option Each Orbit Module is given a unique 10 byte identity (ID) during manufacture. When used on a network it is more efficient to use a shorter temporary ADDRESS stored in the Orbit Module memory;...
  • Page 16 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 14 3.0: Communication with the DIOM Orbit Command OrbitRead1 Description: returns the state of the DIOM inputs. Type: addressed Parameters: card, channel, address, reading The 8 least significant bits of the returned 16-bit number show the state of the input pins. Each pin must first be set high (via OrbitPreset) if it is to be used as an input.
  • Page 17 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 15 3.0: Communication with the DIOM Orbit Command OrbitPreset Description: sets the DIOM outputs. Type: addressed Parameters: card, channel, address, preset The 8 least significant bits of the 32-bit number are used to set the output pins. A logic low (0) will turn the output driver on: the output pin will be set low (0V).
  • Page 18 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 16 3.0: Communication with the DIOM Orbit Command OrbitGetinfo Description: returns information on the Module / Probe Type: addressed Parameters: card, channel, address, module type, hardware type, resolution, module info Will return information about the type of module and / or probe. Using the OrbitIdentify command may return additional information.
  • Page 19 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 17 3.0: Communication with the DIOM Orbit Command OrbitClr Description: clear addressed Orbit Module. Type: addressed Parameters: card, channel, address Performs software reset on a particular Orbit Module. The Orbit Module will then need to be re-addressed. Allow at least 0.5 second for completion of the command.
  • Page 20 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 18 4.0: Application - Hardware Connecting to the DIOM. Example of wiring connections of the DIOM. Inductive loads must be suppressed. (i.e. protection diode.) 0V load must be connected to local 0V, to minimise load return current through DIOM and Orbit.

  • Page 21: Emc Immunity Enhancement

    DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 19 4.0: Application - Hardware EMC Immunity Enhancement Suggestions If the DIOM is used in applications where there may be higher than normal interference sources (i.e. near heavy industrial machinery). Adopting some or all of the following measures may enhance immunity performance.
  • Page 22 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 20 5.0: Application - Software Input / Output Control DIOM Input / Output ports are read by OrbitRead1 and controlled by OrbitPreset. (Refer to Communications with DIOM). In the example below, Port 0 (bit 0) is driving a load and Port 1 (bit 1) is an input to a switch (All other Ports are not used in this example).
  • Page 23 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 21 5.0: Application - Software 5.0 Application - Software Manual No. 502237 Issue 2...
  • Page 24 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 22 5.0: Application - Software Multiple readings In some applications multiple readings of OrbitRead1 may be required i.e.: External Electrical interference. Switch bounce. Noisy Supplies. Mechanical vibration. If a port is being used to read a switch condition for example, a single OrbitRead1 may have missed the event or may have seen a noise spike in the place of the event.
  • Page 25 DIOM 502237_Issue 2.qxd 20/07/2005 15:38 Page 23 Return of Goods Products returned for repair should be shipped prepaid to Solartron Metrology. The shipping container should be marked: "Return for Repair" Model ..Type ..The following information should accompany the product(s): 1.
  • Page 26 Fax: +49 (0) 208 31441 Fax: +44 (0) 1243 833332 Fax: +1 (716) 965-4144 Email: sales@solartronmetrology.com Web: www.solartronmetrology.com solartron Solartron pursues a policy of continuous development. The specifications in this document may therefore be changed without notice Solartron Metrology. A Roxboro Group Company...
