Summary of Contents for Azalea Networks MSR4K44S
- Page 1 AZALEA WIRELESS MESH ROUTER MSR4K44S INSTALLATION GUIDE May 2007 V2.0...
- Page 2 AZALEA MSR4K44S INSTALLATION GUIDE Interconnection cable used inside this device is less than 140 feet. COPYRIGHT 2007 AZALEA NETWORKS...
- Page 3 Networks reserves the right to make changes to products described in this document without notice. Azalea Networks does not assume any liability that may occur due to the use or application of the product(s) described herein. DISCLAIMER: LIMITATION OF LIABILITY 1．Before installation, it’s strongly recommended and requested that users shall pay particular attention...
- Page 4 AZALEA MSR4K44S INSTALLATION GUIDE Safety Warnings MSR4K44S must be installed by trained professional installation technician. All below warning information must be read before installation. General Safety Warnings You can be killed or injured if performing antenna installation near electrical power lines. Carefully read and follow all instructions in this guide. Please be sure there are no high voltage and electronic field.
- Page 5 The installation of power switch must be performed by a trained professional technician. The power switch is not supplied with the MSR4K44S. The power cord must be assembled by a professional installer, and the final assembly must comply with related requirements.
- Page 6 AZALEA MSR4K44S INSTALLATION GUIDE changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. REMINDING This device complies with Part 15 of the FCC Rules. Operation is subject to the...
-
Page 7: Table Of Contents
4.2 Installation of directional antenna..................17 4.3 Omni Antenna Installation ....................19 5 MSR4K44S Installation ....................20 5.1 Install MSR4K44S on Mast ....................20 5.2 Mounting MSR onto wall ....................20 5.3 Grounding of MSR4K44S....................21 5.4 Assembling Solar Shield ....................21 6 Lightning Protection Installation ...................22... -
Page 8: Msr4K44S Quick Installation Guide
MSR4K44S Quick Installation Guide This Quick Installation Guide provides step by step instructions for installing and setting up the MSR4K44S. Content includes methods to access the MSR4K44S. For configuration, please refer to manuals in the attached CD ROM. 1.1 Further Reading More detailed configuration instructions can be found in the CD-ROM. -
Page 9: Abstract
AZALEA MSR4K44S INSTALLATION GUIDE Abstract Function Introduction MSR4K44S is a multi-functional wireless mesh router, which can be connected with end user equipment directly or other MSR routers and wire networks to set up wireless network. The basic functions are listed below: •... -
Page 10: Operating Range
Ethernet Cable Figure below shows one end of the Ethernet cable for connecting to the Ethernet port on the MSR4K44S, and the other end of the cable with a standard RJ45 jack. Between the two cable connectors in the diagram shows... -
Page 11: Console Cable
AZALEA MSR4K44S INSTALLATION GUIDE White/blue Pin 2 Blue Pin 3 White/brown Pin 6 Brown Pin 8 Ground Pin 9 Console Cable The weather insulated console cable plug and pin mapping are shown in the figure below. The other end of the console cable which connecting to the laptop is a standard DB9 connector. -
Page 12: Screws
AZALEA MSR4K44S INSTALLATION GUIDE Connection guide for power cable: Phase（Live Line） – 2 pin of 3 pin power cable with water protection Neutral（Zero Line） – 3 pin of 3 pin power cable with water protection Grounding– 1 pin of 3 pin power cable with water protection... -
Page 13: Installation Preparation
AZALEA MSR4K44S INSTALLATION GUIDE Installation Preparation Site Survey site surveyis is the key step in wireless network project, which is decisive to the reasonablity of system design and the smooth implementation of deployment. Site survey tools The site survey tools should be prepared and checked before departure, the tools... -
Page 14: The Principle Of Site Survey
Site survey engineer should conduct detail measurements according to the plan, the measurements and records include site location information, antenna selection, MSR4K44S mounting position etc. Site survey report is suugested to prepared after all site survey works finished. Eye measurement: building information, terrain information Eye measurement is to verify there are any obstacle and reflection in wave propagation environment and terrain informing, such as building, trees, etc. -
Page 15: Tools
40－60mm; Grounding is prepared already; Check the distance between MSR4K44S and Grounding point; If cabling need to go through wall or ceiling; Special installation material or tools are needed or not. -
Page 16: Antenna Installation
Height of antenna installation: The antennas height can be different even for antennas connected to same MSR4K44S. It would be determined by the space of installation, or by design requirement; The antenna height for access could be 20 meters in open and flat area of city. It could be 30 meters in open area in rural flat area;... -
Page 17: Installation Of Directional Antenna
AZALEA MSR4K44S INSTALLATION GUIDE Installation of directional antenna Assembling of installation accessories Installation accessories of directional antenna includes: directional antenna Antenna up-bracket (length adjustable) Antenna down-bracket U-bolt Nuts to connect antenna and bracket Tools of antenna installation Screwdriver (crosspoint head) - Page 18 AZALEA MSR4K44S INSTALLATION GUIDE Antenna Installation Tools: Spanners size 10 1． The height of antenna must follow the requirement in desgin documentation ( enough isolation should be secured between antennas, vertical isolution is much better than horizental isolation); 2． Put antenna to pole by U-bolt, start from upper U-bolt then down one;...
