- Page 1 Wireless H3G-TA ENGINEERING MANUAL Hangzhou Huasu Jada Technology Co., Ltd No.16, Xiyuan Wu Road, Westlake Tech-economy Zone, Hangzhou, China TEL: 0086-571-87967915 FAX:0086-571-87968969 www.huasucn.com...
- Page 2 Notice: 1. The wireless H3G-TA device may not cause harmful interference 2. The wireless H3G-TA device must accept any interference received, including interference that may cause undesired operation This device complies with Part 15 of the FCC Rules. Operation is subject to the following two...
-
Page 3: Table Of Contents
Wireless H3G-TA Engineering Manual A8 Table of Contents Tools required for installation and Debugging ................1 Overview ..........................3 1 2 System Components and Module Description ..............5 2.1 System Components ...................... 5 2.2 TA Module ........................6 2.3 CM Module ........................7 ... -
Page 4: Tools Required For Installation And Debugging
Wireless H3G-TA Engineering Manual A8 Tools required for installation and Debugging Picture Description Installation tools Socket wrench 12902 Socket head 12307/309/311 Multimeter VC9807A+ Clamp Meters VC3266D Stripper 91108 Phillips-head screwdriver 61213 WWW.HUASUCN.COM TEL:0571-87967915... - Page 5 Wireless H3G-TA Engineering Manual A8 Flat-head screwdriver 61311 Phillips-head screwdriver 61211 Needle nose pliers 70124A Diagonal pliers 70221A Wire pliers CP-376TR Scissors 03131 WWW.HUASUCN.COM TEL:0571-87967915...
-
Page 6: Overview
（this manual） 1 Overview Wireless H3G-TA battery monitoring system is generally composed of wireless TA module, TC module, wireless converter and CM module. The CM module with LCD display and can upload data through RS485 or network port. In remote monitoring, a computer can be connected to battery monitoring equipment by network or serial port. - Page 7 Wireless H3G-TA Engineering Manual A8 Figure 1-1-1 The H3G-TA standard configuration has the following features and functionality: - Online monitoring of cell voltage, internal resistance, cell temperature, overall voltage, charge and discharge current and ambient temperature. - Automatic over-limit alarm...
-
Page 8: System Components And Module Description
Wireless H3G-TA Engineering Manual A8 2 System Components and Module Description System Components Standard configuration below： Part Number Picture Descriptive name TA Module CM Module TC Module Current Transfer (CT) TA test cable TC test cable communication cable Power cable WWW.HUASUCN.COM... -
Page 9: Ta Module
Wireless H3G-TA Engineering Manual A8 Wireless converter Optional parts： Part number Picture Descriptive name Monitoring Module The system topology is below： Figure 2-1-1 TA Module The TA Module monitors cell voltage of a single battery, internal resistance and temperature and uploads data via the communications port. The TA Module doesn’t have an alarm function. -
Page 10: Cm Module
Wireless H3G-TA Engineering Manual A8 Figure 2-2-1 Name Description Test port, connects with battery negative and positive ⑴ poles. A double colors LED with a red and green light, the green ⑵ light indicates power on, the red shows that communication is connected. - Page 11 Wireless H3G-TA Engineering Manual A8 Figure 2-3-1 Name Description Two lines of text are displayed，122X32. ⑴ LCD display Total of four buttons, “Esc” for exit，“▲”“▼”for page Button ⑵ up/page down， “Enter” for confirmation. POWER: is the power light; E1:indicates a communication error;...
-
Page 12: Tc Module
Wireless H3G-TA Engineering Manual A8 TC Module The TC Module monitors charge and discharge current and ambient temperature for one string. The TC Module communicates with the CM module through the COM1 and COM2 parallel port. One string needs one TC Module. The following details are shown below. - Page 13 Wireless H3G-TA Engineering Manual A8 Figure 2-5-1 Name Description It’s a 4 core for collecting the pins of COM1B～COM4B on Communication CM module. From the left are B、A、+、-,where B is – of ⑴ Power Port RS485，A is + of RS485，baud rate is 9600BPS, +/- is a 12VDC input with maximum 0.3W power dissipation.
-
Page 14: Installation And Mounting
Wireless H3G-TA Engineering Manual A8 3 Installation and Mounting Numbering the Batteries Before connecting the TA Modules to the batteries, the batteries should be numbered and labeled correctly by using a label to paste on the surface of the battery where the labels are easy to be seen. - Page 15 Wireless H3G-TA Engineering Manual A8 Figure 3-2-1 It is important to note that the TA test line must be installed on the outside of the battery connection bar (cable) and is not allowed to install between the battery pole and the connection bar.
