Outdoor Gate Entry Alarm
Model Number: THP211
Product Description
The product is intended to monitor outdoor gates or other entry points for safety and security. It is designed to detect a gate
or door opening, which will immediately activate a very loud 105 decibel alarm. It uses a magnetic break triggering
mechanism to activate the alarm. There is a 3-digit password keypad which will allow homeowner to arm and disarm the
alarm and also to bypass the alarm when opening the gate or door.
THP211 Alarm Features
•Installs in minutes
•Adult bypass function
•Water resistant for outdoor use
•9V battery operated (battery not included)
•Battery low indicator
IMPORTANT -
installation.
installation to ensure it functions properly.
Installation Instructions
Tools Required
9V Alkaline Battery
#2 Phillips screwdriver for wall anchors
#1 Phillips screwdriver for bracket screw and battery compartment screw.
1/4" drill if attaching the mounting bracket using the included Phillips screws and wall anchors.
Step-by Step Installation Procedure
1.
Remove all packaging.
2.
Remove the screw on the bottom front of the unit, below the "Bypass" button.
3.
Slide the mounting bracket off.
4.
Remove the screw at the bottom back of the unit, exposing the battery
compartment. Insert 9V Alkaline Battery and close battery compartment.
5.
Reattach the mounting bracket if desired.
6.Locate a suitable location for the mounting the THP211. Install with screws, use
anchors if installing into drywall or plaster.
7.
Use the adhesive pads or screws to mount the magnetic sensors – make sure the
arrows line up (see diagram below).
Low Battery Indicator
If the battery is low, the small LED light on the keypad will continuously flash, indicating it is time to replace the
battery.
Read and thoroughly understand the instructions and warranty prior to
The installation of this alarm requires that the alarm be tested after
Advertisement
Table of Contents
Summary of Contents for Reliance Controls Corporation THP211
-
Page 1: Product Description
Insert 9V Alkaline Battery and close battery compartment. Reattach the mounting bracket if desired. 6.Locate a suitable location for the mounting the THP211. Install with screws, use anchors if installing into drywall or plaster. Use the adhesive pads or screws to mount the magnetic sensors – make sure the arrows line up (see diagram below). - Page 2 ARMING AND DISARMING THE ALARM To “ARM” the THP211 Outdoor Gate Alarm: Enter your password and press the “ON/OFF” button on the keypad. After you enter the password, you will hear a series of 3 beeps, indicating the alarm is “ARMED”.
-
Page 3: Contact Information
One Year Limited Warranty Reliance Controls Corporation (“Reliance”) warrants this product to be free from defects in materials and workmanship under normal use for a period of one year from date of purchase, provided the product has been installed and used in accordance with Reliance’s instructions and has not been subjected to misuse, alteration, modification, accident, or repair...
