- Page 1 Jameco Part number 151482 Ultrasonic Sensor with RS-232 Output User's Guide Jameco Part Number 151482 Senix Corporation, 52 Maple St., Bristol, VT 05443 © 1998 by Senix Corporation...
-
Page 2: Product Overview
Initial product release April 1, 1998 Warranty Senix, Inc. will repair or replace, at our option, any part found by us to be defective in material or workmanship if the product is received by Senix, freight prepaid, within one year from the date of original shipment to buyer. -
Page 3: Table Of Contents
Software ................................7 Performance ................................8 Precautions ................................8 Adjustments ................................8 IN CASE OF DIFFICULTY ....................9 Basic Checkout ..............................9 Common Problems ............................... 9 Repairs and Returns .............................. 9 Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 3... -
Page 4: Ultrasonics Overview
Unaffected by Target's Optical Characteristics The sensor's operation is not sensitive to ambient light levels, the target color, or target's optical transparency or reflectivity. Sensitive Detects large and small objects. and many more... Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 4... -
Page 5: Getting Started
0 to +70 C (32 to 160 F) Humidity 5-95%, non-condensing Measurement Period 50 mSec (20 Hz update) Interface connections Terminal Block Transducer connection 2-pin Molex Weight 1.6 oz. Size 2.85L x 1.85W x 1.25H Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 5... -
Page 6: Beam Pattern
As soon as listed above in the Sensor Terminal column. you apply power, the Power Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 6... -
Page 7: Operation
50 mSec. To exit the program, hit any key. Refer to the source code file JAMECO1.BAS to understand how to read sensor data and calculate the distance. Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 7... -
Page 8: Performance
A practical cable maximum length is • Keep transducer away from ultrasonic noise 20 feet, and longer cables should be shielded in sources, such as pressurized air nozzles electrically noisy areas. Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 8... -
Page 9: In Case Of Difficulty
Repairs and Returns If you need to discuss a problem or return a unit please call the following number for technical support: Jameco Electronics (415)592-8097 (voice) (415)592-2503 Senix Corporation, 52 Maple St., Bristol, VT 05443 Page 9...