-
Page 19: Omni Antenna Installation
The installation should be done by experienced antenna installer. Power line and high electric field must be avoided. Don’t stand on side of antenna of MSR4K44S when MSR4K44S is operating, there are strong electromagnetic field surrounding the antenna Don’t do any installation works during raining time. -
Page 20: Msr4K44S Installation
1. use long bolts to fasten the pipe holder and bracket to the mast 2. use 2 MSR4K44S fastening bolts to mount the MSR box to the bracket 3. use the 4 shied bolts to mount solar shield to MSR400 And MSR4K44S could also be mounted on horizon pole by mounting bracket equipped. -
Page 21: Grounding Of Msr4K44S
5． Connect the other side of grounding wire with grounding bar; 6． Daub butter on both side of grounding wire Never skip grounding in the MSR4K44S installation, and it must be finished before powering up MSR4K44S.The residence of grounding wire must be less than 5 ohm. Assembling Solar Shield Secure screws through the holes on the corner of shield to MSR4K44S. -
Page 22: Lightning Protection Installation
AZALEA MSR4K44S INSTALLATION GUIDE Lightning Protection Installation The lightning protector is to protect MSR4K44S to avoid damage by burst high current from lightning. Lightning protector should be installed between radio port and antenna feeder, and the lightning protector should be connected with lightning system of the building . -
Page 23: Feeder Installation
AZALEA MSR4K44S INSTALLATION GUIDE Feeder Installation Feeder is used to connect antenna with MSR4K44S. Due to the high propagation loss for high frequency waves , the feeder must be as short as possible to get minimum loss of signal strength. If long feeder must to be used, higher diameter feeder is recommended. -
Page 24: Ethernet Cable Installation
3． Water proof the connection by wiring insulation Adhesive Tape and PVC insulation type; Power Cord Installation MSR4K44S use 110-220V AC as power, the power interface is on the left bottom of MSR4K44S. Power cable should be the last step of installation. Tools: Diagonal Pliers，paper knife The procedure of power cable installation: 1．... -
Page 25: Completed Installation
AZALEA MSR4K44S INSTALLATION GUIDE Completed Installation Picture of site with completed installation: COPYRIGHT 2007 AZALEA NETWORKS... -
Page 26: Administrating The Msr4K44S
AZALEA MSR4K44S INSTALLATION GUIDE Administrating the MSR4K44S There are two methods of performing the quick start configuration: using the Quick Setup Wizard provided by MSR series’ Web-based Management Interface (WMI), or using the setup command of the router’s Command Line Interface (CLI). Azalea recommends using the Quick Setup Wizard which is accessible from most modern internet browsers such as Internet Explorer. - Page 27 AZALEA MSR4K44S INSTALLATION GUIDE from these other nodes, giving these other nodes an indirect connection to the internet. Unlike node 1, node 2 does not serve any client devices but only forwards traffic to and from other nodes. As such, both of its radios are configured in backhaul mode.
- Page 28 AZALEA MSR4K44S INSTALLATION GUIDE 11.2 Configuring nodes with the Quick Setup Wizard The basic software requirement for the web-interface is: • Web Browser： Internet Explorer 5.5 and above with Javascript enabled • Optimal Resolution：1024 X 768 and above Accessing the Quick Setup Wizard To access the WMI’s Quick Setup Wizard, input the IP address of that router and the port:...
- Page 29 AZALEA MSR4K44S INSTALLATION GUIDE Figure 2 Web Management Interface Home Page Using the Quick Setup Wizard To configure a node with the Quick Setup Wizard, answer the questions asked during each step of the wizard. After entering the answers for all the questions at one step, click the “Next”...
- Page 30 AZALEA MSR4K44S INSTALLATION GUIDE Figure 4 Configuring the portal node, step 2 Figure 5 Configuring the portal node, step 3 COPYRIGHT 2007 AZALEA NETWORKS...
- Page 31 AZALEA MSR4K44S INSTALLATION GUIDE Figure 6 Configuring the portal node, step 4 After the last step of confirming the reboot is performed, the web interface would stop responding for a few seconds while the router reboots itself. Note that since the...
- Page 32 AZALEA MSR4K44S INSTALLATION GUIDE Figure 8 Configuring the point node, step 2 Figure 9 Configuring the point node, step 3 Example Configuration 3: AP node The following figures show how the example AP node can be configured by answering the questions on each screen.
- Page 33 AZALEA MSR4K44S INSTALLATION GUIDE Figure 10 Configuring the AP node, step 1 Figure 11 Configuring the AP node, step 2 Figure 12 Configuring the AP node, step 3 Note: The scope of this document does not cover tuning the mesh network for total coverage.
-
Page 34: Appendix
AZALEA MSR4K44S INSTALLATION GUIDE Appendix MSR4K44S basic specifications 802.11a/b/g Quad radio Antenna changeable Power range: 100 ~ 240 VAC 50/60Hz Power consumption: 10W Output power: 100mw(20dBm) 400mw(26dBm, b/g) ‐ ℃ Operating temperature: 40 ~ +55 ‐ ℃ Storage temperature: 40 ~ +80 Operating humidity: 10%~90% non condensing Wind Survivability: <165mph...
