Summary of Contents for Agrint COUNTRY
- Page 1 USE AND MAINTENANCE MANUAL ROTARY TILLER TYPE COUNTRY Country-e-05 Use and maintenance manual : COUNTRY...
-
Page 2: Preface
PREFACE This manual is an integral part of the machine. It must always accompany the machine and be kept within reach of the operator. The enclosures mentioned are on integral part of this manual. The purpose of this manual. This manual gives information for the correct and safe use of the machine. The owner must read this manual carefully before work with the machine. -
Page 3: Description
DESCRIPTION UNCTION OF USE The machine, thanks to the large range of types, carries out all the function related with tools rotation in various work environment (open field, vineyards, orchards, flower gardens, parks, vegetable gardens), in all type of ground whatever its composition (sandy soil, medium mixture, clay) and consistency (crumbly, hard, semi-plastic) may be. -
Page 4: Technical Specification
Power Working width Weight Working depth Total width N° of hoes inch lbs. inch inch n° n° flange hoes 15-35 11-26 133 293 15÷17 15-35 11-26 146 322 15÷17 COUNTRY 15-35 11-26 159 351 15÷17 15-35 11-26 171 377 15÷17... -
Page 5: Safety Information
SAFETY INFORMATION ENERAL REGULATIONS Only work in daylight. The machine must not be used near people, especially children or animals. Wear long pants and heavy shoes. The protections are integral part of the machine: always work with the protections. ... -
Page 6: Safety Signs On The Machines
SAFETY SIGNS ON THE MACHINES In this section the safety signs on the machine are reproduced and explained. 1. Read the operator manual. 2. Disconnect the tractor key before maintenance and repair operations. 3. Don’t remove safety protection. 4. Stay at safety distance from PTO shaft. 5. -
Page 7: Instruction For Use
INSTRUCTION FOR USE EFORE BEGINNING WORK a) Adjust working depth as follows : 1. Unscrew nuts "B" ant take out the screws. 2. Adjust working depth moving slide "A" towards up to increase and towards down to decrease. 3. Plug in the screws and lock nuts "B". 4. -
Page 8: To Beginning Work
c) Hook the machine to the tractor, operate as follows : 1. Remove the safety pins then take out the pins from the two lower connection points of the machine. 2. Plug in the raising tractor beams into the lower hitch points of the machine, plug in the pins, and lock with the safety pins. -
Page 9: Reverse Set-Up
COUNTRY STANDARD COUNTRY REVERSE To set-up COUNTRY as Reverse rotary tiller operate as follow: a) Disassemble from the deck the upper linkage “UL”, the right and left lower linkages “LL”, the rear tail “RT taking out the 2 stopper “RTS”, the chain holder “CS” and the gear box “GB”. -
Page 10: Maintenance Instructions
MAINTENANCE INSTRUCTIONS On diagram "A" the maintenances are indicated with their terms to effect on the machine. Not follow the scheduled terms can compromise the functionality of the machine and in this case the warranty is not applicable. IAGRAM "A" SCHEDULED MAINTENANCE FIRST AFTER 10 EACH 30... -
Page 11: Greasing
1. G REASING At the scheduled time on diagram "A", grease points "B-C-D". Greasing points are equipped with greaser HYDRAULIC TYPE MODEL "A" UNI 7663. To greasing use only MULTIFUNCTIONAL GREASE LITHIUM BASED Type NLGI 2. IL CHECK - OIL SUBSTITUTION IN GEAR BOX At the scheduled time on diagram "A", check or substitute oil into gear box. -
Page 12: Oil Check - Oil Substitution In Side Transmission Box
IL CHECK - OIL SUBSTITUTION IN SIDE TRANSMISSION BOX At the scheduled time on diagram "A", check or substitute oil into side transmission box. To fill oil use only OIL SAE 140 EP. Transmission gear box capacity: 2 L a) To check oil level in side transmission box, operate as follows : 1. -
Page 13: Hoes Substitution
4. HOES SUBSTITUTION a) To change the hoes, operate as follows : 1. Unscrew the two nuts "A" that lock the screw of the hoes to change. 2. Take out the two screws from the holes and take out the hoe “B”. 3. -
Page 14: Problems Solving
PROBLEMS SOLVING TROUBLES GROUNDS AND SOLUTIONS -Decrease the forward speed -Increase the working depth (slides) Insufficient depth of work -Broken hoes - Replace -Not balanced hoes - Balance -Broken or damaged hoes - Replace -Check the hoes assembling Hoes don't penetrate -Foreign objects between hoes - Clean Tiller bounces on the ground and vibrates -Soil too dry and hard - Decrease the forward speed... -
Page 15: Transport
TRANSPORT Except when working, moving the machine takes place when the machine is standing still and the transmission is disconnected. <Important>: keep speed low avoiding holes and ground roughness. <Important>: Before begin the movements always make sure that the safety hooks be in position. <Note when on the road, obey existing traffic laws. -
Page 16: Work And Maintenance Sheet
WORK AND MAINTENANCE SHEET Every user should register on this sheet the facts about the life of the machine (both work and maintenance), so as to attest its conditions. DATE WORKING MAITENANCE NOTE USER HOURS... - Page 17 SPARE PARTS AND OPTIONS...
-
Page 18: Country Mechanisms
COUNTRY MECHANISMS... -
Page 19: Country Frame Components
COUNTRY FRAME COMPONENTS... -
Page 20: Table Of Contents
HOES SUBSTITUTION ............................13 CHAIN SUSTITUTION ............................13 PROBLEMS SOLVING............................... 14 TRANSPORT ..................................15 STORAGE ..................................... 15 INFORMATION ON DEMOLITION ..........................15 WARRANTY ..................................15 WORK AND MAINTENANCE SHEET ..........................16 COUNTRY MECHANISMS ............................... 18 COUNTRY FRAME COMPONENTS ..........................19...