-
Page 16: Mounting Ta Module
Wireless H3G-TA Engineering Manual A8 Mounting TA Module Pastes the TA modules on a side of battery case, then plug the TA test cable in the port JI on the modules (See (1)), the green LED will turn on. Figure 3-3-1... - Page 17 Wireless H3G-TA Engineering Manual A8 3. When modifying the TA module address, you need to change one by on. 4. Each TA module / TC module needs to set the address separately, and the default address is 1. 5. For the same battery string, the TA module port number needs to be consistent with the wireless converter port number.
- Page 18 Wireless H3G-TA Engineering Manual A8 The TA address modifier can be used to modify TA and TC module addresses. This way for modifying is more conveniently and quickly, especially when modifying in large quantities. If you need a TA address modifier, you can contact us directly to buy.
-
Page 19: Address Setting For Tc Modules By Cm Module
Wireless H3G-TA Engineering Manual A8 Port Number Setting for TA Module Staring the serial port software and sending the modification commands "01 06 CRC16 " and XX is the port number. 00 1D 00 XX+ Address Setting For TC modules by CM Module Connecting COM1 or COM2 port of the TC module to the COM1A port of the CM module, and the COM1B port cannot be connected to the wireless converter. -
Page 20: Ct And Tc Module Installation
Wireless H3G-TA Engineering Manual A8 COM1，TC-Mod, 1 Notice: Modifying module type by“▲▼” type module, Notice:Module COM1，TC-Mod,241 address is 241 Notice: 1→241 means address modifying is COM1，TC-Mod,242 successful, 1 is modified to 241 TC-Mod, 1→241 CT and TC Module Installation The Current Transfer (CT) should be mounted on a battery cable and let the cable go through the CT. -
Page 21: Cm Module Installation And Wiring
Wireless H3G-TA Engineering Manual A8 Figure 3-5-3 The default address for TC module is 1, which can be changed with the CM module or the address module like the way the TA module does. The address assigned to TC module is 241 by “Easy Setup”, so the TC module’s address should be changed to that address before connecting to CM module. - Page 22 Wireless H3G-TA Engineering Manual A8 WWW.HUASUCN.COM TEL:0571-87967915...
-
Page 23: Wiring Notice
Wireless H3G-TA Engineering Manual A8 Wiring Notice The wiring should be clear.The intuitive part should be horizontal and vertical as far as possible, and the part near the battery should be orderly which should not look disorderly (the direction of installation of the collecting wiring ring should be the same) Where there is a need to wire from a trench, it needs to ask the user if it is necessary to add a PVC tube to the harness. -
Page 24: Alarm Checking
Wireless H3G-TA Engineering Manual A8 The time is the last updated time for battery resistance values. Continue to press “▼”: S1 V&C： 352.5V +0.1A “V” means string voltage and “C” means string current. Continue to press “▼”: S1-001#： +23.5 ℃... -
Page 25: Reading Accuracy Checking
Wireless H3G-TA Engineering Manual A8 After performing a resistance test, the values can be used as a standard resistance for those specific batteries. See the steps below to set a standard resistance setting. “3 Setup”→“3.8 R Set”→Choose the string then press “Enter”, the last IR values will be saved as standard IR values. -
Page 26: Advanced Setting
Wireless H3G-TA Engineering Manual A8 6 Advanced Setting Changing Alarm Llimits In the menu “3 Setup” → “3.5 Str Set” →Choose a string then press “▼” to the page where you want to change the parameters. IR Setting Changing IR alarm limit The default rate is 50% that means the battery IR is higher 50% than the standard one stored in the CM, CM will give an IR alarm. - Page 27 Wireless H3G-TA Engineering Manual A8 Click ‘Reset BMS’: After reloading the web, enter admin in the User ID blank and 2022 in the Password blank: Choose a new firmware file and click ‘Upload’: The updating process starts and will finish in few minutes.
-
Page 28: Setting Capacity Estimation Function (Optional)
Wireless H3G-TA Engineering Manual A8 Setting Capacity Estimation Function (Optional) The capacity estimation function is optional. At present, the capacity estimated by this function is only for your reference and some models of H3G-TA cannot support this function. This function is turned off when you received and can be turned on by the CM Module menu. -
Page 29: Appendix 1: Table Between Lead-Acid Battery Installation Hours And Ir Value
Wireless H3G-TA Engineering Manual A8 8 Appendix 1: Table between Lead-Acid Battery Installation Hours and IR Value Capacity（AH） 2V（mΩ） 6V（mΩ） 12V（mΩ） 1.55 4.65 9.30 1.15 3.45 6.90 0.85 2.55 5.10 0.57 1.71 —— 0.39 1.17 —— 0.32 0.96 —— 0.25 ——...
